SMD POWER INDUCTORS
1. PART NO. EXPRESSION :
SSB1205 SERIES
SSB12054R7MZF
(a)
(b)
(c)
(d)(e)(f)
(a) Series code
(b) Dimension code
(c) Inductance code : 4R7 = 4.7uH
(d) Tolerance code : M = ±20%
(e) X, Y, Z : Standard part
(f) F : Lead Free
2. CONFIGURATION & DIMENSIONS :
B
C
E
F
I
G
I
A
12.50±0.3 12.50±0.3
3. SCHEMATIC :
4. MATERIALS :
g
b
(a) Core : DR Ferrite Core
a
d
c
e
f
(b) Core : RI Ferrite Core
(c) Base : LCP
(d) Wire : Enamelled Copper Wire
(e) Terminal : Tinned Copper Plate
(f) Adhesive : Epoxy
(g) Ink : Bon Margue
5. GENERAL SPECIFICATION :
a) Irms : Temp. rise 40°C Typ.
b) Isat : L/L0A = 10% Typ.
c) Storage temp. : -40°C to +125°C
d) Operating temp. : -40°C to +85°C
e) Resistance to solder heat : 260°C.10 secs
NOTE : Specifications subject to change without notice. Please check our website for latest information.
100
B
C
5.50±0.3
D
A
PCB Pattern
Unit:m/m
D
3.0±0.10
E
2.0±0.15
F
8.6±0.30
G
5.6 Ref.
H
3.2 Ref.
I
2.5 Ref.
H
08.05.2008
SUPERWORLD ELECTRONICS (S) PTE LTD
PG. 1
SMD POWER INDUCTORS
6. ELECTRICAL CHARACTERISTICS :
Part No.
SSB12054R7MZF
SSB12056R8MZF
SSB1205100MZF
SSB1205150MZF
SSB1205220MZF
SSB1205330MZF
SSB1205470MZF
SSB1205680MZF
SSB1205101MZF
SSB1205151MZF
SSB1205221MZF
SSB1205331MZF
SSB1205471MZF
SSB1205681MZF
SSB1205102MZF
SSB1205152MZF
Inductance
( µH )
4.7±20%
6.8±20%
10.0±20%
15.0±20%
22.0±20%
33.0±20%
47.0±20%
68.0±20%
100.0±20%
150.0±20%
220.0±20%
330.0±20%
470.0±20%
680.0±20%
1000.0±20%
1500.0±20%
Test
Frequency
( Hz )
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
1V / 100K
RDC
(m )
Max.
23
25
30
38
46
60
85
110
150
240
350
500
710
1000
1450
2100
SSB1205 SERIES
Irms
(A)
Typ.
5.30
5.00
4.50
4.00
3.50
3.20
2.50
2.20
1.80
1.40
1.20
1.00
0.88
0.73
0.60
0.48
Isat
(A)
Typ.
5.00
4.00
3.50
2.80
2.30
1.90
1.60
1.30
1.10
0.90
0.72
0.60
0.50
0.43
0.35
0.29
NOTE : Specifications subject to change without notice. Please check our website for latest information.
08.05.2008
SUPERWORLD ELECTRONICS (S) PTE LTD
PG. 2
SMD POWER INDUCTORS
7. CHARACTERISTICS CURVES :
SSB1205 SERIES
@ TEMP. RISE VS. DC SUPERPOSITION RESPONSE CURVE
90
80
70
60
50
40
30
20
10
0 0
152M 102M
101M
330M
4R7M
t
(°C)
1
2
3
4
5
6
7
8
DC CURRENT (A)
@ INDUCTANCE VS. FREQUENCY RESPONSE CURVE
10 4
5
3
152M
@ INDUCTANCE VS. DC SUPERPOSITION RESPONSE CURVE
10 4
5
3
152M
10 3
5
3
102M
10 3
5
3
102M
L
(uH)
10 2
5
3
10 1
5
3
0
10
10-3
101M
L
(uH)
10 2
5
101M
330M
3
10 1
330M
4R7M
5
3
0
10
10-3
4R7M
3 5
10-2 3 5
-1
10
3 5
0
10
3 5
1
10
3 5
102
3 5
10-2 3 5
-1
10
3 5
0
10
3 5
1
10
3 5
102
FREQUENCY(MHZ)
DC CURRENT (A)
NOTE : Specifications subject to change without notice. Please check our website for latest information.
08.05.2008
SUPERWORLD ELECTRONICS (S) PTE LTD
PG. 3
SMD POWER INDUCTORS
RECOMMENDED SOLDERING CONDITIONS
REFLOW SOLDERINGS
10s max.
SSB1205 SERIES
255°C
230°C
180°C
150°C
Pre-heating
40s max.
Natural
cooling
90 to 120s
8. PACKAGING INFORMATION :
( 1 ) CONFIGURATION
T
COVER TAPE
2.0±0.5
ØC
ØC
N
A
B
D
G
EMBOSSED CARRIER
* CARRIER TAPE WIDTH : D
P:16 m/m
4 m/m
( 2 ) DIMENSIONS
STYLE
13-24
A
330
B
21±0.8
C
13
D
24
G
26
+0
N
50
-0
( 3 ) Q'TY & G.W. PER PACKAGE
INNER : REEL
SERIES
SSB1205
Q'TY (PCS)
600
G.W. (gw)
1000
STYLE
13-24
OUTER : CARTON
Q'TY (PCS)
2400
G.W. (Kg)
7.5
SIZE (cm)
40 x 40 x 24
NOTE : Specifications subject to change without notice. Please check our website for latest information.
SUPERWORLD ELECTRONICS (S) PTE LTD
PG. 4
100
100
100
100
100
100
100
100
Unit:m/m
T
30.4
08.05.2008
SMD POWER INDUCTORS
9. RELIABILTY AND TEST CONDITION :
SSB1205 SERIES
TEST ITEM
SOLDERABILITY
SPECIFICATION
MORE THAN 90% OF THE
TERMINAL ELECTRODE
SHALL BE COVERED
WITH FRESH SOLDER.
TEST CONDITION
PREHEAT : 125±25°C FOR 60 SECONDS
SOLDER : 99%Sn/0.3%Ag/0.7%Cu OR EQUIVALENT
SOLDER TEMP. : 245±5°C
FLUX : ROSIN
DIP TIME : 4±1 SECONDS
THERMAL SHOCK
TEST
INDUCTANCE SHALL
NOT CHANGE MORE
THAN ±20%
ROOM TEMP.
15 MINUTES
-25±2°C
30 MINUTES
( TEMP. CYCLE )
ROOM TEMP.
15 MINUTES
TOTAL : 50 CYCLES
85±2°C
30 MINUTES
HUMIDITY
RESISTANCE TEST
TEMPERATURE : 40±2°C
HUMIDITY : 90 ~ 95%
APPLIED CURRENT : PER SPEC.
TIME : 500 HOURS
HIGH TEMP.
RESISTANCE TEST
TEMPERATURE : 85±2°C
APPLIED CURRENT : PER SPEC.
TIME : 500 HOURS
NOTE : Specifications subject to change without notice. Please check our website for latest information.
08.05.2008
SUPERWORLD ELECTRONICS (S) PTE LTD
PG. 5
