IDT74LVCH162245A
3.3V CMOS 16-BIT BUS TRANSCEIVER WITH 5V TOLERANT I/O
INDUSTRIAL TEMPERATURE RANGE
3.3V CMOS 16-BIT
BUS TRANSCEIVER
WITH 5 VOLT TOLERANT I/O
AND BUS-HOLD
• Typical t
SK(o)
(Output Skew) < 250ps
• ESD > 2000V per MIL-STD-883, Method 3015; > 200V using
machine model (C = 200pF, R = 0)
• V
CC
= 3.3V ± 0.3V, Normal Range
• V
CC
= 2.7V to 3.6V, Extended Range
• CMOS power levels (0.4µ W typ. static)
µ
• All inputs, outputs, and I/O are 5V tolerant
• Available in SSOP, TSSOP, and TVSOP packages
IDT74LVCH162245A
FEATURES:
DESCRIPTION:
DRIVE FEATURES:
APPLICATIONS:
• Balanced Output Drivers: ±12mA (A port)
• High Output Drivers: ±24mA (B port)
• 5V and 3.3V mixed voltage systems
• Data communication and telecommunication systems
This 16-bit bus transceiver is built using advanced dual metal CMOS
technology. This high-speed, low power transceiver is ideal for asynchro-
nous communication between two busses (A and B). The Direction and
Output Enable controls are designed to operate this device as either two
independent 8-bit transceivers or one 16-bit transceiver. The direction
control pin (DIR) controls the direction of data flow. The output enable pin
(OE) overrides the direction control and disables both ports. All inputs are
designed with hysteresis for improved noise margin.
All pins can be driven from either 3.3V or 5V devices. This feature allows
the use of this device as a translator in a mixed 3.3V/5V supply system.
The LVCH162245A (B port) has been designed with a ±24mA output
driver. This driver is capable of driving a moderate to heavy load while
maintaining speed performance.
The LVCH162245 (A port) has series resistors in the device output
structure which will significantly reduce line noise when used with light loads.
The driver has been designed to drive ±12mA at the designated threshold
levels.
The LVCH162245A has “bus-hold” which retains the inputs’ last state
whenever the input goes to a high impedance. This prevents floating inputs
and eliminates the need for pull-up/down resistors.
FUNCTIONAL BLOCK DIAGRAM
1
DIR
1
48
24
2
DIR
25
1
OE
1
A
1
47
2
46
2
OE
2
A
1
36
13
35
1
B
1
2
A
2
2
B
1
1
A
2
3
1
B
2
1
A
3
44
5
43
6
33
14
2
B
2
2
A
3
16
1
B
3
32
2
B
3
2
A
4
17
1
A
4
1
B
4
1
A
5
41
8
2
B
4
2
A
5
30
19
1
B
5
1
A
6
40
9
2
B
5
2
A
6
1
B
6
29
20
27
22
2
B
6
1
A
7
38
11
2
A
7
1
B
7
2
B
7
2
A
8
26
23
1
A
8
37
12
1
B
8
2
B
8
The IDT logo is a registered trademark of Integrated Device Technology, Inc.
INDUSTRIAL TEMPERATURE RANGE
1
© 1999 Integrated Device Technology, Inc.
MARCH 1999
DSC-4597/1
IDT74LVCH162245A
3.3V CMOS 16-BIT BUS TRANSCEIVER WITH 5V TOLERANT I/O
INDUSTRIAL TEMPERATURE RANGE
PIN CONFIGURATION
ABSOLUTE MAXIMUM RATINGS
(1)
Symbol
Description
Max
V
TERM
Terminal Voltage with Respect to GND
Storage Temperature
DC Output Current
Continuous Clamp Current,
V
I
< 0 or V
O
< 0
Continuous Current through each
V
CC
or GND
–0.5 to +6.5
–65 to +150
–50 to +50
–50
±100
T
STG
I
OUT
I
IK
I
OK
I
CC
I
SS
Unit
V
°C
mA
mA
mA
1
DIR
1
B
1
1
B
2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
1
OE
1
A
1
1
A
2
GND
1
B
3
1
B
4
GND
1
A
3
1
A
4
V
CC
1
B
5
1
B
6
V
CC
1
A
5
1
A
6
NOTE:
1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause
permanent damage to the device. This is a stress rating only and functional operation
of the device at these or any other conditions above those indicated in the operational
sections of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods may affect reliability.
GND
1
B
7
1
B
8
2
B
1
2
B
2
GND
1
A
7
1
A
8
2
A
1
2
A
2
CAPACITANCE
(T
A
= +25°C, F = 1.0MHz)
Symbol
C
IN
C
OUT
C
I/O
Parameter
(1)
Input Capacitance
Output Capacitance
I/O Port Capacitance
Conditions
V
IN
= 0V
V
OUT
= 0V
V
IN
= 0V
Typ.
