Part Number

Search

SMBTA64

Description
PNP Silicon Darlington Transistors
CategoryDiscrete semiconductor    The transistor
File Size43KB,4 Pages
ManufacturerInfineon
Websitehttp://www.infineon.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

SMBTA64 Overview

PNP Silicon Darlington Transistors

SMBTA64 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerInfineon
Parts packaging codeSOT-23
package instructionSMALL OUTLINE, R-PDSO-G3
Contacts3
Reach Compliance Codecompli
ECCN codeEAR99
Maximum collector current (IC)0.5 A
Collector-emitter maximum voltage30 V
ConfigurationDARLINGTON
Minimum DC current gain (hFE)20000
JESD-30 codeR-PDSO-G3
Humidity sensitivity level1
Number of components1
Number of terminals3
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typePNP
Maximum power dissipation(Abs)0.36 W
Certification statusNot Qualified
surface mountYES
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Transistor component materialsSILICON
Nominal transition frequency (fT)125 MHz
SMBTA63, SMBTA64
PNP Silicon Darlington Transistors
High collector current
High DC current gain
3


2
1
VPS05161
Type
SMBTA63
SMBTA64
Maximum Ratings
Parameter
Marking
s2U
s2V
1=B
1=B
Pin Configuration
2=E
2=E
3=C
3=C
Package
SOT23
SOT23
Symbol
V
CES
V
CBO
V
EBO
I
C
I
CM
I
B
I
BM
P
tot
T
j
T
stg
Value
30
30
10
500
800
100
200
330
150
-65 ... 150
Unit
V
Collector-emitter voltage
Collector-base voltage
Emitter-base voltage
DC collector current
Peak collector current
Base current
Peak base current
Total power dissipation,
T
S
= 81 °C
Junction temperature
Storage temperature
mA
A
mA
mW
°C
Thermal Resistance
Junction - soldering point
1)
R
thJS

210
K/W
1For calculation of
R
thJA
please refer to Application Note Thermal Resistance
1
Nov-30-2001

SMBTA64 Related Products

SMBTA64 SMBTA63
Description PNP Silicon Darlington Transistors PNP Silicon Darlington Transistors
Is it Rohs certified? conform to conform to
Maker Infineon Infineon
Parts packaging code SOT-23 SOT-23
package instruction SMALL OUTLINE, R-PDSO-G3 SMALL OUTLINE, R-PDSO-G3
Contacts 3 3
Reach Compliance Code compli compli
ECCN code EAR99 EAR99
Maximum collector current (IC) 0.5 A 0.5 A
Collector-emitter maximum voltage 30 V 30 V
Configuration DARLINGTON DARLINGTON
Minimum DC current gain (hFE) 20000 10000
JESD-30 code R-PDSO-G3 R-PDSO-G3
Humidity sensitivity level 1 1
Number of components 1 1
Number of terminals 3 3
Maximum operating temperature 150 °C 150 °C
Package body material PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR
Package form SMALL OUTLINE SMALL OUTLINE
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED
Polarity/channel type PNP PNP
Maximum power dissipation(Abs) 0.36 W 0.36 W
Certification status Not Qualified Not Qualified
surface mount YES YES
Terminal form GULL WING GULL WING
Terminal location DUAL DUAL
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED
Transistor component materials SILICON SILICON
Nominal transition frequency (fT) 125 MHz 125 MHz
