Radial Leaded RF Inductors
Dimensions:
(mm)
RB855
A:
B:
C:
D:
E:
7.8±0.5
5.5 Max
5.0 ± 1.0
5.0±0.3
0.7±0.1-0.05
Features
Allied
Part
Number
Inductance
(
µh)
Tolerance
Test Freq
DCR
(Ohms)
Max
Rated
Current
(mA)
RB855-100M-RC
RB855-120M-RC
RB855-150M-RC
RB855-180M-RC
RB855-220K-RC
RB855-270K-RC
RB855-330K-RC
RB855-390K-RC
RB855-470K-RC
RB855-560K-RC
RB855-680K-RC
RB855-820K-RC
RB855-101K-RC
RB855-121K-RC
RB855-151K-RC
RB855-181K-RC
RB855-221K-RC
RB855-271K-RC
RB855-331K-RC
RB855-391K-RC
RB855-471K-RC
RB855-561K-RC
RB855-681K-RC
RB855-821K-RC
RB855-102K-RC
RB855-122K-RC
RB855-152K-RC
RB855-182K-RC
RB855-222K-RC
RB855-272K-RC
RB855-332K-RC
RB855-392K-RC
RB855-472K-RC
RB855-562K-RC
RB855-682K-RC
RB855-822K-RC
RB855-103K-RC
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
20%
20%
20%
20%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52MHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
0.07
0.08
0.09
0.10
0.12
0.14
0.17
0.21
0.24
0.31
0.34
0.40
0.52
0.59
0.71
0.89
1.04
1.28
1.47
1.67
1.95
2.83
3.25
3.82
5.28
6.03
7.15
8.26
11.1
13.1
15.9
18.0
23.9
26.8
31.7
46.5
55.7
2500
2400
2100
2000
1700
1600
1400
1300
1200
1100
1000
930
810
760
670
620
540
490
440
410
380
350
320
310
250
230
210
200
180
160
140
130
120
110
98
88
81
•
•
•
For R.F and other applications
Extensive Inductance Range
Tighter tolerance available
Electrical
Inductance Range:
-10µh ~ 10,000µh
Tolerance:
10% over entire range.
Tighter tolerances available.
Test Frequency:
As shown
Operating Temperature:
-55ºC to +125ºC
DC Current:
Based on Inductance change
by no more than 10% of initial value and
Temperature rise of no more than 30ºC of
initial temperature within the coil body.
Under no circumstances should the
temperature of the part increase to more
than 125ºC.
Test Equipment
Inductance:
CH-100 / HP4342A
DCR:
CH-301 Current Source & DCR Meter
Current:
CH-301 Current Source & DCR
Physical
Packaging:
50 per bag
Marking:
EIA Inductance code
All specifications subject to change without notice.
949-356-1780
ALLIED COMPONENTS INTERNATIONAL
07/03/2014
www.alliedcomponents.com
