Metal Oxide Varistors
MVS
Series
Surface Mount
MERITEK
Features
1. EIA size 0402 ~ 2220
2. Working voltage: 5.5 ~ 85 Vdc
3. -40 ~ +125°C operating temperature range
4. Bidirectional and symmetrical V/I characteristics
5. Multilayer ceramic construction technology
6. Cost effective
Recommended Applications
1. Cellular phones
2. Mother board / notebook
3. Scanner
4. Handheld devices
5. Digital video
6. Set-top box
Dimensions
Part No
MVS0402
MVS0603
MVS0805
MVS1206
MVS1210
L1
L1
(Unit:mm)
L
1.00±0.15
1.60±0.15
2.00±0.20
3.20±0.30
3.20±0.30
4.50±0.40
5.70±0.40
W
0.50± 0.10
0.80±0.05
1.25±0.20
1.60±0.20
2.50±0.25
3.20±0.30
5.00±0.30
T
0.60max
0.95max
1.20max
1.50max
1.50max
1.50max
2.00max
L1
0.20±0.10
0.25±0.15
0.40±0.20
0.50±0.20
0.50±0.20
0.60±0.30
0.60±0.30
MVS1812
MVS2220
Characteristics
Varistor Voltage
Max
Allowable
Voltage
V
1mA
(V)
MVS0402B080M
MVS0603B080M
MVS0805B080M
MVS1206B080M
MVS1210B080M
MVS1812B080M
MVS2220B080M
MVS0402B110M
MVS0603B110M
MVS0805B110M
MVS1206B110M
MVS1210B110M
MVS1812B110M
MVS2220B110M
MVS0402B12RM
MVS0603B12RM
MVS0805B12RM
8
8
8
8
8
8
8
11
11
11
11
11
11
11
12.5
12.5
12.5
V
1mA
(±%)
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
V
AC(rms)
(V)
4
4
4
4
4
4
4
6
6
6
6
6
6
6
7
7
7
V
DC
(V)
5.5
5.5
5.5
5.5
5.5
5.5
5.5
8
8
8
8
8
8
8
9
9
9
V
p
(V)
19
19
19
17
17
17
17
27
27
27
25
25
25
25
30
30
30
Max.
Clamping Voltage
(8/20 s)
Max.
Surge Current
(8/20 s)
I
max
(A)
10
30
60
150
250
500
1000
10
30
60
200
300
500
1200
10
30
60
Max.
Energy
(10/1000 s)
W
max
(J)
0.05
0.1
0.1
0.3
0.4
0.8
1.4
0.05
0.1
0.2
0.4
0.7
1.0
3.6
0.05
0.1
0.2
Reference
Rate Power Capacitance
@1KHz
P
(W)
0.003
0.003
0.005
0.008
0.01
0.015
0.02
0.003
0.003
0.005
0.008
0.01
0.015
0.02
0.003
0.003
0.005
C
(PF)
230
950
1500
4800
8200
18000
29000
160
600
1400
3900
7500
15000
25000
140
570
1100
Part No.
I
p
(A)
1.0
1.0
1.0
1.0
2.5
5.0
10
1.0
1.0
1.0
1.0
2.5
5.0
10
1.0
1.0
1.0
Specifications are
subject to change without notice.
rev: 5b
