SHEET 1 OF 1
4.70
[.185 in]
n
1.85
[.073 in]
9.27
[.365 in]
ISOMETRIC
P.C. MOUNTING
16.87
[.664 in]
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
13.49
[.531 in]
POS. 1
25
~
POS. 3
ON
2-3
NONE
OPEN
ON
2-1
7.87
[.310 in]
B
1.65
[.065 in]
ACTUATOR COLOR:
BLACK
2
1
3
10.42
[.410 in]
CIRCUIT: SPDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: GOLD
5. RATING: 0.4 VOLT-AMPS MAX. @20V MAX. AC OR DC
6. ELECTRIC LIFE: 30,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30°C to 85°C
10.
DENOTES CRITICAL PARAMETER.
EPOXY SEAL
1
.76
[.030 in]
4.70
[.185 in]
12.70
[.500 in]
6.60
[.260 in]
2
3
1.27
[.050 in]
3
B
5.40
[.213 in]
B
A
REV
19236
14614
PCR NO
REVISE 2 DIMENSIONS
RELEASED FOR PRODUCTION
DESCRIPTION
8/5/10
1/12/05
DATE
BLR
AR
BY
TITLE
300AWSP1J1BLKM2RE
DATE
DR
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
2:1
DWG
REV
8/5/2010
BLR
T301014
B
