Datasheet> All Categories > Discrete semiconductor> The transistor> L4N60I

L4N60I: DescriptionPower Field-Effect Transistor, N-Channel, Metal-oxide Semiconductor FET,; CategoryDiscrete semiconductor The transistor; File Size324KB，9 Pages; ManufacturerLRC; Websitehttp://www.lrc.cn; Environmental Compliance

Download Datasheet Parametric Compare View All

L4N60I Overview

Power Field-Effect Transistor, N-Channel, Metal-oxide Semiconductor FET,

L4N60I Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1293792430
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Configuration	Single
Maximum drain current (Abs) (ID)	4 A
FET technology	METAL-OXIDE SEMICONDUCTOR
Maximum operating temperature	150 °C
Polarity/channel type	N-CHANNEL
Maximum power dissipation(Abs)	77 W
surface mount	NO

Preview

Download Datasheet

View All

LESHAN RADIO COMPANY, LTD.

4 Amps, 600 Volts

N-CHANNEL POWER MOSFET

L4N60

DESCRIPTION

The LRC L4N60 is a high voltage MOSFET and is designed to

have better characteristics, such as fast switching time, low gate

charge, low on-state resistance and have a high rugged avalanche

characteristics. This power MOSFET is usually used at high speed

switching applications in power supplies, PWM motor controls, high

efficient DC to DC converters and bridge circuits.

FEATURES

* R

DS(ON)

= 2.5

Ohms

= 10 V

* Ultra low gate charge

* Low reverse transfer Capacitance

* Fast switching capability

* Avalanche energy Specified

* Improved dv/dt capability, high ruggedness

ORDERING INFORMATION

Pin Assignment

Order Number

L4N60P

L4N60F

L4N60I

L4N60D

Package

TO-220

TO-220F

TO-251

TO-252

Packing

Tube

Rev .O 1/9

L4N60I Related Products

	L4N60I	L4N60D
Description	Power Field-Effect Transistor, N-Channel, Metal-oxide Semiconductor FET,	Power Field-Effect Transistor, N-Channel, Metal-oxide Semiconductor FET,
Is it Rohs certified?	conform to	conform to
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
Configuration	Single	Single
Maximum drain current (Abs) (ID)	4 A	4 A
FET technology	METAL-OXIDE SEMICONDUCTOR	METAL-OXIDE SEMICONDUCTOR
Maximum operating temperature	150 °C	150 °C
Polarity/channel type	N-CHANNEL	N-CHANNEL
Maximum power dissipation(Abs)	77 W	77 W
surface mount	NO	YES
