74HC05
HEX INVERTERS WITH OPEN DRAIN OUTPUTS
Description
The 74HC05 provides provides six independent inverters with open
drain outputs.
The device is designed for operation with a power
supply range of 2.0V to 6.0V.
The gates perform the Boolean function:
Pin Assignments
Y
=
A
NEW PRODUCT
Features
•
•
•
•
•
Wide Supply Voltage Range from 2.0V to 6.0V
Sinks 4mA at V
CC
= 4.5V
CMOS Low Power Consumption
Schmitt Trigger Action at All Inputs
ESD Protection Exceeds JESD 22
200-V Machine Model (A115-A)
2000-V Human Body Model (A114-A)
Exceeds 1000-V Charged Device Model (C101C)
•
•
•
Range of Package Options SO-14 and TSSOP-14
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Applications
•
•
General Purpose Logic
Wide array of products such as:
PCs, Networking, Notebooks, Netbooks
Computer Peripherals, Hard Drives, CD/DVD ROM
TV, DVD, DVR, Set Top Box
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
74HC05
Document number: DS35321 Rev. 3 - 2
1 of 7
www.diodes.com
January 2013
© Diodes Incorporated
74HC05
Pin Descriptions
Pin
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Pin Name
1A
1Y
2A
2Y
3A
3Y
GND
4Y
4A
5Y
5A
6Y
6A
V
CC
Function
Data Input
Data Output
Data Input
Data Output
Data Input
Data Output
Ground
Data Output
Data Input
Data Output
Data Input
Data Output
Data Input
Supply Voltage
NEW PRODUCT
Logic Diagram
Function Table
Input
A
H
L
Output
Y
L
Z
74HC05
Document number: DS35321 Rev. 3 - 2
2 of 7
www.diodes.com
January 2013
© Diodes Incorporated
74HC05
Absolute Maximum Ratings
(Note 4) (@T
A
= +25°C, unless otherwise specified.)
Symbol
ESD HBM
ESD CDM
ESD MM
V
CC
V
I
Description
Human Body Model ESD Protection
Charged Device Model ESD Protection
Machine Model ESD Protection
Supply Voltage Range
Input Voltage Range (Note 5)
Input Clamp Current
Output Clamp Current
V
I
< -0.5V or Vi > V
CC
+ 0.5V
V
O
< -0.5V or V
O
> V
CC
+ 0.5V
Rating
2
1
200
-0.5 to +7.0
-0.5 to +7.0
±20
±20
+/- 25
50
-50
-40 to +150
-65 to +150
500
Unit
KV
KV
V
V
V
mA
mA
mA
mA
mA
°C
°C
mW
NEW PRODUCT
I
IK
I
OK
I
O
I
CC
I
GND
T
J
T
STG
P
TOT
Notes:
Continuous Output Current - 0.5V < V
O
V
CC
+ 0.5V
Continuous Current Through V
CC
Continuous Current Through GND
Operating Junction Temperature
Storage Temperature
Total Power Dissipation
4. Stresses beyond the absolute maximum may result in immediate failure or reduced reliability. These are stress values and device operation should
be within recommend values.
5. Input Voltage cannot exceed V
CC
to the extent the Maximum clamp current is exceeded
Recommended Operating Conditions
(Note 6) (@T
A
= +25°C, unless otherwise specified.)
Symbol
V
CC
V
I
V
O
Δt/ΔV
T
A
Note:
Parameter
Supply Voltage
Input Voltage
Output Voltage
Conditions
Min
2.0
0
0
Max
6.0
Vcc
V
CC
625
140
85
Unit
V
V
V
ns/V
°C
V
CC
= 2.0V
Input transition rise or fall rate
Operating free-air temperature
V
CC
= 4.5V
V
CC
= 6.0V
-40
6. Unused inputs should be held at V
CC
or Ground.
