308 Constitution Drive
Menlo Park, CA 94025-1164
Phone: 800-227-4856
www.circuitprotection.com
PolySwitch®
PTC Devices
Overcurrent Protection Device
Raychem Circuit Protection Products
PRODUCT: TRF600-150-B-0.5
DOCUMENT: SCD 25731
REV LETTER: G
REV DATE: MAY 27, 2010
PAGE NO.: 1 OF 1
Specification Status: Released
Maximum Operating Voltage:
250V
DC
Fault Ratings at 20°C:
250V
AC
, 3A, 10 applications
600V
AC
, 40A, 1 application
Additional Info at 20°C:
•
Resistance matched: 0.5 Ohm
•
Lightning withstand: TIA-968-A
•
Helps equipment meet UL60950 (UL1459)
Lead Material:
22 AWG Tin-Plated Copper (0.64 mm [0.025”] nominal diameter)
Marking:
TABLE I. DIMENSIONS:
A
MIN
MAX
MIN
mm:
--
9.0
--
in:*
--
(0.35)
--
*Rounded off approximation
B
MAX
12.5
(0.49)
MIN
--
--
C
MAX
4.6
(0.18)
MIN
4.7
(0.19)
D
MAX
--
--
E
NOM
5.0
(0.20)
F
MIN
--
--
MAX
9.0
(0.35)
TABLE II. PERFORMANCE RATINGS @ 20°C (as measured in Loranger sockets P/N 02901-032-6218A):
HOLD
TRIP
CURRENT CURRENT
(A)
(A)
RESISTANCE (Ω)
TIME TO TRIP(Sec)
@ 1A
MAX
4.0
OPERATING
TEMPERATURE
(°C)
MIN
MAX
-40
85
TRIPPED
POWER DISSIPATION
(W) @ 250V
DC
TYP
MAX
1.4
1.8
R MIN R MAX R
1 MAX
*
TYP
0.150
0.300
6.0
10.0
17.0
1.4
*Maximum device resistance at 20°C measured 1 hour post trip.
TABLE III. APPLICABLE PART DESCRIPTIONS:
PART DESCRIPTION
TRF600-150-B-0.5
TRF600-150-B-0.5-2
PACKAGING TYPE
Bulk
Tape and Reel
NOTES
N/A
Dim D not applicable
Agency Recognitions:
Reference Documents:
Precedence:
Effectivity:
CAUTION:
UL (File # E74889), CSA (File #CA-78165-7), TUV
Raychem PS300, PS500, UL60950, TIA-968A, GR1089
This specification takes precedence over documents referenced herein.1.9
Reference documents shall be the issue in effect on the date of invitation for bid.
Operation beyond the rated voltage or current may result in rupture, electrical arcing or flame.
Materials Information
ROHS Compliant
ELV Compliant
Pb-Free
© 2006, 2010 Tyco Electronics Corporation. All rights reserved.
