Capacitive proximity sensors
Capacitive proximity sensors
dimension drawing
M30 x 1,5
CFAK 30N1100
58
SW 36
LED
general data
nominal sensing distance Sn
mounting type
GND electrode
temperature drift
sensitivity adjustment
output indicator
electrical data
voltage supply range +Vs
current consumption max. (no load)
output circuit
output current
voltage drop Vd
switching frequency
short circuit protection
reverse polarity protection
mechanical data
type
housing material
dimension
housing length
connection types
cylindrical threaded
PBT
30 mm
72 mm
cable, 2 m
10 ... 30 VDC
20 mA
NPN make function (NO)
< 200 mA
< 1,5 VDC
< 50 Hz
yes
yes
8 mm
non-flush
no
± 15 % (0 ... +70 °C)
no
LED yellow
72
connection diagram
BN (1)
+V
S
Z
NPN
BK (4)
BU (3)
output
0V
ambient conditions
operating temperature
protection class
field of application
detection of non-conductive media
fill level detection through container
liquids in direct contact
object detection / bulk goods
yes
yes
yes
yes
-25 ... +75 °C
IP 67/65 (sensing face/sensor)
CFAK 30N1100
www.baumer.com
8/1/2014
