SHEET 1 OF 1
5.08
[.200 in]
5.08
[.200 in]
n
1.09
(4)
[.043 in]
8.13
[.320 in]
.76
[.030 in]
n
6.10
[.240 in]
P.C. MOUNTING
FLAT
SWITCH FUNCTION
POS. 1
POS. 2
3
5.08
[.200 in]
4.39
[.173 in]
1
OFF
OPEN
(ON)
1-3
3.53
[.139 in]
5.59
[.220 in]
4.01
[.158 in]
.41
[.016 in]
CIRCUIT: SPST
(ON)=MOMENTARY
10-48 UNS-2A
THREADS
E-LOGO ON
OPPOSITE SIDE
1
3
3
3.30
[.130 in]
5.08
[.200 in]
SWITCH
RATING
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT MATERIAL: SILVER
5. RATING: 1A @ 250 VAC
3A @ 120 VAC OR 28 VDC
6. MECHANICAL LIFE: 50,000 MAKE-AND-BREAK CYCLES
7. CONTACT RESISTANCE: 20 mΩ MAX. INITIAL @ 2-4VDC
100mA FOR BOTH GOLD AND SILVER CONTACTS
8. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
9. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
10. OPERATING TEMP.: -30°C to 85°C
11.
DENOTES CRITICAL PARAMETER.
12. 2002/95/EC (ROHS) COMPLIANT
.51
[.020 in]
.76
[.030 in]
5.08
[.200 in]
B
REV
20003
PCR NO
UPDATED AND REDRAWN
DESCRIPTION
06/16/11
DATE
BMA
BY
TITLE
SCALE
800SP9B5M6QEH
2:1
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
6/16/2011
BMA
ST811021
B
