SERIES 28
HiPer-D
®
Combo Connectors
280-047S combo cable socket connectors with standard
mounting flange, crimp termination
Combo HiPer-D
®
socket connectors feature size #20 signal contacts and size #8
power or coax contacts.
Size #8 contacts are ordered separately.
The HiPer-D
®
features a rugged machined aluminum shell, waterproof sealing and optional
ground springs for improved resistance to electromagnetic interference. Size
#20 contacts are packaged with connector. Terminate contacts with crimp tools
purchased separately. Glass-reinforced thermoset epoxy insulators, copper alloy
retention clips. Fluorosilicone rear grommet meets IP67 immersion requirement.
1000 VAC, 7.5 Amps (#20), up to 40 Amps with size #8 power contacts.
How To Order
Sample Part Number
Basic Part Number
280-047S
See Shell Size - Contact Arrangements Table
ME
= Electroless Nickel
MT
= Nickel-PTFE
JF
= Cadmium with Yellow Chromate
N
= No Hardware (Through-Hole)
P
= #4-40 Female Jackpost
L
= Jackscrew, Hex Head, Low Profile
Z2
= Gold
Z1
= Passivated Stainless Steel
K
= Jackscrew, Slot Head, Extended Length
S
= Screwlock, Male, Hex Head, Low Profile
T
= Screwlock, Male, Slot Head, Extended Length
280-047S
3-5W5 MT
P
C
Shell Size-
Contact Arrangement
Shell Finish
Mating Hardware
Contact Arr.
1-2W2
1-5W1
2-3W3
2-7W2
2-11W1
3-5W5
3-9W4
3-13W3
3-17W2
3-21W1
4-8W8
4-13W6
4-17W5
4-21WA4
4-25W3
4-27W2
5-24W7
5-36W4
5-43W2
5-47W1
Contact Arrangements
Contact Size and Qty
Shell Size-
#20
4
5
10
5
10
15
20
7
12
17
22
25
17
32
41
46
#8
2
1
3
2
1
5
4
3
2
1
8
6
5
4
3
2
7
4
2
1
Mating Hardware
N
Thru-Hole
No Hardware
P
Female Jackpost
#4-40 UNC-2A
NUT AND
LOCKWASHER
Specifications
Current Rating
Test Voltage
Insulation
Resistance
Operating
Temperature
Ingress
Protection
Shock
Vibration,
Random
#20 7.5 AMPS, #8 40 AMPS
1000 VAC RMS
5000 megohms minimum
-65° C. to +200° C.
IP 67
300 g.
43.92 g.
.115/.125
(2.92/3.18)
#4-40 UNC-2B
S
Captive Screwlock,
Hex Head
L
Captive Jackscrew,
Hex Head
RETAINER
RETAINER
#4-40 UNC-2A
#4-40 UNC-2A
Materials and Finishes
Shell
Contacts
Insulators
Retention Clips
Grommet
Hardware
Aluminum alloy
Copper alloy, 50
microinches gold
Thermoset epoxy
Copper alloy
Fluorosilicone rubber
300 series stainless steel
K
Slot-Head Extended
Jackscrew
1.1 (28)
MAX
RETAINER
#4-40 UNC-2A
T
Slot-Head Extended
Captive Screwlock
1.1 (28)
MAX
RETAINER
#4-40 UNC-2A
C-8
Rev. 09.04.20
© 2015 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • Series 28 HiPer-D catalog
Dimensions in Inches (millimeters) are subject to change without notice.
SERIES 28
HiPer-D
®
Combo Connectors
280-047S combo cable socket connectors with standard
mounting flange, crimp termination
280-047S DIMENSIONS
OPTIONAL SEALING BOOT
SUPPLIED WITH CONTACT OR
ORDERED SEPARATELY
1.129 (28.68)
(REF)
A
C
D
Ø .120 (3.05)
TYP
.049
(1.24)
E
.435
(11.05)
F
C
G
B
10°
TYP
.243 ± .005
(6.17 ± 0.13)
BACKSHELL
MOUNTING
GROOVE
10°
TYP
Dimensions
Shell
Size
1
2
3
4
5
A
B
C Basic
D
E
F
G
± .015 ± 0.38 ± .015 ± 0.38
1.213
30.81
.494
12.55
1.541
2.088
2.729
2.635
39.14
53.04
69.32
66.93
.494
.494
.494
.605
12.55
12.55
12.55
15.37
in
mm
in
mm
in.
.984
1.312
1.852
2.500
2.406
mm
24.99
33.32
47.04
63.50
61.11
± .005 ± 0.13 ± .005 ± 0.13 ± .005 ± 0.13 ± .005 ± 0.13
.643
16.33
.311
7.90
.769
19.53
.432
10.97
.971
1.511
2.159
2.054
24.66
38.38
54.84
52.17
.311
.311
.311
.423
7.90
7.90
7.90
10.74
1.093
1.635
2.282
2.188
27.76
41.53
57.96
55.58
.432
.432
.432
.544
10.97
10.97
10.97
13.82
in
mm
in
mm
in
mm
in
mm
NOTES
1. See
About Series 28 HiPer-D
®
Shell Plating Options
for additional shell material and finish options. Glenair offers the industry’s widest
selection of plating options with no minimum order quantities or setup charges.
2. For panel cutouts, refer to
Panel Cutouts and Printed Circuit Board Footprints.
3. Connectors are supplied with size #20 crimp contacts per M39029. Contacts are not installed. Refer to
HiPer-D
®
Contacts and Tools
section for contact part numbers, specifications, crimp tool information, and insertion/extraction tools.
4.
Size 8 contacts are ordered separately.
Refer to
HiPer-D
®
Contacts and Tools
section for contact ordering information, specifications,
crimp tool information, and insertion/extraction tools.
5. Combo HiPer-D
®
connectors meet the applicable requirements of MIL-DTL-24308 and are intermateable with standard non-
environmental D Subminiature connectors with corresponding contact arrangements and type.
Size 8 contacts from other
manufacturers cannot be installed in HiPer-D
®
connectors.
6. Additional electrical, mechanical and environmental specifications are listed in
HiPer-D
®
Product Specification.
© 2015 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • Series 28 HiPer-D catalog
Dimensions in Inches (millimeters) are subject to change without notice.
C-9