4.5
6.5
6.5
Max.
6
8
8
Unit
pF
pF
pF
NOTE:
1. As applicable to the device type.
GND
2
B
3
2
B
4
GND
2
A
3
2
A
4
PIN DESCRIPTION
Pin Names
xOE
xDIR
xAx
xBx
Description
Output Enable Input (Active LOW)
Direction Control Output
Side A Inputs or 3-State Outputs
(1)
Side B Inputs or 3-State Outputs
(1)
V
CC
2
B
5
2
B
6
V
CC
2
A
5
2
A
6
GND
2
B
7
2
B
8
2
DIR
GND
2
A
7
2
A8
2
OE
NOTE:
1. These pins have "Bus-Hold". All other pins are standard inputs, outputs, or I/Os.
FUNCTION TABLE
(EACH 8-BIT SECTION)
(1)
Inputs
xOE
xDIR
L
H
X
Outputs
B Data to A Bus
A Data to B Bus
High Z State
SSOP/ TSSOP/ TVSOP
TOP VIEW
L
L
H
NOTE:
1. H = HIGH Voltage Level
X = Don’t Care
L = LOW Voltage Level
Z = High-Impedance
2
IDT74LVCH162245A
3.3V CMOS 16-BIT BUS TRANSCEIVER WITH 5V TOLERANT I/O
INDUSTRIAL TEMPERATURE RANGE
DC ELECTRICAL CHARACTERISTICS OVER OPERATING RANGE
Following Conditions Apply Unless Otherwise Specified:
Operating Condition: T
A
= –40°C to +85°C
Symbol
V
IH
V
IL
I
IH
I
IL
I
OZH
I
OZL
I
OFF
V
IK
V
H
I
CCL
I
CCH
I
CCZ
∆I
CC
High Impedance Output Current
(3-State Output pins)
Input/Output Power Off Leakage
Clamp Diode Voltage
Input Hysteresis
Quiescent Power Supply Current
V
CC
= 0V, V
IN
or V
O
≤
5.5V
V
CC
= 2.3V, I
IN
= –18mA
V
CC
= 3.3V
V
CC
= 3.6V
V
IN
= GND or V
CC
—
—
—
—
—
—
—
–0.7
100
—
—
—
±50
–1.2
—
10
10
500
µA
V
mV
µA
V
CC
= 3.6V
V
O
= 0 to 5.5V
—
—
±10
µA
Parameter
Input HIGH Voltage Level
Input LOW Voltage Level
Input Leakage Current
V
CC
= 2.3V to 2.7V
V
CC
= 2.7V to 3.6V
V
CC
= 2.3V to 2.7V
V
CC
= 2.7V to 3.6V
V
CC
= 3.6V
V
I
= 0 to 5.5V
Test Conditions
Min.
1.7
2
—
—
—
Typ.
(1)
—
—
—
—
—
Max.
—
—
0.7
0.8
±5
µA
V
Unit
V
Quiescent Power Supply Current
Variation
3.6
≤
V
IN
≤
5.5V
(2)
One input at V
CC
- 0.6V, other inputs at V
CC
or GND
µA
NOTES:
1. Typical values are at V
CC
= 3.3V, +25°C ambient.
2. This applies in the disabled state only.
BUS-HOLD CHARACTERISTICS
Symbol
I
BHH
I
BHL
I
BHH
I
BHL
I
BHHO
I
BHLO
NOTES:
1. Pins with Bus-Hold are identified in the pin description.
2. Typical values are at V
CC
= 3.3V, +25°C ambient.
Parameter
(1)
Bus-Hold Input Sustain Current
Bus-Hold Input Sustain Current
Bus-Hold Input Overdrive Current
V
CC
= 3V
V
CC
= 2.3V
V
CC
= 3.6V
Test Conditions
V
I
= 2V
V
I
= 0.8V
V
I
= 1.7V
V
I
= 0.7V
V
I
= 0 to 3.6V
Min.
– 75
75
—
—
—
Typ.
(2)
—
—
—
—
—
Max.
