BAS85
Taiwan Semiconductor
Small Signal Product
CREAT BY ART
Hermetically Sealed Glass Fast Switching Schottky Barrier Diodes
FEATURES
- Low forward voltage drop
- Ideal for automated placement
- Hermetically sealed glass
- Compression bonded construction
- All external surfaces are corrosion
resistant and leads are readily solderable
- Solder hot dip tin (Sn) lead finish
MINI MELF
MECHANICAL DATA
- Polarity: Indicated by black cathode band
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25℃ unless otherwise noted)
PARAMETER
SYMBOL
P
D
V
RRM
V
R
I
F(AV)
I
FSM
T
J
T
STG
SYMBOL
I
R
=10μA
V
R
=25V
I
F
=0.1mA
I
F
=1.0mA
I
F
=10mA
I
F
=30mA
I
F
=100mA
Reverse Recovery Time
(Note 1)
t
rr
5
10
V
R
=1V, f=1.0MHz
C
J
Junction Capacitance
Note 1: Reverse recovery test conditions : I
F
=I
R
=10mA, R
L
=100Ω, I
RR
=1mA
V
F
B
V
I
R
MIN
30
2
0.24
0.32
0.40
0.50
0.80
ns
pF
V
VALUE
200
30
30
200
4
125
-65 to +125
TYP
MAX
UNIT
mW
V
V
mA
A
o
o
Power Dissipation
Repetitive Peak Reverse Voltage
Maximum DC Blocking Voltage
Average Forward Rectified Current
Peak Forward Surge Current
Operating Junction Temperature
Storage Temperature Range
PARAMETER
Breakdown Voltage
Reverse Leakage Current
Forward Voltage
C
C
UNIT
V
μA
Document Number: DS_S1412007
Version: C14
BAS85
Taiwan Semiconductor
Small Signal Product
ORDERING INFORMATION
PART NO.
PART NO.
SUFFIX
(Note 1)
BAS85
-xx
PACKING CODE
L0
L1
PACKING CODE
SUFFIX
G
PACKAGE
MINI MELF
PACKING
10K / 13" Reel
2.5K / 7" Reel
Note 1: Part No. Suffix „-xx “ would be used for special requirement
EXAMPLE
PREFERRED P/N
PART NO.
PART NO.
SUFFIX
PACKING CODE
PACKING CODE
SUFFIX
G
DESCRIPTION
Multiple manufacture
source
Halogen free
Define manufacture
source
Halogen free
BAS85 L0G
BAS85
L0
BAS85-L0 L0G
BAS85
-L0
L0
G
PACKAGE OUTLINE DIMENSION
C
DIM.
A
B
B
Unit (mm)
Min
3.30
1.40
0.20
Max
3.70
1.60
0.50
Unit (inch)
Min
0.130
0.055
0.008
Max
0.146
0.063
0.020
C
A
SUGGEST PAD LAYOUT
Unit (mm)
Typ.
1.25
2.00
2.50
5.00
Unit (inch)
Typ.
0.049
0.079
0.098
0.197
DIM.
A
B
C
D
Document Number: DS_S1412007
Version: C14
BAS85
Taiwan Semiconductor
Small Signal Product
Notice
Specifications of the products displayed herein are subject to change without notice. TSC or anyone on its behalf,
assumes no responsibility or liability for any errors or inaccuracies.
Information contained herein is intended to provide a product description only. No license, express or implied,to
any intellectual property rights is granted by this document. Except as provided in TSC's terms and conditions of
sale for such products, TSC assumes no liability whatsoever, and disclaims any express or implied warranty,
relating to sale and/or use of TSC products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright, or other intellectual property right.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications.
Customers using or seling these products for use in such applications do so at their own risk and agree to fully
indemnify TSC for any damages resulting from such improper use or sale.
Document Number: DS_S1412007
Version: C14
