SUMMIT
MICROELECTRONICS, Inc.
Preliminary
SMS2916
3 and 5 Volt Systems
Precision Voltage Supervisory Circuit
With Watchdog Timer and 16K I
2
C Memory
FEATURES
• Precision Voltage Monitor
– Automatic V
CC
Supply Monitor
- Complementary reset outputs for complex
microcontroller systems
- Integrated memory write lockout function
- No external components required
• Watchdog Timer
– Nominal 1.6 second Timeout
• Memory Internally Organized 2K X 8
– Two Wire Serial Interface (I
2
C™)
• High Reliability
– Endurance: 1,000,000 erase/write cycles
– Data retention: 100 years
• 8-Pin PDIP or SOIC Packages
OVERVIEW
The SMS2916 is a power supervisory circuit that monitors
V
CC
(either in a 5V system or 3V system) and will generate
complementary reset outputs. The reset pins also act as
I/Os and may be used for signal conditioning. The
SMS2916 also has an on-board watchdog timer that has
a nominal time out period of 1.6 seconds.
The SMS2916 integrates a 16K-bit nonvolatile serial
memory. It features the industry standard I
2
C serial
interface allowing quick implementation in an end-users’
system.
BLOCK DIAGRAM
V
CC 8
2
RESET
5KHz
Oscillator
RESET
PULSE
GENERATOR
V
CC
+
-
GND 4
1.26V
V
TRIP
RESET
CONTROL
7
RESET
WATCHDOG
TIMER
SCL
SDA
6
5
EEPROM
MEMORY
ARRAY
WDI
1
2028 ILL2.1
SUMMIT MICROELECTRONICS, Inc.
•
300 Orchard City Drive, Suite 131
•
Campbell, CA 95008
•
Telephone 408-378-6461
•
Fax 408-378-6586
•
www.summitmicro.com
© SUMMIT MICROELECTRONICS, Inc. 1998
2028-02 4/24/98
Characteristics subject to change without notice
1
