MMSTA13/MMSTA14

NPN SURFACE MOUNT DARLINGTON TRANSISTOR

Features

•

Epitaxial Planar Die Construction

Complementary PNP Type Available

(MMSTA63/MMSTA64)

Ideal for Low Power Amplification and Switching

High Current Gain

Ultra-Small Surface Mount Package

Lead Free/RoHS Compliant (Note 2)

"Green" Device (Note 3 and 4)

SOT-323

Dim

B C

Min

0.25

1.15

2.00

0.30

1.20

1.80

0.0

0.90

0.25

0.10

Max

0.40

1.35

2.20

0.40

1.40

2.20

0.10

1.00

0.40

0.18

0.65 Nominal

Mechanical Data

•

Case: SOT-323

Case Material: Molded Plastic, "Green" Molding

Compound, Note 4. UL Flammability Classification

Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020C

Terminal Connections: See Diagram

Terminals: Solderable per MIL-STD-202, Method 208

Lead Free Plating (Matte Tin Finish annealed over Alloy

42 leadframe).

MMSTA13 Marking K2D, K3D, See Page 3

MMSTA14 Marking K3D, See Page 3

Ordering & Date Code Information: See Page 3

Weight: 0.006 grams (approximate)

0°

8°

All Dimensions in mm

Maximum Ratings

= 25°C unless otherwise specified

Symbol

CBO

CEO

EBO

, T

STG

Value

300

200

625

-55 to +150

Unit

°C/W

°C

Characteristic

Collector-Base Voltage

Collector-Emitter Voltage

Emitter-Base Voltage

Collector Current - Continuous (Note 1)

Power Dissipation (Note 1)

Thermal Resistance, Junction to Ambient (Note 1)

Operating and Storage Temperature Range

Notes: 1.

Device mounted on FR-4 PCB, 1 inch x 0.85 inch x 0.062 inch; pad layout as shown on Diodes Inc. suggested pad layout document AP02001,

which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.

2. No purposefully added lead.

3. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.

4. Product manufactured with Date Code 0627 (week 27, 2006) and newer are built with Green Molding Compound. Product manufactured prior to

Code 0627 are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.

DS30165 Rev. 9 - 2

1 of 3

www.diodes.com

MMSTA13/MMSTA14
