F-215
ZW–06–13–L–D–787–118
DW–11–20–T–D–825
(2,54 mm) .100"
HW–14–08–G–S–300–100
DW, EW, ZW, HW SERIES
FLEXIBLE .025" SQ BOARD STACKERS
Mates with:
SSW, SSQ, ESW, ESQ,
CES, SLW, BSW, BCS,
SSM, IDSS, IDSD, HLE,
PHF, SMSD, SMSS
TYPE
STRIP
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
STACKER
HEIGHT
OTHER
OPTIONS
SPECIFICATIONS
For complete specifications
see www.samtec.com?DW,
www.samtec.com?EW,
www.samtec.com?ZW or
www.samtec.com?HW-TH
Insulator Material:
DW, EW, ZW: Black Glass
Filled Polyester
HW: Natural Liquid
Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27 µm) Ni
Operating Temp Range:
-55°C to +125°C with Gold
-55°C to +105°C with Tin
RoHS Compliant:
Yes
Lead–Free Solderable:
DW, EW, ZW: Wave Only
HW: Yes
–S
DW
= (2,79 mm)
.110" Tail
Specify LEAD STYLE
from chart
LEAD
STYLE
POST
(0,00).000
MIN
= Single
Row
–“XXX”
= Stacker
Height
–“XXX”
= ZW or HW
Tail Length
–D
= Double
Row
OAL
(10,92) .430
(13,46) .530
(18,54) .730
(21,08) .830
(23,62) .930
(26,16) 1.030
(31,24) 1.230
(36,32) 1.430
(16,00) .630
(11,30) .445
(12,19) .480
(33,78) 1.330
(28,70) 1.130
STACKER
HEIGHT
(5,08)
.200
MIN
(2,79)
.110
OVERALL
LENGTH
STACKER
HEIGHT
EW
= (8,38 mm)
.330" Tail
(OAL)
TAIL
(1,40) .055
MIN
– 07
– 08
– 09
–10
–11
–12
–13
–14
–15
–16
–17
–19
– 20
–T
= Triple
Row
ZW or
HW TAIL
LENGTH
(1,40)
.055
MIN
–Q
= Double
Row .200"
(5,08 mm)
row space
–LL
= Locking
Lead
(Shortest
dimension
between the
tail and the
post is the
end that will
be crimped.
Available
on tails from
(2,29 mm)
.090" to
(7,87 mm)
.310" only.)
Single row, 01
& 02 positions
& –Q row not
available
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
(8,38)
.330
–F
= Gold flash on contact,
Matte Tin on tail
–L
01 thru 50
50
(2.54) .100 x
No. of Positions
01
(2.54)
.100
02
(5,08)
.200
01
03
99
150
(5,08)
.200
01
148
100
(2.54)
.100
FILE NO: 090871_0_000
ZW
= Custom Tail
= 10µ" (0,25 µm) Gold on contact
area of longer tail,
Matte Tin on tail
–G
–S
–D
= 10µ" (0,25 µm) Gold on contact
area of longer tail,
Gold flash on balance
–“XXX”
= Polarized
Specify omitted
pin position
TAIL
LENGTH
–T
= Matte Tin
ALSO AVAILABLE
(MOQ Required)
• Other platings
Contact Samtec.
HW
= High Temp
Custom Tail
(7,52)
.296
–T
or –Q*
= Same as
-T except
middle
row
of pins
missing.
–Q*
B o a rd
S t a ck i n g
SO C KE T
PR O FI LE
PO ST
BO A RD
SP A C E
Note:
For added mechanical
stability, Samtec recommends
mechanical board spacers be
used in applications with gold or
selective gold plated connectors.
Contact ipg@samtec.com for
more information.
Note:
This Series is
non-standard, non-returnable.
(2.54)
.100
(2.54)
.100
O V ER A LL
LE
TH RU HO
PI N
(O A L)
ST A C KE R
HE IG H T
TAIL
LENGTH
(0,64) .025 SQ TYP
TA IL
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
