Y16235K00000J0L Overview

Ultra High Precision Z-Foil Surface Mount Power Resistors in TO-220 Configuration with TCR of ± 0.05 ppm/°C,

VPR220SZ (Z-Foil)
Vishay Foil Resistors
Ultra High Precision Z-Foil Surface Mount Power Resistors in
TO-220 Configuration with TCR of ± 0.05 ppm/°C,
Tolerance to ± 0.01 % and Power Rating to 8 W
FEATURES
Temperature Coefficient of Resistance (TCR):
± 0.05 ppm/°C typical (0 °C to + 60 °C)
Pb-free
Available
± 0.2 ppm/°C typical (- 55 °C to + 125 °C,
- 25 °C Ref.)
RoHS*
COMPLIANT
Tolerance: to ± 0.01 %
Power Coefficient of Resistance (PCR) “ΔR
due to self heating”: 5 ppm at rated power
Electrostatic Discharge (ESD) above 25 000 V
Load Life Stability: ± 0.005 % (25 °C, 2000 hours at Rated
Power)
Resistance Range: 5
Ω
to 10 kΩ
Power Rating: 8 W chassis mounted (per MIL-PRF-39009)
Non Inductive, Non Capacitive Design
Current Noise: < - 40 dB
Voltage Coefficient: < 0.1 ppm/W
Non Inductive: < 0.08 µH
Non Hot Spot Design
Thermal EMF: 0.05 µV/°C typical
Terminal Finishes Available: Lead (Pb)-free
Tin/Lead Alloy
For higher performances please contact us
Notes
1. Whichever is lower.
2. Heat sink chassis dimensions and requirements per
MIL-PRF-39009:
DIMENSION
L
W
1 ns
0.1 µH maximum: 0.03 µH typical
1.0 pF maximum: 0.5 pF typical
< 0.1 ppm/V
- 55 °C to + 150 °C
300 V. Not to exceed power rating.
0.15 µV/°C maximum (lead effect)
H
T
INCHES
6.00
4.00
2.00
0.04
mm
152.4
101.6
50.8
1.0
Any value at any tolerance available within resistance range
Model VPR220SZ, made from Vishay Bulk Metal
®
Z-Foil,
offers very low TCR, high stability, tight tolerance, low PCR
and fast response time in a small surface mount molded
resistor.
The Z-Foil technology provides a significant reduction of the
resistive components sensitivity to ambient temperature
variations and applied power changes. Designers now can
guarantee a high degree of stability and accuracy in fixed
resistor applications using solutions based on Vishay’s
revolutionary Z-Foil technology.
Our Application Engineering Department is available to
advise and make recommendations. For non-standard
technical requirements and special applications, please
contact us.
TABLE 1 - SPECIFICATIONS
Load Life Stability at 2000 h
Power Rating at + 25 °C
Current Noise
High Frequency Operation
Rise Time
Inductance
3)
(L)
Capacitance (C)
Voltage
Coefficient
4)
Operating Temperature
Range
Maximum Working Voltage
Thermal EMF
5)
± 0.05 % max
ΔR
under full rated
power at + 25 °C
8 W or 3 A
1)
on heat sink
2)
1.5 Wor 3 A
1)
in free air
Further derating not necessary.
< 0.010 µV (rms)/V of applied
voltage (- 40 dB)
3. Inductance (L) due mainly to the leads.
4. The resolution limit of existing test equipment (within the
measurement capability of the equipment, or “essentially zero”).
5. µV/°C relates to EMF due to lead temperature difference.
TABLE 2 - VPR220SZ
RESISTANCE RANGE (Ω)
50 to 10K
25 to < 50
10 to < 25
5 to < 10
Weight = 1 g Maximum
Note
1. Maximum specifications.
* Pb containing terminations are not RoHS compliant, exemptions may apply
www.foilresistors.com
1
For any questions, contact:
foil@vishaypg.com
Document Number: 63068
Revision: 25-Mar-10
TIGHTEST RESISTANCE TOLERANCE
± 0.01 %
± 0.02 %
± 0.05 %
± 0.1 %
± 2.5 ppm/°C
TCR
1)
- 55 °C to + 125 °C, Ref. + 25 °C