+125
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol
Parameter
High-level Input
Voltage
Low-level input
voltage
I
OL
= 20μA
V
OL
Low-level Output
Voltage
I
OL
= 20μA
I
OL
= 20μA
I
OL
= 4mA
I
OL
= 5.2mA
I
OZ
I
I
I
CC
Z State
Leakage Current
Input Current
Supply Current
V
O
=0 to 6.0V
V
I
=GND or 6.0V
V
I
=GND to 5.5V
V
I
= GND or V
CC
,
I
O
=0
Test Conditions
V
CC
2.0V
4.5V
6.0V
2.0V
4.5V
6.0V
2.0V
4.5V
6.0V
4.5V
6.0V
6.0V
6.0V
6.0V
3 of 7
www.diodes.com
T
A
= -40°C to +85°C
Min
1.5
3.15
4.2
Max
T
A
= -40°C to +125°C
Min
1.5
3.15
4.2
Max
Unit
V
IH
V
0.5
1.35
1.8
0.1
0.1
0.1
0.44
0.44
± 10
±1
40
μA
μA
μA
January 2013
© Diodes Incorporated
V
IL
0.5
1.35
1.8
0.1
0.1
0.1
0.33
0.33
± 5.0
±1
20
V
V
74HC05
Document number: DS35321 Rev. 3 - 2
74HC05
Switching Characteristics
Symbol
Parameter
Propagation
Delay A
N
to Y
N
Test
Conditions
Figure 1
C
L
= 50 pF
Figure 1
C
L
= 50 pF
V
CC
2.0V
4.5V
6.0V
2.0V
4.5V
6.0V
T
A
= +25°C
Min
—
—
—
—
—
—
Typ
25
9
7
19
7
6
Max
90
18
15
75
15
13
-40°C to +85°C
Max
115
23
20
95
19
16
-40°C to +125°C
Max
125
27
23
110
22
19
Unit
t
PD
ns
t
t
Transition time
ns
NEW PRODUCT
Operating Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Parameter
C
pd
C
I
Power dissipation
capacitance per gate
Input Capacitance
Test Conditions
f = 1 MHz
V
I
= V
CC
– or GND
V
CC
= 6V
Typ
22
4
Unit
pF
pF
Parameter Measurement Information
TEST
t
PLZ
(see Notes D and E)
t
PZL
(see Notes D and F)
Condition
Vload
Vload
V
CC
2.0V to 6.0V
Inputs
V
I
V
CC
t
r
/t
f
≤6ns
V
M
V
CC
/2
V
LOAD
2 X V
CC
C
L
50 pF
R
L
2 KΩ
V∆
10% of Vcc
Voltage Waveform
Pulse Duration
Voltage Waveform
Propagation Delay Times
Notes:
A. Includes test lead and test apparatus capacitance.
B. All pulses are supplied at pulse repetition rate
≤
1 MHz.
C.The inputs are measured one at a time with one transition per measurement.
D. For the open drain device t
PLZ
and t
PZL
are the same as t
PD.
E. t
PZL
is measured at V
M
.
F. t
PLZ
is measured at V
OL
+V
∆.
D. A Thevenin equivalent load may be used in place of V
CC
X 2 and resistor divider.
Figure 1 Load Circuit and Voltage Waveforms
74HC05
Document number: DS35321 Rev. 3 - 2
4 of 7
www.diodes.com
January 2013
© Diodes Incorporated
74HC05
Ordering Information
NEW PRODUCT
Device
74HC05S14-13
74HC05T14-13
Package Code
S14
T14
Packaging
SO-14
TSSOP-14
7” Tape and Reel
Quantity
Part Number Suffix
2500/Tape & Reel
-13
2500/Tape & Reel
-13
Marking Information
(1) SO-14, TSSOP-14
Part Number
74HC05S14
74HC05T14
Package
SO-14
TSSOP-14
74HC05
Document number: DS35321 Rev. 3 - 2
5 of 7
www.diodes.com
January 2013
© Diodes Incorporated
