Naina Semiconductor Ltd.
Thyristor-Diode Module, 70 Amps
Features
•
•
•
•
Improved glass passivation for high reliability
Exceptional stability at high temperatures
High di/dt and dv/dt capabilities
Low thermal resistance
NTD72A
Voltage Ratings
(T
A
= 25
o
C, unless otherwise noted)
Type
number
Voltage
Code
V
RRM,
Maximum
repetitive peak
reverse voltage
(V)
60
80
100
120
140
160
180
600
800
1000
1200
1400
1600
1800
V
RSM,
Maximum non-
repetitive peak reverse
voltage
(V)
700
900
1100
1300
1500
1700
1900
V
DRM,
Maximum
repetitive peak off-
state voltage
(V)
600
800
1000
1200
1400
1600
1800
I
RRM,
Maximum
reverse leakage
current @ T
JMAX
(mA)
NTD72A
8
Electrical Characteristics
(T
A
= 25
0
C unless otherwise noted)
Parameter
Maximum average forward current @ T
J
= 85
0
C
Maximum average RMS forward current
Maximum non-repetitive surge current
Maximum I
2
t for fusing
Forward voltage drop
Critical rate of rise of on-state current
Critical rate of rise of off-state voltage
Gate current required to trigger
Gate voltage required to trigger
Maximum holding current
Maximum latching current
Isolation voltage
Symbol
I
T(AV)
I
T(RMS)
I
TSM
I
2
t
V
TM
di/dt
dv/dt
I
GT
V
GT
I
H
I
L
V
ISO
Values
70
110
1600
12800
1.25
150
1000
150
3
150
300
3000
Units
A
A
A
A
2
s
V
A/µs
V/µs
mA
V
mA
mA
V
Thermal & Mechanical Specifications
(T
A
= 25
0
C unless otherwise noted)
Parameter
Operating junction temperature range
Storage temperature
Thermal resistance, junction to case
to heatsink
Mounting torque
to terminals
Weight
Symbol
T
J
T
stg
R
th(JC)
F
W
Values
-40 to +125
-40 to +125
0.35
4 ± 15%
3 ± 15%
100
Units
0
C
0
C
0
C/W
Nm
g
1
D-95, Sector 63, Noida – 201301, India • Tel: 0120-4205450 • Fax: 0120-4273653
sales@nainasemi.com • www.nainasemi.com
Naina Semiconductor Ltd.
Package Outline
(All dimensions in mm)
NTD72A
Circuit Configuration
Circuit Description
Configuration Code
Circuit Drawing
Series Connection (doubler circuit)
N
Common Anode
A
2
D-95, Sector 63, Noida – 201301, India • Tel: 0120-4205450 • Fax: 0120-4273653
sales@nainasemi.com • www.nainasemi.com
Naina Semiconductor Ltd.
Ordering Table
NTD
1
72
2
A
3
N
4
160
5
NTD72A
1 – Power Module
>
DD = Diode-Diode
>
TD = Thyristor-Diode
>
TT = Thyristor-Thyristor
2 – Current Rating =
I
T(AV)
3 – Package Type
4 – Circuit Configuration (see Table)
5 – Voltage Code (see Voltage Ratings table)
3
D-95, Sector 63, Noida – 201301, India • Tel: 0120-4205450 • Fax: 0120-4273653
sales@nainasemi.com • www.nainasemi.com
