Xeon 3 Power Warm White LED
OSM5XZE3C1E
VER C.2
■Features
●
■
Outline
Dimension
Highest Luminous Flux
Super Energy Efficiency
Long Lifetime Operation
Superior ESD protection
1.15
●
●
Anode(+)
3.6
●
●
Superior UV Resistance
2.0
■
Caution
●
Cathode(-)
Avoid Reflow Soldering Process
BackView
3.0
5.0
■Applications
●
Anode
5.5
0.1
Cathode
ESD Protection Diode
Unit:mm
Tolerance:±0.30mm
Read lights (car, bus, aircraft)
Portable (flashlight, bicycle)
Bollards / Security / Garden
Traffic signaling / Beacons
In door / Out door Commercial lights
Automotive Ext
●
14.5
●
●
●
■Absolute
Maximum Rating
Item
DC Forward Current
Pulse Forward Current*
Reverse Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Lead Soldering Temperature
*Pulse width Max.10ms
(Ta=25℃)
Symbol
I
F
I
FP
V
R
P
D
Topr
Tstg
Tsol
0.2
■
Directivity
Value
800
1000
5
3200
-30 ~ +85
-40~ +100
260
℃
/5sec
Unit
mA
mA
V
mW
1.05
●
0
℃
℃
-
0
Duty ratio max 1/10
■Electrical
-Optical Characteristics
Item
DC Forward Voltage
DC Reverse Current
Luminous Flux
Color Temperature
Chromaticity
Coordinates*
50% Power Angle
(Ta=25℃)
Min.
3.0
3.5
-
190
-
-
-
-
■
Forward Operating Current (DC)
Unit
V
Forward Current, I
F
(mA)
800
700
600
500
400
300
200
100
0
0
25
50
75
100
125
R
J-A
=30
℃
/W
R
J-A
=25
℃
/W
R
J-A
=20
℃
/W
R
J-A
=15
℃
/W
Symbol
V
F
I
R
Φv
CCT
x
y
2θ
1/2
Condition
I
F
=350mA
I
F
=700mA
V
R
=5V
I
F
=700mA
I
F
=700mA
I
F
=700mA
I
F
=700mA
I
F
=700mA
Typ.
3.3
3.8
-
210
3000
0.44
0.41
120
Max.
4.0
4.5
10
-
-
-
-
-
V
µA
lm
K
-
-
deg
Ambient Temperature, T
A
(
℃
)
Note: Don’t drive at rated current more than 5s without heat sink for Xeon 3 emitter series.
