SHEET 1 OF 1
5.08
[.200 in]
2.54
[.100 in]
n
1.09
[.043 in]
5.08
[.200 in]
8.13
[.320 in]
P.C. MOUNTING
n
6.00
[.236 in]
4.39
[.173 in] FLAT
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
2.54
ON
2-3
NONE
OPEN
ON
2-1
n
[.100 in]
POS. 1
25
~
POS. 3
ISOMETRIC
12.30
[.484 in]
2
5.59
[.220 in]
.51
[.020 in]
4.01
[.158 in]
5.08
[.200 in]
1
3
CIRCUIT: SPDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: GOLD
5. RATING: 0.4VOLT-AMPS MAX. @20V MAX. AC OR DC
6. ELECTRIC LIFE: 30,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30°C to 85°C
10.
DENOTES CRITICAL PARAMETER.
1
2
3
3.30
[.130 in]
5.08
[.200 in]
2.54
[.100 in]
.76
[.030 in]
A
REV
15517
PCR NO
RELEASED FOR PRODUCTION
DESCRIPTION
11/17/04
DATE
AR
BY
TITLE
SCALE
200MSP1T4B2M7RE
2:1
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
11/17/04
AR
T211104
A