—
—
—
—
±500
Unit
µA
µA
µA
3
IDT74LVCH162245A
3.3V CMOS 16-BIT BUS TRANSCEIVER WITH 5V TOLERANT I/O
INDUSTRIAL TEMPERATURE RANGE
OUTPUT DRIVE CHARACTERISTICS (A PORT)
Symbol
V
OH
Parameter
Output HIGH Voltage
V
CC
= 2.3V
V
CC
= 2.7V
V
CC
= 3V
V
OL
Output LOW Voltage
V
CC
= 2.3V to 3.6V
V
CC
= 2.3V
V
CC
= 2.7V
V
CC
= 3V
Test Conditions
(1)
V
CC
= 2.3V to 3.6V
I
OH
= – 0.1mA
I
OH
= – 4mA
I
OH
= – 6mA
I
OH
= – 4mA
I
OH
= – 8mA
I
OH
= – 6mA
I
OH
= – 12mA
I
OL
= 0.1mA
I
OL
= 4mA
I
OL
= 6mA
I
OL
= 4mA
I
OL
= 8mA
I
OL
= 6mA
I
OL
= 12mA
Min.
V
CC
– 0.2
1.9
1.7
2.2
2
2.4
2
—
—
—
—
—
—
—
Max.
—
—
—
—
—
—
—
0.2
0.4
0.55
0.4
0.6
0.55
0.8
V
Unit
V
NOTE:
1. V
IH
and V
IL
must be within the min. or max. range shown in the DC ELECTRICAL CHARACTERISTICS OVER OPERATING RANGE table for the appropriate V
CC
range.
T
A
= – 40°C to + 85°C.
OUTPUT DRIVE CHARACTERISTICS (B PORT)
Symbol
V
OH
Parameter
Output HIGH Voltage
V
CC
= 2.3V
V
CC
= 2.3V
V
CC
= 2.7V
V
CC
= 3V
V
CC
= 3V
V
OL
Output LOW Voltage
V
CC
= 2.3V to 3.6V
V
CC
= 2.3V
V
CC
= 2.7V
V
CC
= 3V
I
OH
= – 24mA
I
OL
= 0.1mA
I
OL
= 6mA
I
OL
= 12mA
I
OL
= 12mA
I
OL
= 24mA
Test Conditions
(1)
V
CC
= 2.3V to 3.6V
I
OH
= – 0.1mA
I
OH
= – 6mA
I
OH
= – 12mA
Min.
V
CC
– 0.2
2
1.7
2.2
2.4
2
—
—
—
—
—
Max.
—
—
—
—
—
—
0.2
0.4
0.7
0.4
0.55
V
Unit
V
NOTE:
1. V
IH
and V
IL
must be within the min. or max. range shown in the DC ELECTRICAL CHARACTERISTICS OVER OPERATING RANGE table for the appropriate V
CC
range.
T
A
= – 40°C to + 85°C.
4
IDT74LVCH162245A
3.3V CMOS 16-BIT BUS TRANSCEIVER WITH 5V TOLERANT I/O
INDUSTRIAL TEMPERATURE RANGE
OPERATING CHARACTERISTICS, V
CC
= 3.3V ± 0.3V, T
A
= 25°C
Symbol
C
PD
C
PD
Parameter
Power Dissipation Capacitance per Transceiver Outputs enabled
Power Dissipation Capacitance per Transceiver Outputs disabled
Test Conditions
C
L
= 0pF, f = 10Mhz
Typical
39
4
Unit
pF
SWITCHING CHARACTERISTICS (A PORT)
(1)
Symbol
t
PLH
t
PHL
t
PZH
t
PZL
t
PHZ
t
PLZ
t
SK
(o)
Parameter
Propagation Delay
xBx to xAx
Output Enable Time
xOE to xAx
Output Disable Time
xOE to xAx
Output Skew
(2)
V
CC
= 2.7V
Min.
Max.
1.5
5.7
1.5
1.5
7.9
8.3
V
CC
= 3.3V ± 0.3V
Min.
Max.
1.5
4.8
1.5
2.2
6.3
7.4
500
Unit
ns
ns
ns
ps
—
—
—
NOTES:
1. See TEST CIRCUITS AND WAVEFORMS. T
A
= – 40°C to + 85°C.
2. Skew between any two outputs of the same package and switching in the same direction.
SWITCHING CHARACTERISTICS (B PORT)
(1)
Symbol
t
PLH
t
PHL
t
PZH
t
PZL
t
PHZ
t
PLZ
t
SK
(o)
Parameter
Propagation Delay
xAx to xBx
Output Enable Time
xOE to xBx
Output Disable Time
xOE to xBx
Output Skew
(2)
V
CC
= 2.7V
Min.
Max.
1.5
4.7
1.5
1.5
6.7
7.1
V
CC
= 3.3V ± 0.3V
Min.
Max.
1
4
1.5
1.5
5.5
6.6
500
Unit
ns
ns
ns
ps
—
—
—
NOTES:
1. See TEST CIRCUITS AND WAVEFORMS. T
A
= – 40°C to + 85°C.
2. Skew between any two outputs of the same package and switching in the same direction.
5
京公网安备 11010802033920号
EEWORLD
