XOSM-532
www.vishay.com
Vishay Dale
Surface Mount Oscillator
FEATURES
• Size: 5.0 x 3.2 x 1.3 (mm)
• Miniature package
• Tri-state enable/disable
• HCMOS compatible
The XOSM-532 series is an ultra miniature package clock
oscillator with dimensions 5.0 mm x 3.2 mm x 1.3 mm. It is
mainly used in portable PC and telecommunication devices
and equipment.
• Tape and reel
• I
R
re-flow
• 2.5 V input voltage
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
STANDARD ELECTRICAL SPECIFICATIONS
PARAMETER
Frequency range
Frequency stability
(1)
SYMBOL
F
O
CONDITION
-
all conditions
VALUE
1.544 MHz to 100.000 MHz
± 25 ppm, ± 50 ppm, ± 100 ppm
0 ºC to 70 ºC
- 40 ºC to + 85 ºC (option)
- 55 ºC to + 125 ºC
2.5 V ± 10 %
± 5 ppm
7 mA max.
8 mA max.
20 mA max.
30 mA max.
40 %/60 % (45 %/55 % option)
6 ns max.
6 ns max.
90 % V
DD
min.
10 % V
DD
max.
30 pF max. (15 pF typ.)
10 ms max.
pin 1 = H or open (output active at pin 3)
pin 1 = L (high impedance at pin 3)
Operating temperature range
Storage temperature range
Power supply voltage
Aging (first year)
T
OPR
T
STG
V
DD
-
-
-
25 ºC ± 3 ºC
1.544 MHz to 9.999 MHz
10.000 MHz to 34.999 MHz
35.000 MHz to 49.999 MHz
50.000 MHz to 100.000 MHz
at
1
/
2
V
DD
10 % V
DD
to 90 % V
DD
90 % V
DD
to 10 % V
DD
-
-
-
-
-
Supply current
I
DD
Output symmetry
Rise time
Fall time
Output voltage
Output load
Start-up time
Pin 1, tri-state function
Sym
t
r
t
f
V
OH
V
OL
HCMOS load
t
s
Note
(1)
Include: 25 °C tolerance, operating temperature range, input voltage change, aging, load change, shock vibration
DIMENSIONS
in inches [millimeters]
0.047 ± 0.003
[1.20 ± 0.1]
0.197 ± 0.008
[5.0 ± 0.2]
0.047
[1.2]
#4
#1
PIN
#1
#2
#3
#4
CONNECTION
TRI-STATE/NC
GND
OUTPUT
V
DD
0.1 ± 0.003
[2.54 ± 0.1]
0.1
[2.54]
0.055
[1.4]
#3
0.130 ± 0.008
[3.3 ± 0.2]
#2
0.087
[2.2]
0.051 [1.3]
max.
0.047
[1.2]
Note
• A 0.01 μF bypass capacitor should be placed between V
DD
(pin 4) and GND (pin 2) to minimize power supply line noise
