SHEET 1 OF 1
5.08
[.200 in]
5.08
[.200 in]
5.08
[.200 in]
.76
[.030 in]
5.08
[.200 in]
1
2.54
[.100 in]
2
3
n
1.09
[.043 in]
P.C. MOUNTING
8.13
[.320 in]
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
n
6.00
[.236 in]
ISOMETRIC
ON
2-3
OFF
OPEN
ON
POS. 1
2-1
25
~
POS. 2
POS. 3
n
[.100 in]
2.54
(ON)=MOMENTARY
5.59
[.220 in]
2
9.00
[.354 in]
10-48 UNS-2A
THREADS
4.01
[.158 in]
1
3
CIRCUIT: SPDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: GOLD
5. RATING: 0.4VA @ 20VAC OR VDC MAX.
6. ELECTRIC LIFE: 30,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 M
Ω
MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30°C to 85°C
10.
DENOTES CRITICAL PARAMETER.
11. 2002/95/EC (ROHS) COMPLIANT
B
A
REV
20596
15886
PCR NO
CHG ETCHED TEXT WAS "E"
RELEASED FOR PRODUCTION
DESCRIPTION
05/08/12
3/22/06
DATE
.41
[.016 in]
1
2
3
EPOXY SEAL
.51
[.020 in]
.51
[.020 in]
3.30
[.130 in]
5.08
[.200 in]
2.54
[.100 in]
.76
[.030 in]
drg
PH
BY
TITLE
200MSP3T1B1M6RE
DATE
DR
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
2:1
DWG
REV
3/22/2006
PH
T205003
B
