SHEET 1 OF 1
1.20
[.047 in]
[.787 in]
n
20.00
n
23.00
[.906 in]
21.40
[.843 in]
4.20
[.165 in]
ACTUATOR COLOR
BLACK
20.20
[.795 in]
PANEL MOUNTING
3
1
SWITCH FUNCTION
POS. 1
2
CURCUIT: SPDT
ON
2, 3
NONE
NONE
ON
2, 1
14.60
[.575 in]
NOTE:
1. DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X =
±
0.4
X.XX =
±
0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT MATERIAL: SILVER
5. CONTACT RATING: 16A @ 125VAC (UL, cUL)
10A @ 250VAC (UL, cUL)
1/3HP 125/250VAC (UL,cUL)
10(4)A 250VAC, 1E4 T125/55 (VDE)
6. CONTACT RESISTANCE: 35mΩ MAX. @ 50VAC
7. INSULATION RESISTANCE: 1000MΩ MIN. @ 500VAC
8. DIELECTRIC STRENGTH: 1,500VAC FOR 1 MINUTE
9. ELECTRICAL LIFE: 6,000 CYCLES [UR, cUR, NOM]
10,000 CYCLES [ENEC14, SEMKO]
10. OPERATING TEMPERATURE: -20°C TO 105°C [UR, cUR, NOM]
-20°C TO 125°C [ENEC14, SEMKO]
11. DENOTES CRITICAL PARAMETER
12. 2002/95/EC (ROHS) COMPLIANT
A
REV
20562
PCR NO
New Release
DESCRIPTION
22.80
[.898 in]
POS. 2
POS. 3
2.00
[.079 in]
Pos 1
5.80
[.228 in]
HOUSING COLOR
BLACK
Pos 2
8.20
[.323 in]
1
2
3
7.10
[.280 in]
.80
[.031 in]
4.80
[.189 in]
2
[.083 in]
n
2.10
14.20
[.559 in]
19.80
[.780 in]
21.20
[.835 in]
4/25/12
DATE
rc
BY
TITLE
SCALE
RRG383C1100
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
4/25/2012
38-RRG383C1100
A
