1000Base-T Module
ELECTRONICS INC.
EPG4000SLH
• Guaranteed to operate with 100 Base-X
• Complies with or exceeds IEEE 802.3ab 1000Base-T
• 1500 Vrms Isolation
Electrical Parameters @ 25° C
OCL
(µH Min.)
@ 8 mA DC bias
@ 100 KHz,
0.1 Vrms
350 (Media Side)
1-65
MHz
-1
Insertion
Loss
(dB Max.)
65-100
MHz
-1.1
100-125
MHz
-1.5
1-40
MHZ
-18
Return
Loss
(dB Min.)
60
MHZ
-15
80
MHZ
-12
100
MHz
-10
CMRR
(dB Min.)
1-80
MHz
-30
1
MHZ
-60
Common to
Differential
(dB Min.)
30
MHZ
-40
50
MHZ
-35
100
MHz
-30
1-40
MHZ
-40
Cross talk
(dB Min.)
60
MHZ
-35
100
MHz
-30
• Rise Time :
1.75 nS Max.
• Impedance :
100
Ω
•
Schematic
1, 4, 7, 10
2, 5, 8, 11
1CT:1CT
24, 21, 18, 15
23, 20, 17, 14
3, 6, 9, 12
22, 19, 16, 13
Package
.720
(18.29)
.085
(2.16)
PCA
EPG4000SLH
.480
Date Code
(12.45)
.050
(1.27)
Pad
Layout
.090
(2.29)
.670
(17.02)
Pin 1
I.D.
.550
(24.13
.200
(5.08)
.010/.015
(.254/3.81)
0°-8°
.030
(.762)
.008/.013
(.203/.304)
.035
(.889)
.016/.022
(.406/.559)
.050
(1.27)
.600
(12.24)
Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25
PCA ELECTRONICS, INC.
16799 SCHOENBORN ST.
NORTH HILLS, CA 91343
Product performance is limited to specified parameters. Data is subject to change without prior notice.
CSG4000SLH
Rev. 1
9/4/02
TEL: (818) 892-0761
FAX: (818) 894-5791
http://www.pca.com
