Finisar
Product Specification
2 Gb/s RoHS Compliant Long-Wavelength Pluggable SFP Transceiver
FTLF1419P1xCL
PRODUCT FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
Up to 2.125Gb/s bi-directional
data links
Hot-pluggable SFP footprint
Built-in digital diagnostic functions
Uncooled 1310nm DFB laser
transmitter
Duplex LC connector
RoHS compliant and Lead Free
No Rate Select input required for
Fibre Channel 1x/2x Operation
Up to 55 km on 9/125μm SMF
Metal enclosure, for lower EMI
Single 3.3V power supply
Low power dissipation <700mW
typical
Extended operating temperature
range: -10°C to 70°C
APPLICATIONS
•
•
1.25Gb/s 1000Base-LX Ethernet
Dual Rate 1.06 / 2.125 Gb/s Fibre
Channel
Finisar’s FTLF1419P1xCL Small Form Factor Pluggable (SFP) transceivers are
compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA)
1
.
They simultaneously comply with Gigabit Ethernet as specified in IEEE Std 802.3
2
, and
1x and 2x Fibre Channel as defined in FC-PI 13.0
3,4
. They are RoHS compliant and lead-
free per Directive 2002/95/EC
5
and Finisar Application Note AN-2038. Digital
diagnostics functions are available via the 2-wire serial bus specified in the SFP MSA.
PRODUCT SELECTION
FTLF1419P1xCL
x
W
B
Wide Extraction Bail
Narrow Extraction Bail
Page 1
©
Finisar Corporation November 4, 2005 Rev. A
FTLF1419P1xCL Pluggable SFP Product Specification – November 2005
Finisar
I.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Pin Descriptions
Symbol
V
EET
T
FAULT
T
DIS
MOD_DEF(2)
MOD_DEF(1)
MOD_DEF(0)
Rate Select
LOS
V
EER
V
EER
V
EER
RD-
RD+
V
EER
V
CCR
V
CCT
V
EET
TD+
TD-
V
EET
Name/Description
Transmitter Ground (Common with Receiver Ground)
Transmitter Fault. Not supported.
Transmitter Disable. Laser output disabled on high or open.
Module Definition 2. Data line for Serial ID.
Module Definition 1. Clock line for Serial ID.
Module Definition 0. Grounded within the module.
No connection required
Loss of Signal indication. Logic 0 indicates normal operation.
Receiver Ground (Common with Transmitter Ground)
Receiver Ground (Common with Transmitter Ground)
Receiver Ground (Common with Transmitter Ground)
Receiver Inverted DATA out. AC Coupled
Receiver Non-inverted DATA out. AC Coupled
Receiver Ground (Common with Transmitter Ground)
Receiver Power Supply
Transmitter Power Supply
Transmitter Ground (Common with Receiver Ground)
Transmitter Non-Inverted DATA in. AC Coupled.
Transmitter Inverted DATA in. AC Coupled.
Transmitter Ground (Common with Receiver Ground)
Ref.
1
2
3
3
3
4
5
1
1
1
1
1
1
Notes:
1. Circuit ground is internally isolated from chassis ground.
2. Laser output disabled on T
DIS
>2.0V or open, enabled on T
DIS
<0.8V.
3. Should be pulled up with 4.7k - 10 kohms on host board to a voltage between 2.0V and 3.6V.
MOD_DEF(0) pulls line low to indicate module is plugged in.
4. Finisar FTLFxx21xxxxx transceivers operate between OC-3 and OC-48, 1x and 2x Fibre Channel, and
Gigabit Ethernet data rates and respective protocols without active control. Finisar FTLFxx19xxxxx
transceivers operate at 1x and 2x Fibre Channel, and Gigabit Ethernet data rates and respective
protocols without active control.
5. LOS is open collector output. Should be pulled up with 4.7k – 10 kohms on host board to a voltage
between 2.0V and 3.6V. Logic 0 indicates normal operation; logic 1 indicates loss of signal.
VeeT
1
2
3
4
VeeT
TD-
TXFault
TD+
TX Disable
VeeT
MOD-DEF(2)
VccT
20
19
18
17
16
15
14
13
12
11
Towards
Bezel
5
6
7
8
9
10
MOD-DEF(1)
VccR
MOD-DEF(0)
VeeR
Rate Select
RD+
LOS
RD-
VeeR
VeeR
VeeR
Towards
ASIC
Pinout of Connector Block on Host Board
©
Finisar Corporation November 4, 2005 Rev. A
Page 2
FTLF1419P1xCL Pluggable SFP Product Specification – November 2005
Finisar
II.
Absolute Maximum Ratings
Parameter
Maximum Supply Voltage
Storage Temperature
Case Operating Temperature
Relative Humidity
Symbol
Vcc
T
S
T
OP
RH
Min
-0.5
-40
-10
0
Typ
Max
4.5
85
70
85
Unit
V
°C
°C
%
Ref.
1
III.
Electrical Characteristics
(T
OP
= -10 to 70
°C,
V
CC
= 3.00 to 3.60 Volts)
Symbol
Vcc
Icc
R
in
Vin,pp
V
D
V
EN
Min
3.00
Typ
200
100
250
Vcc – 1.3
Vee
1200
Vcc
Vee+ 0.8
10
400
100
100
800
175
175
Vcc
HOST
Vee+0.5
51.7
122.4
Max
3.60
300
Unit
V
mA
Ω
mV
V
V
us
mV
ps
ps
V
V
mVpp
ps
ps
Ref.
