FIXED INPUT,ISOLATED®ULATED Dual Output DC/DC Converter
SELECTION GUIDE
Input
Order code
Voltage(VDC)
2E-XSR
Series
Output
Range
Voltage
(VDC)
Current(MA)
Max
Min
Nominal
Efficiency
(%,Typ)
Switching
Frequency
(KHz,Typ)
2E0505XSR
2E0509XSR
5
5
5
5
12
12
12
12
24
24
24
24
4.75-5.25
4.75-5.25
4.75-5.25
4.75-5.25
11.4-12.6
11.4-12.6
11.4-12.6
11.4-12.6
22.8-25.2
22.8-25.2
22.8-25.2
22.8-25.2
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±200
±112
±83
±67
±200
±112
±83
±67
±200
±112
±83
±67
±20
±11
±8
±7
±20
±11
±8
±7
±20
±11
±8
±7
70
61
62
64
75
61
65
64
78
69
63
74
85
83
83
250
120
83
83
83
83
83
83
300
FEATURES
◆
◆
◆
◆
2E0512XSR
2E0515XSR
2E1205XSR
2E1209XSR
2E1212XSR
2E1215XSR
2E2405XSR
2E2409XSR
2E2412XSR
2E2415XSR
RoHS compliant
Efficiency up to 83%
SIP Package
Wide temperature performance at full 2 Watt
load,-40°C to 85°C
◆
◆
◆
◆
◆
◆
◆
◆
UL 94V-0 package material
No heatsink required
Low ripple and good EMC Features
Industry standard pinout
Power sharing on output
3KVDC isolation
Continuous Short Circuit Protection
Internal SMD construction
No external components required
NOTICE:add Suffix “P” for Continuous Short Circuit Protection, e.g. IE0505XSP
ISOLATION SPECIFICATIONS
Parameter
Isolation test voltage
Isolation resistance
Test conditions
Flash tested for 1 minute and 1mA max
Test at Viso=500VDC
Min.
3000
1000
Typ.
Max.
Units
VDC
MΩ
◆
◆
Good dynamic feature
MODEL SELECTION
2E 05 05 X S R
①Product
Series
③Output
Voltage
⑤SIP10
Package
①
②
③
④
⑤
⑥
②Input
Voltage
④Fixed
Input
⑥Regulated
output
APPLICATIONS
The 2IE-XSR series are specially designed for
applications where a group of polar power
supplies are isolated from the input power
supply in a distributed power supply system on
a circuit board.
These products apply to:
1) where the voltage of the input power supply
is fixed (voltage variation ≤±5%);
2) where isolation is necessary between input
and output (isolation voltage ≤3000VDC);
3) where the regulation of the output voltage
and the output ripple noise are demanded.
OUTPUT SPECIFICATIONS
Parameter
Output power
Line regulation
Load regulation
Output voltage accuracy
Temperature drift
Output Ripple*
Output Noise*
Switching frequency
For Vin change of ±5%
10% to 100% full load
100% full load
100% full load
20MHz Bandwidth
20MHz Bandwidth
Full load,nominal input
20
50
100
Test conditions
Min
0.2
Typ.
Max.
2
±0.5
±1.5
±3
0.03
30
150
Units
W
%
%
%
%/°C
MV p-p
MV p-p
Khz
* Test ripple and noise by "parallel cable" method.
See detailed operation instructions at Testing of Power Converter section, application notes.
MICRODC R ESERVES THE COPYRIGHT
http://www.microdc.cn
Technical Enquiries-Email:tech@microdc.cn Tel:0086-20-86000646
Page 1 of 2
2E-XSR
Series
TEMPERATURE CHARACTERISTICS
Parameter
Storage humidity range
Operating temperature
Storage temperature
Lead temperature
Temp.rise at full load
Cooling
Case material
Short circuit protection
MTBF
Weight
IE-XSP
1.5mm from case for 10 seconds
-40
-55
40
Filtering
Typ.
Max.
95
85
125
58
300
Free air convection
Plastic(UL94-V0)
Continuous
1
*
S
K hours
5.2
g
Conditions
Min.
Units
%
°C
°C
°C
°C
To get an extreme low ripple,an"LC"filtering network
may be connected to the input and output ends of the
DC/DC converter.Which may produce a more significant
filtering effect.It should also be noted that the inductance
and the frequency of the "LC"filtering network should be
staggered with the DC/DC frequency to avoid mutual
interference see (Figure 1).
3500
*Supply voltage must be discontinued at the end of short circuit duration.
TYPICAL CHARACTERISTICS
Temperature Derating Graph
In some circuits which are sensitive to noise and ripple.a
filtering capacitor may be added to the DC/DC output
end and input end to reduce the noise and ripple.
However, the capacitance of the output filter capacitor
must be proper. If the capacitance is too big, a startup
problem might arise. For every channel of output,
provided the safe and reliable operation is ensured,
the greatest capacitance of its filter capacitor sees
(Table 1).
EXTERNAL CAPACITOR TABLE (TABLE 1)
Cin
Vout
Vin
(VDC)
5
12
24
(μF)
4.7
2.2
0.47
(VDC)
±5
±9
±12
Cout
(μF)
4.7
2.2
1.0
OUTLINE DIMENSIONS & PIN CONNECTIONS
SIZE Graph
RECOMMENDED FOOTPRINT
Top view,grid:2.54mm(0.1inch)
diameter:1.00mm(0.039inch)
It's not recommend to connect any external capacitor in
the application field with less than 0.5 watt output.
Overload Protection
Under normal operating conditions , the output circuit of
these products has no protection against over-current
and short-circuits.The simplest method is to connect a
self-recovery fuse in series at the input end or add a
circuit breaker to the circuit.
FOOTPRINT DETAILS
Pin
1
2
7
Note:
Unit:mm(inch)
Pin section:0.50*0.3mm(0.020*0.012inch)
Pin section tolerances:±0.10mm(±0.004inch)
General tolerances:±0.25mm(±0.010inch)
9
10
Function
VIN
GND
+V0
-V0
0V
When the environment temperature is higher than
71℃, the product output power should be less then
60% of the rated power.
No parallel connection or plug and play.
Use dual output simultaneously, forbid opening
Output pin (0V) to use as single output.
All specifications typical at TA=25°C, nominal input voltage and rated output current unless otherwise
specified.Another 24V products, please inquire Our technical department!
Requirement on output load
To ensure this module can operate efficiently and reliably, a minimum load is specified for this kind of
DC/DC converter in addition to a maximum load(namely full load).During operation, make sure the
specified range of input voltage is not exceeded,the minimum output load is
not less than 10%
of the full
load, and that this product should never be operated under no load!
RoHS COMPLIANT INFORMATION
This series is compatible with RoHS soldering systems with a peak wave solder temperature
of 300°C for 10 seconds.
The pin termination finish on the SIP package type is Tin Plate, Hot Dipped over Matte Tin
with Nickel Preplate. The DIP types are Matte Tin over Nickel Preplate. Both types in this
series are backward compatible with Sn/Pb soldering systems.
REACH COMPLIANT INFORMATION
This series has proven that this product does not contain harmful chemicals, it also has
harmful chemical substances through the registration, inspection and approval.
Microdc Professional Power Module,Inc.
Tel:0086-20-86000646
E-mail:tech@microdc.cn
Website:http://www.microdc.cn
