DMN2400UFB4-7B datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> DMN2400UFB4-7B

DMN2400UFB4-7B: Description750 mA, 20 V, N-CHANNEL, Si, SMALL SIGNAL, MOSFET; Categorysemiconductor Discrete semiconductor; File Size316KB，7 Pages; ManufacturerDiodes; Websitehttp://www.diodes.com/

Download Datasheet Parametric Compare View All

DMN2400UFB4-7B Overview

750 mA, 20 V, N-CHANNEL, Si, SMALL SIGNAL, MOSFET

DMN2400UFB4-7B Parametric

Parameter Name	Attribute value
Number of terminals	3
Minimum breakdown voltage	20 V
Processing package description	GREEN, ULTRA SMALL, PLASTIC, DFN1006H4-3, 3 PIN
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
packaging shape	Rectangle
Package Size	ChipCARRIER
surface mount	Yes
Terminal form	NO
terminal coating	Nickel Palladium
Terminal location	BOTTOM
Packaging Materials	Plastic/Epoxy
structure	Single WITH BUILT-IN diode
Shell connection	DRAIN
Number of components	1
transistor applications	switch
Transistor component materials	silicon
Channel type	N channel
field effect transistor technology	Metal-OXIDE SEMICONDUCTOR
operating mode	ENHANCEMENT
Transistor type	Universal small signal
Maximum leakage current	0.7500 A
Maximum drain on-resistance	0.5500 ohm

Preview

Download Datasheet

View All

DMN2400UFB4

20V N-CHANNEL ENHANCEMENT MODE MOSFET

Features



Low On-Resistance

Low Gate Threshold Voltage

Low Input Capacitance

Fast Switching Speed

Low Input/Output Leakage

UItra-Small Surface Mount Package

Ultra-Low Package Profile, 0.4mm Maximum Package Height

ESD Protected up to 1.5kV

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 standards for High Reliability

Mechanical Data



Case: X2-DFN1006-3

Case Material: Molded Plastic, "Green" Molding Compound;

UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Finish



NiPdAu over Copper Leadframe; Solderable

per MIL-STD-202, Method 208

Weight: 0.001 grams (Approximate)

D r a in

X2-DFN1006-3

ESD PROTECTED TO 1.5kV

G a te

BOTTOM VIEW

TOP VIEW

Package Pin Configuration

G a te

P ro te c tio n

D io d e

S o u rce

E Q U IV A L E N T C IR C U I T

Ordering Information

(Note 4)

Part Number

DMN2400UFB4-7

DMN2400UFB4-7B

Notes:

Marking

Reel size (inches)

Tape width (mm)

Quantity per reel

3,000

10,000

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.

DMN2400UFB4

Document number: DS32025 Rev. 6 - 2

1 of 7

www.diodes.com

May 2015
