MMBD4148PLM
FIVE ELEMENT COMMON CATHODE SWITCHING DIODE ARRAY
Please click here to visit our online spice models database.
Features
•
•
•
•
•
•
Low Forward Voltage Drop
Fast Switching
Very High Density (Five Diode Elements in a Sub-Miniature
Package)
Lead Free/RoHS Compliant (Note 1)
"Green" Device (Note 2)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
•
•
•
•
•
•
•
•
•
DFN1616-6
NEW PRODUCT
Case: DFN1616-6
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020D
Terminals: Solderable per MIL-STD-202, Method 208
Lead Free Plating (NiPdAu Finish over Copper leadframe).
Polarity: Pin 1 Dot and Center Pad notch, See diagram
Marking Information: See Page 2
Ordering Information: See Page 2
Weight: 0.004 grams (approximate)
N/A
BOTTOM VIEW
TOP VIEW
Internal Schematic
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Symbol
V
RM
V
RRM
V
RWM
V
R
V
R(RMS)
I
FM
I
O
@ t = 1.0μs
@ t = 1.0s
I
FSM
Value
100
75
53
300
200
2.0
1.0
Unit
V
V
V
mA
mA
A
Characteristic
Non-Repetitive Peak Reverse Voltage
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current
Average Rectified Output Current
Non-Repetitive Peak Forward Surge Current
Thermal Characteristics
Characteristic
Power Dissipation (Note 3)
Thermal Resistance Junction to Ambient Air (Note 3)
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
T
J
, T
STG
Value
500
256
-65 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
Characteristic
Reverse Breakdown Voltage (Note 4)
Forward Voltage
@T
A
= 25°C unless otherwise specified
Symbol
V
(BR)R
V
F
Min
75
⎯
Max
⎯
0.715
0.855
1.0
1.25
1.0
50
30
25
2.0
4.0
Unit
V
V
μA
μA
μA
nA
pF
ns
Test Condition
I
R
= 100μA
I
F
= 1.0mA
I
F
= 10mA
I
F
= 50mA
I
F
= 150mA
V
R
= 75V
V
R
= 75V, T
J
= 150°C
V
R
= 25V, T
J
= 150°C
V
R
= 20V
V
R
= 0, f = 1.0MHz
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100Ω
Leakage Current (Note 4)
Total Capacitance
Reverse Recovery Time
Notes:
1.
2.
3.
I
R
C
T
t
rr
⎯
⎯
⎯
No Purposefully added Lead.
Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
Only one switching diode powered on.
4. Short duration pulse test used to minimize self-heating effect.
MMBD4148PLM
Document number: DS31437 Rev. 6 - 2
1 of 3
www.diodes.com
September 2008
© Diodes Incorporated
MMBD4148PLM
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
500
R
θJA
= 256°C/W
1
P
D
, POWER DISSIPATION (mW)
400
0.1
300
NEW PRODUCT
200
0.01
100
0
0
0.001
0
500
1,000
1,500
V
F
, INSTANTANEOUS FORWARD VOLTAGE (mV)
Fig. 2 Typical Forward Characteristics
2.0
1.8
100
200
T
A
, AMBIENT TEMPERATURE, (°C)
Fig. 1 Power Derating Curve
I
R
, INSTANTANEOUS REVERSE CURRENT (nA)
100,000
C
T
, TOTAL CAPACITANCE (pF)
10,000
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
1,000
100
10
1
0
0
10 20 30 40 50 60 70 80 90 100
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 3 Typical Reverse Characteristics
0
0
25
50
75
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Capacitance vs. Reverse Voltage
Ordering Information
Part Number
MMBD4148PLM-7
Notes:
(Note 5)
Case
DFN1616-6
Packaging
3000/Tape & Reel
5. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
AP6 = Product Type Marking Code
YM = Date Code Marking
Y = Year ex: V = 2008
M = Month ex: 9 = September
AP6 YM
Date Code Key
Year
Code
Month
Code
2008
V
Jan
1
Feb
2
2009
W
Mar
3
2010
X
Apr
4
May
5
2011
Y
Jun
6
2012
Z
Jul
7
Aug
8
2013
A
Sep
9
2014
B
Oct
O
Nov
N
2015
C
Dec
D
MMBD4148PLM
Document number: DS31437 Rev. 6 - 2
2 of 3
www.diodes.com
September 2008
© Diodes Incorporated
MMBD4148PLM
Package Outline Dimensions
A
A3
A1
D
e
NEW PRODUCT
E E2
L
b
D2
DFN1616-6
Dim Min
Max
Typ
A
0.545 0.605 0.575
A1
0
0.05 0.02
A3
0.13
⎯
⎯
b
0.20 0.30 0.25
D
1.55 1.675 1.60
D2
1.10 1.30 1.20
E
1.55 1.675 1.60
e
0.50
⎯
⎯
E2
0.30 0.50 0.40
L
0.275 0.375 0.325
All Dimensions in mm
Suggested Pad Layout
Y
C
X2
G
X1
Dimensions
Z
G
X1
X2
Y
C
Value (in mm)
1.3
0.175
0.50
0.525
0.30
0.50
Z
