NCST12GR050HTRF datasheet, PDF

Datasheet> All Categories > Passive components> The resistor> NCST12GR050HTRF

NCST12GR050HTRF: DescriptionFixed Resistor, Metal Strip, 0.25W, 0.05ohm, 2% +/-Tol, 400ppm/Cel, Surface Mount, 1206, CHIP, ROHS COMPLIANT; CategoryPassive components The resistor; File Size341KB，9 Pages; ManufacturerNIC Components Corp; Environmental Compliance

Download Datasheet Parametric Compare View All

NCST12GR050HTRF Overview

Fixed Resistor, Metal Strip, 0.25W, 0.05ohm, 2% +/-Tol, 400ppm/Cel, Surface Mount, 1206, CHIP, ROHS COMPLIANT

NCST12GR050HTRF Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1760568542
package instruction	CHIP, ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
structure	Chip
JESD-609 code	e3
Installation features	SURFACE MOUNT
Number of terminals	2
Maximum operating temperature	155 °C
Minimum operating temperature	-55 °C
Package height	0.6 mm
Package length	3.05 mm
Package shape	RECTANGULAR PACKAGE
Package form	SMT
Package width	1.55 mm
method of packing	TR, 7 INCH
Rated power dissipation(P)	0.25 W
Rated temperature	70 °C
resistance	0.05 Ω
Resistor type	FIXED RESISTOR
size code	1206
surface mount	YES
technology	METAL STRIP
Temperature Coefficient	400 ppm/°C
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal shape	WRAPAROUND
Tolerance	2%

Preview

Download Datasheet

View All

Current Sensing Chip Resistors

FEATURES

•

SURFACE MOUNTABLE 0201 ~ 7520 CASE SIZE

PRECISON TOLERANCE (±1%)

POWER RATINGS UP TO 3 WATTS

Pb-FREE REFLOW COMPATIBLE

includes all homogeneous materials

NCST Series

RoHS

Compliant

*See Part Number System for Details

Operating

Temp. Range

(°C)

CHARACTERISTICS

Type

EIA

Size

Power Rating at

70°C

Resistance

Tolerance

1% (F)

2% (G)

5% (J)

1% (F)

2% (G)

5% (J)

Temperature

Coefficient (°C)

±300ppm (G)

±600ppm (J)

±1000ppm (R)

±200ppm (F)

±300ppm (G)

±400ppm (H)

±200ppm (F)

NCST06

0603

1/10W

1% (F)

2% (G)

5% (J)

±300ppm (G)

±400ppm (H)

±600ppm (J)

±100ppm (E)

NCST10

0805

1/8W

1% (F)

2% (G)

5% (J)

±200ppm (F)

±300ppm (G)

±400ppm (H)

±600ppm (J)

±100ppm (E)

NCST12

1206

1/4W

1% (F)

2% (G)

5% (J)

±200ppm (F)

±300ppm (G)

±400ppm (H)

±600ppm (J)

±100ppm (E)

NCST25*

1210

1/2W

1% (F)

2% (G)

5% (J)

±200ppm (F)

±300ppm (G)

±400ppm (H)

±600ppm (J)

±100ppm (E)

NCST50*

2010

3/4W

1% (F)

2% (G)

5% (J)

±200ppm (F)

±300ppm (G)

±400ppm (H)

±600ppm (J)

*Tolerance Codes: 1% (F), 2% (G) or 5% (J)

Resistance

Range

501mΩ ~ 1Ω

150mΩ ~ 500mΩ

100mΩ ~ 149mΩ

501mΩ ~ 1Ω

101mΩ ~ 500mΩ

50mΩ ~ 100mΩ

501mΩ ~ 1Ω

101mΩ ~ 500mΩ

51mΩ ~ 100mΩ

20mΩ ~ 50mΩ

100mΩ ~ 1Ω

200mΩ ~ 1Ω

101mΩ ~ 199mΩ

51mΩ ~ 100mΩ

20mΩ ~ 50mΩ

100mΩ ~ 1Ω

51mΩ ~ 99mΩ

21mΩ ~ 50mΩ

10mΩ ~ 20mΩ

75mΩ ~ 1Ω

100mΩ ~ 1Ω

51mΩ ~ 99mΩ

21mΩ ~ 50mΩ

10mΩ ~ 20mΩ

50mΩ ~ 1Ω

100mΩ ~ 1Ω

51mΩ ~ 99mΩ

21mΩ ~ 50mΩ

10mΩ ~ 20mΩ

Resistance

Range (Codes)

R501 ~ 1R00

R150 ~ R500

R100 ~ R149

R501 ~ 1R00

R101 ~ R500

R050 ~ R100

R501 ~ 1R00

R101 ~ R500

R051 ~ R100

R020 ~ R050

R100 ~ 1R00

R200 ~ 1R00

R101 ~ R199

R051 ~ R100

R020 ~ R050

R100 ~ 1R00

R051 ~ R099

R021 ~ R050

R010 ~ R020

R075 ~ 1R00

R100 ~ 1R00

R051 ~ R099

R021 ~ R050

R010 ~ R020

R050 ~ 1R00

R100 ~ 1R00

R051 ~ R099

R021 ~ R050

R010 ~ R020

-55°C ~ +155°C

NCST02

0201

1/20W

NCST04

0402

1/16W

Sizes and Values Table Continues on Next Page

PART NUMBER SYSTEM

NCST10 F R501 F TR F

RoHS compliant

Packaging: TR = Tape & Reel

TCR Code: E=100ppm, X=150ppm, F=200ppm,

G=300ppm, H=400ppm, J=600ppm,

R=1000ppm

Resistance Code: See examples

Tolerance Code: J=5%, G=2%, F=1%

Series and Size Code

NIC COMPONENTS CORP.

www.niccomp.com

www.lowESR.com

www.RFpassives.com

www.SMTmagnetics.com

SPECIFICATIONS ARE SUBJECT TO CHANGE