Parameter
Supply Voltage
Supply Current
Transmitter
Input differential impedance
Single ended data input swing
Transmit Disable Voltage
Transmit Enable Voltage
Transmit Disable Assert Time
Receiver
Single ended data output swing
Data output rise time
Data output fall time
LOS Fault
LOS Normal
Power Supply Rejection
Deterministic Jitter Contribution
Total Jitter Contribution
2
3
Vout,pp
t
r
t
f
V
LOS fault
V
LOS norm
PSR
RX
Δ
DJ
RX
Δ
TJ
300
Vcc – 0.5
Vee
100
4
5
5
6
6
7
8
Notes:
1. Non condensing.
2. Connected directly to TX data input pins. AC coupled thereafter.
3. Or open circuit.
4. Into 100 ohm differential termination.
5. 20 – 80 %
6. LOS is LVTTL. Logic 0 indicates normal operation; logic 1 indicates no signal detected.
7. Receiver sensitivity is compliant with power supply sinusoidal modulation of 20 Hz to 1.5 MHz up to
specified value applied through the recommended power supply filtering network.
8. Measured with DJ-free data input signal. In actual application, output DJ will be the sum of input DJ
and
Δ
DJ.
©
Finisar Corporation November 4, 2005 Rev. A
Page 3
FTLF1419P1xCL Pluggable SFP Product Specification – November 2005
Finisar
IV.
Optical Characteristics (T
OP
= -10 to 70
°
C, V
CC
= 3.00 to 3.60 Volts)
Symbol
P
OUT
λ
σ
OMA
SSR
t
r
/ t
f
RIN
ER
TX
Δ
DJ
TX
Δ
TJ
R
SENS1
R
SENS2
R
SENS1
P
MAX
λ
C
LOS
D
LOS
A
0
1270
12
-30
0.5
-23
-25
1500
1600
-19
Min
0
1275
174
30
160
-120
9
56.5
119
-21
-22
-22
Typ
Max
5
1350
1
Unit
dBm
nm
nm
μW
dB
ps
dB/Hz
dB
ps
ps
dBm
dBm
dBm
dBm
MHz
nm
dB
dBm
dBm
dB
Ref.
1
2
2
2,3
4
Parameter
Transmitter
Output Opt. Power
Optical Wavelength
Spectral Width (-20dB)
Optical Modulation Amplitude
Sidemode Supression Ratio
Optical Rise/Fall Time
Relative Intensity Noise
Optical Extinction Ratio
Deterministic Jitter Contribution
Total Jitter Contribution
Receiver
Average Rx Sensitivity @ 2.125
Gb/s (2X Fibre Channel)
Average Rx Sensitivity @ 1.25 Gb/s
(Gigabit Ethernet)
Average Rx Sensitivity @ 1.06 Gb/s
(1X Fibre Channel)
Maximum Input Power
Receiver Elec. 3 dB cutoff freq.
Optical Center Wavelength
Return Loss
LOS De-Assert
LOS Assert
LOS Hysteresis
5
6, 7
6, 7
6, 7
Notes:
1. Class 1 Laser Safety per FDA/CDRH and EN (IEC) 60825 regulations.
2. Meets curves in FC-PI 13.0 Figures 18 and 19, which allow trade-off between wavelength, spectral
width and OMA.
3. Equivalent extinction ratio specification for Fibre Channel. Allows smaller ER at higher average
power.
4. Unfiltered, 20-80%. Complies with FC 1x and 2x eye mask when filtered.
5. Measured with DJ-free data input signal. In actual application, output DJ will be the sum of input DJ
and
Δ
DJ.
6. Measured with conformance signals defined in FC-PI 13.0 specifications.
7. As measured with 9dB extinction ratio. Measured with a PRBS 2
7
-1 test pattern.
©
Finisar Corporation November 4, 2005 Rev. A
Page 4
FTLF1419P1xCL Pluggable SFP Product Specification – November 2005
Finisar
V.
General Specifications
Parameter
Symbol
BR
BER
L
MAX1
L
MAX2
Min
1062
Typ
Max
2125
10
-12
Units
Ref.
Mb/sec 1
2
km
3, 4
km
3, 4
Data Rate
Bit Error Rate
Max. Supported Link Length on
9/125μm SMF @ 2X Fibre Channel
Max. Supported Link Length on
9/125μm SMF @ Gigabit Ethernet
52.5
55
Notes:
1. Gigabit Ethernet and 1x/2x Fibre Channel compliant.
2. Tested with a PRBS 2
7
-1 test pattern.
3. Dispersion limited per FC-PI Rev. 13
4. Attenuation of 0.40 dB/km is used for the link length calculations. Distances are indicative only.
Please refer to the Optical Specifications in Table IV to calculate a more accurate link budget based on
specific conditions in your application.
VI.
Environmental Specifications
Finisar 1310nm SFP transceivers have an extended operating temperature range from
–10°C to +70°C case temperature.
Parameter
Case Operating Temperature
Storage Temperature
Symbol
T
op
T
sto
Min
-10
-40
Typ
Max
70
85
Units
°C
°C
Ref.
VII.
Regulatory Compliance
Finisar transceivers are Class 1 Laser Products and comply with US FDA regulations.
These products are certified by TÜV and CSA to meet the Class 1 eye safety
requirements of EN (IEC) 60825 and the electrical safety requirements of
EN (IEC) 60950. Copies of certificates are available at Finisar Corporation upon request.
©
Finisar Corporation November 4, 2005 Rev. A
Page 5
