TRJ Series • Pulse Transformers for RF Applications
These miniature transformers are suitable for pulse
applications requiring a very fast rise time and for 50 ohm
wideband RF
Features
• SMD styles are pick and place compatable and
provide consistent and reliable coplanarity
• EMI noise suppression in the common mode
• low leakage inductance
• excellent quality at extremely competitive price due to high
volume production
• Manufactured in an ISO-9001:2000, TS-16949:2002
and ISO-14001:2004 certified Talema facility
• Fully RoHS compliant and meets lead free
reflow level J-STD-020C
Electrical Specifications @ 25°C
Power Rating : 250mW
Dielectric Strength between windings: 700Vrms
Operating Temperature Range: -40°C to +85°C
Storage Temperature: -40°C to +125°C
Insulation Resistance: 10,000 MOhm minimum
Test Frequency: Inductance measured @ 100kHz/20mVrms
Standard Packaging: Tape & Reel
TRJ Series • SMD RF Pulse Transformers
Bandw ith for
Part
Number
OCL
(µH ±30%
Turns
Ratio
±2%
L
L
Pri/Sec
C
C
Pri/Sec
Rise
Time
Primary
ET
R
CU
P
R
CU
S
R
CU
T
-3dB Loss
Freq. (MHz )
Low
High
Schematic
(µH Max) (pF Max) (nS Max) (V-µS Min)
(mOhms) (mOhms) (mOhms)
TRJ-20-6A
TRJ-20-6C
TRJ-40-6A
TRJ-40-6C
TRJ-40-6D
TRJ-80-6A
TRJ-80-6B
TRJ-80-6C
TRJ-80-6E
TRJ-80-6F
20
20
40
40
40
80
80
80
80
80
1:4
1:4ct
1:2
1:2ct
1:1:1
1:1
1ct:1ct
1:1ct
1:1.414
1:1.414ct
0.10
0.10
0.14
0.14
0.10
0.15
0.18
0.18
0.30
0.20
10
10
15
15
12
12
15
15
18
18
6.0
6.0
3.0
3.0
2.0
2.2
3.0
3.0
4.0
3.0
1.25
1.25
2.00
2.00
2.00
2,50
2.50
2.50
2.50
2.50
90
90
130
130
130
190
190
190
270
270
360
360
260
260
130
190
190
190
270
270
--
--
--
--
130
--
--
--
--
--
0.20
0.20
0.10
0.10
0.10
0.05
0.05
0.05
0.05
0.05
60
60
110
110
150
110
90
90
50
50
A
C
A
C
D
A
B
C
A
C
TRJ
TALEMA IN
Suggested
Pad Layout
0.200
(5.08)
6
Schematic
A
1
6
5
0.453 0.374
WK/YR
(11.50) (9.50)
Part Number
0.100
(2.54)
B
1
2
3
0° - 8°
0.307
(7.80)
0.283 0.244
(7.20) (6.20)
0.492 0.287
(12.50) (7.30)
0.047
(1.20)
4
3
4
C
6
1
2
4
3
6
1
D
2
5
3
4
0.020 x 0.12
(0.50 x 0.30)
Surface coplanarity will be 0.004 (0.01) maximum
Dimensions: Inches (Millimeters)
To l e r a n c e : ± 0 . 0 1 0 ( 0 . 2 5 ) u n l e s s s p e c i f i e d o t h e r w i s e
USA: AlfaMag Electronics LLC | 945 Parkwood | PO Box 668 | Rolla, MO 65402
Phone: 1-800-413-6693 FAX: 1-364-5390 EMail: support@alfamag.com
http://www.alfamag.com
(10-06 )Networks\TRJ
