T-5/8 Surface Mounting Tape & Reel Package,
0581, 0587, 0589 Series
The 058X series of tape and reel packaged subminiature lamps are designed for automated surface mount applications. The different
series indicate lead shaping from the same LED type. When packaged in bulk without lead forming the series is 0580. These lamps are
compatible with vapor phase reflow surface mounting as well as conventional soldering.
Anode(Cathode for SR)
0.13 max
0.5±.1
0.4±.1
6 max
0581 Series
2.0
Ø1.9
Cathode
1.4
0.16
1.1
2.5±.2
30
40
20
10
0
10
20
30
40
2.8
0.13 max
0.8
4.2 max
0587 Series
50
60
70
80
90
75
50
25
25
50
75
50
0.2 max
60
70
80
90
7.6 max
0589 Series
Relative Intensity (%)
GENERAL INFORMATION
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
Preheat Temperature
-40 °C to +85 °C
-40 °C to +85 °C
240 °C for 3 sec
100 °C
APPLICATION INFORMATION (ALL RATINGS AT 25 °C AMBIENT)
Chip
Part No.
Emitted
Color
Red
Red
Green
Blue
Blue
Peak
Absolute Maximum Ratings
E/O Characteristics
Vr
(V)
5
5
5
5
5
5
Min
–
1.7
1.7
1.7
-
-
Vf
(V)
@If=20mA
Typ
1.7
2.0
2.1
2.0
3.8
3.5
Max
2.4
2.8
2.8
2.8
4.5
4.0
Iv
(mcd)
@ If=20mA
Min
113
48
30
18
160
213
Typ
170
80
50
30
203
270
λ
(nM)
660
640
570
585
428
468
∆λ
(nM)
20
45
30
35
65
26
Pd
(mW)
100
105
105
105
140
140
If
(mA)
dc
30
30
25
30
30
30
1/10 duty
@ 1 khz
Ir
@Vr=5V
2Θ
1/2
(Deg)
25
25
25
25
25
25
Material
(µA)
10
10
10
10
50
50
ISRC058X
IVGC058X
IUBC058X
GaAlAs
GaP
GaN/SiC
150
150
150
150
70
70
IVRC058X GaAsP/GaP
IVYC058X GaAsP/GaP Yellow
IUBC058X7 InGaN/SiC
Specifications subject to change without notice. Dimensions are in mm±0.3 unless stated otherwise. *reversed polarity
IDEA, Inc., 1351 Titan Way, Brea, CA 92821 Ph:714-525-3302, 800-LED-IDEA; Fax: 714-525-3304 0508
