BZX85C9V1

Description
Zener Diode, 9.1V V(Z), 6.1%, 1.3W, Silicon, Unidirectional, DO-41
CategoryDiscrete semiconductor    diode
File Size63KB,3 Pages
ManufacturerDiodes Incorporated
Download Datasheet Parametric View All

BZX85C9V1 Online Shopping

Suppliers Part Number Price MOQ In stock
BZX85C9V1 - - View Buy Now

BZX85C9V1 Overview

Zener Diode, 9.1V V(Z), 6.1%, 1.3W, Silicon, Unidirectional, DO-41

BZX85C9V1 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
Objectid1436982917
package instructionO-LALF-W2
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresLOW NOISE
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeZENER DIODE
Maximum dynamic impedance5 Ω
JEDEC-95 codeDO-41
JESD-30 codeO-LALF-W2
JESD-609 codee0
Number of components1
Number of terminals2
Maximum operating temperature200 °C
Package body materialGLASS
Package shapeROUND
Package formLONG FORM
Peak Reflow Temperature (Celsius)NOT SPECIFIED
polarityUNIDIRECTIONAL
Maximum power dissipation1.3 W
Certification statusNot Qualified
Nominal reference voltage9.1 V
surface mountNO
technologyZENER
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formWIRE
Terminal locationAXIAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Maximum voltage tolerance6.1%
Working test current25 mA
BZX85C2V7 - BZX85C75
1.3W ZENER DIODE
Features
Very Sharp Edge in Reverse Characteristics
Low Reverse Current Level
Very High Stability
Low Noise
A
B
A
D
C
Mechanical Data
Case: DO-41, Glass
Terminals: Solderable per MIL-STD-202,
Method 208
Polarity: Cathode Band
Approx. Weight: 0.35 grams
Dim
A
B
C
D
DO-41 Glass
Min
25.40
Max
4.70
0.863
2.71
All Dimensions in mm
Maximum Ratings
Power Dissipation
@ T
A
= 25°C unless otherwise specified
Symbol
P
d
R
θJA
V
F
T
j
, T
STG
Value
1.3
110
1.0
-65 to +175
Unit
W
K/W
V
°C
Test Condition
Lead length = 4mm, T
L
= 25°C
Lead length = 4mm T
L
= constant
I
F
= 200mA
Characteristic
Thermal Resistance, Junction to Ambient Air
Forward Voltage
Operating and Storage Temperature Range
DS18014 Rev. C-2
1 of 3
BZX85C2V7-BZX85C75
