All specifications are based on 25°C, Nominal Input Voltage, and Maximum Output Current unless otherwise noted.
We reserve the right to change specifications based on technological advances.
SPECIFICATION
REMOTE ON/OFF
(See Note 4)
Positive Logic (standard)
Negative Logic (optional)
Input Current of Remote Control Pin
Remote OFF State Input Current
ENVIRONMENTAL SPECIFICATIONS
Operating Ambient Temperature
Maximum Case Temperature
Storage Temperature
Thermal Impedance (See Note 6)
Relative Humidity
Thermal Shock
Vibration
MTBF
PHYSICAL SPECIFICATIONS
Weight
Dimensions (L x W x H)
Case Material
Base Material
Potting Material
Shielding
SAFETY & EMC CHARACTERISTICS
Safety Approvals
EMI (See Note 3)
ESD
Radiated Immunity
Fast Transient (See Note 2)
Surge (See Note 2)
Conducted Immunity
EN55022
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
Natural Convection
With derating
TEST CONDITIONS
The CTRL pin is referenced to –Input pin
The CTRL pin is referenced to –Input pin
Nominal Vin
Nominal Vin
DC/DC ON
DC/DC OFF
DC/DC ON
DC/DC OFF
Min
Typ
Max
Unit
Open or 3V < Vr < 15 VDC
Short or 0V < Vr < 1.2 VDC
Short or 0V <Vr < 1.2 VDC
Open or 3V < Vr < 15 VDC
-0.5
2.5
-40
-55
+85
+105
+125
16.18
15.13
5
95
MIL-STD-810F
MIL-STD-810F
1.0
mA
mA
°C
°C
°C
°C/W
% RH
Without Heatsink
With Heatsink
MIL-HDBK-217F Ta=25°C, full load
3,308,000 hours
0.58oz (16.5g)
1.00x1.00x0.39 inch (25.4x25.4x9.9 mm)
Copper
FR4 PCB
Silicon (UL94-V0)
Six-sided
UL60950-1, IEC60950-1, EN60950-1
Class A, Class B
Air ±8kV
Contact ±6kV
10 V/m
±2kV
±1kV
3 Vrms
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
NOTES
1. Trimming allows the user to increase or decrease the output voltage set point of the module. This is accomplished by connecting an external resistor
between the Trim pin and either the +Vout pin or the –Vout pin.
2. An external input filter capacitor is required if the module has to meet EN61000-4-4, EN61000-4-5. The filter capacitor suggested is Nippon chemi-con KY
series, 220µF/100V.
3. The JFC10 series standard modules meet EN55022 Class A without external components and meet Class B with external components. For more details
please call factory.
4. Both positive logic and negative logic remote on/off control is available. Positive logic remote on/off comes standard; for negative logic remote on/off add
the suffix “R” to the model number (Ex: JFC24S05-10R).
5. There are several different options available for this series. Please see the “Model Number Setup” on page 5 for all options and ordering information.
6. Optional heatsink is available. Please call factory for more information.
CAUTION:
This power module is not internally fused. An input line fuse must always be used.
