SHEET 1 OF 1
4
PUSH
1
2
3
CIRCUIT DIAGRAM
5
6
R05 BUTTON
TRANSPARENT
(B410000)
9.00
[.354 in]
n
10.00
[.394 in]
20.10
[.791 in]
10.60
[.417 in]
23.20
[.913 in]
13.20
[.520 in]
5.00
[.197 in]
5.70
[.224 in]
9.10
[.358 in]
2.50
[.098 in]
2.54
[.100 in]
+
4
5
6
n
.90
[.035 in]
8 PLS
4
.50
[.020 in]
3.00
[.118 in]
- PIN
1
.50
[.020 in]
3.70
[.146 in]
-
1
2
3
.60
[.024 in]
2.50
[.098 in]
WBL2UEERBQ
(B400011)
3.70
[.146 in]
3.70
[.146 in]
-
1
2
3
8.00
[.315 in]
PCB LAYOUT
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
-
2. GENERAL TOLERANCE: x.x=
`
0.4mm
RED
LED
x.xx=
`
0.25mm
+
3. RATING: DC 30V, 0.3A
4. OPERATING FORCE: 200
`
100gf
5. TRAVEL: FULL: 3.3mm, LOCK: 2.5mm
6. LIFE CYCLES: 10,000 CYCLES
7. OPERATING TEMPERATURE: -20
~
C TO 70
~
C
8. CONTACT RESISTANCE: 20m
W
MAX.
9. INSULATION RESISTANCE: 100M
W
MIN@ 500VDC.
10. LED COLOR: RED/BLUE
11. DENOTES CRITICAL PARAMETER.
12. 2002/95/EC (RoHS) COMPLIANT.
+
BLUE
LED
1
3
-
4
6
2.54
[.100 in]
3.00
[1.18]
+ PIN
LED SPECS
FORWARD CURRENT
FORWARD VOLTAGE @20mA
LUMINOUS INTENSITY @ 20mA
UNITS
mA
V
MCD
RED
20
1.95 Typ-2.5 Max
400 TYP
BLUE
20
3.3 Typ-4 Max
60 TYP
A
REV
20616
PCR NO
INITIAL RELEASE
DESCRIPTION
05/22/12
DATE
drg
BY
TITLE
WBL2UEERBQR05CLR
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
5/22/2012
DR
DWG
REV
drg
XB0933P
A
