Radial Bobbin Inductors
Dimensions:
Inches
(mm)
RB2200R
A:
B:
C:
D:
E:
F:
G:
0.283±0.020
0.335±0.020
0.413 MAX
1.614±0.130
1.772±0.130
0.024±0.002
0.118±0.020
Features
Allied
Part
Number
Inductance
(
µh)
DCR
Max.
(Ω)
SRF
(MHz)
Nom.
Q at f KHZ Nom
Q
f
DC Current
(A)
Max.
RB2200R-100K-RC
RB2200R-150K-RC
RB2200R-220K-RC
RB2200R-330K-RC
RB2200R-470K-RC
RB2200R-680K-RC
RB2200R-101K-RC
RB2200R-151K-RC
RB2200R-221K-RC
RB2200R-331K-RC
RB2200R-471K-RC
RB2200R-681K-RC
RB2200R-102K-RC
RB2200R-152K-RC
RB2200R-222K-RC
RB2200R-332K-RC
RB2200R-472K-RC
RB2200R-682K-RC
RB2200R-103K-RC
RB2200R-153K-RC
RB2200R-223K-RC
RB2200R-333K-RC
RB2200R-473K-RC
RB2200R-683K-RC
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
10000
15000
22000
33000
47000
68000
0.05
0.07
0.09
0.14
0.22
0.28
0.39
0.54
0.83
1.21
1.65
2.64
3.63
6.49
8.58
11.0
15.0
22.0
37.4
51.7
82.5
118.8
169.4
242.0
21.2
19.4
17.0
11.4
10.9
8.7
7.0
5.7
4.4
3.7
3.2
2.5
2.1
1.9
1.7
1.2
1.0
0.85
0.62
0.51
0.34
0.28
0.25
0.20
65
60
50
50
50
90
90
90
100
100
110
120
120
130
90
140
150
145
155
140
100
95
90
70
1000
500
500
500
500
100
100
100
100
100
100
100
100
100
50
150
150
150
150
150
50
50
50
50
1.62
1.35
1.08
0.90
0.77
0.77
0.67
0.52
0.43
0.38
0.31
0.25
0.17
0.13
0.11
0.10
0.081
0.072
0.063
0.054
0.045
0.036
0.027
0.018
•
•
•
•
Small Foot print
Radial Leaded
Extensive Inductance Range
UL Polyolefin Tubing
Electrical
Inductance Range:
-10µh ~ 68,000µh
Tolerance:
10% over entire range.
Tighter tolerances available.
Test Frequency:
1KHz, 0.1V
Operating Temperature:
-25ºC to +70ºC
DC Current:
Based on Inductance change
by no more than 10% of initial value and
Temperature rise of no more than 30ºC of
initial temperature within the coil body.
Under no circumstances should the
temperature of the part increase to more
than 125ºC.
Test Equipment
Inductance:
HP4263B 1KHz-0.1V
DCR:
HP4263B 1KHz-0.1V
Current:
CH-301 Current Source & DCR
DCR:
HP4263B 1KHz-0.1V
Q:
HP4342A Q meter
All specifications subject to change without notice.
Physical
Packaging:
500 pcs per bag
Marking:
EIA Inductance code and
“F” RoHS Indentifier
