HIGH SPEED SILICON SWITCHING DIODE
IN914, B
IN916
250mW
DO- 35
Glass Axial Package
FEATURES
Intended for General Purpose Application.
ABSOLUTE MAXIMUM RATINGS (Ta=25ºC unless specified otherwise)
DESCRIPTION
SYMBOL
V
R
Reverses Voltage ( Continuous)
V
RRM
Repetitive Peak Reverse Voltage
Average Forward Current
T
A
=25ºC
I
F (AV)
I
F (AV)
T
A
=150ºC
I
F
Forward Current (D.C.)
I
FRM
Repetitive Peak Forward Current
Non Repetitive Peak Surge Current
I
FSM
tp=1sec
P
tot
Power Dissipation
T
stg
Storage Temperature
T
amb
Operating ambient Temperature
ELECTRICAL CHARACTERISTICS (Ta=25ºC unless specified otherwise)
DESCRIPTION
SYMBOL TEST CONDITION
V
F
Forward Voltage
I
F
=10
IN914/916
I
F
=100mA,
1N914B
I
F
=5mA,
Reverse Breakdown Voltage
Reverse Current
V
(BR)R
I
R
I
R
=100µA
V
R
= 20V
V
R
= 75V
V
R
= 20V, T
j
=150ºC
VALUE
75
100
75
10
75
225
500
250
-65 to +200
-65 to +175
UNIT
V
V
mA
mA
mA
mA
mA
mW
ºC
ºC
MIN
TYP
MAX
1.0
1.0
0.72
UNIT
V
V
V
V
nΑ
µA
0.62
100
25
5
Diode Capacitance
Reverse Recovery Time
C
d
t
rr
V
R
=0, f=1MHz
I
F
=10mA to I
R
=10mA
R
L
=100
Ω
Measured at I
R
=1mA
I
F
=10mA to I
R
=60mA
R
L
=100
Ω
Measured at I
R
=1mA
2.5
8
pF
ns
4
ns
1N914_B_6 Rev031001
Continental Device India Limited
Data Sheet
Page 1 of 3
IN916
250mW
DO- 35
Glass Axial Package
DO-35 Glass Axial Package
A
B
A
DIM
MIN
MAX
—
A
25.40
B
3.05 4.15
C
0.46 0.56
D
1.70 2.29
All dimensions are in mm.
C
NOTE:
Cathode is marked by Band.
D
DO-35, 52mm Taping Specification
1.05 MAX.
1.5 R MAX.
5.50
4.50
52 mm Taping Specification
1.
2.
3.
4.
5.
T & A indicates Axial Tape and Ammo
Packing (52 mm Tape Spacing).
300 mm (min) leader tape on every tape.
No. of empty places allowed 0.25%
without consecutive empty places.
Ends of leads shall preferably not
protrude beyond the tapes.
Components shall be held sufficiently in
the tape or tapes so that they
can not come free in normal handling.
CENTRE LINE
± 1.05
54.00
6.0
11 DIODES
52.0
48.0
5.0
50.00
All dimensions are in mm.
LEADER
6 . 0
± 1. 0
52
±2.
.0
0
DIODE AMMO PACK
TAPES
FE
ED
6.0
±1.0
±2.0
83.0
LABEL
.0
±2
.0
255
DO-35:- 5000 pcs./Ammo Pack
On request also available
in 26 mm Tape
80.
±2.0
0
Packing Detail
PACKAGE
Details
DO-35 T&A
5K/
ammo box
STANDARD PACK
Net Weight/
Qty
0.88 kg/ pcs
5K
Size
10" x 3.2" x 3.2"
INNER CARTON BOX
Qty
5K
Size
OUTER CARTON BOX
Qty
125K
Gr Wt
25 kgs
12.7" x 12.7" x 20"
1N914_B_6 Rev031001
Continental Device India Limited
Data Sheet
Page 2 of 3
IN916
250mW
Component Disposal Instructions
1. CDIL Semiconductor Devices are RoHS compliant, customers are requested to please dispose
as per prevailing Environmental Legislation of their Country.
2. In Europe, please dispose as per EU Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE).
Customer Notes
Disclaimer
The product information and the selection guides facilitate selection of the CDIL's Semiconductor Device(s) best suited for application in
your product(s) as per your requirement. It is recommended that you completely review our Data Sheet(s) so as to confirm that the
Device(s) meet functionality parameters for your application. The information furnished in the Data Sheet and on the CDIL Web Site/CD
are believed to be accurate and reliable. CDIL however, does not assume responsibility for inaccuracies or incomplete information.
Furthermore, CDIL does not assume liability whatsoever, arising out of the application or use of any CDIL product; neither does it convey
any license under its patent rights nor rights of others. These products are not designed for use in life saving/support appliances or
systems. CDIL customers selling these products (either as individual Discrete Semiconductor Devices or incorporated in their end
products), in any life saving/support appliances or systems or applications do so at their own risk and CDIL will not be responsible for any
damages resulting from such sale(s).
CDIL strives for continuous improvement and reserves the right to change the specifications of its products without prior notice.
CDIL is a registered Trademark of
Continental Device India Limited
C-120 Naraina Industrial Area, New Delhi 110 028, India.
Telephone + 91-11-2579 6150,
4141
1112 Fax + 91-11-2579 5290,
4141
1119
email@cdil.com
www.cdilsemi.com
1N914_B_6 Rev031001
Continental Device India Limited
Data Sheet
Page
3
of
3
