* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
XA connector high box type, with
19.5mm mounting height and with 6.9mm
thickness.
• Header for 2.5mm pitch XA connector for use
specifically with resin coated ("potted") PC
boards
• Interchangeability
Standards ––––––––––––––––––––––
1
Certified LR20812
2
R9851220
0
Recognized E60389
PC board layout (viewed from component side) and Assembly layout
Without a boss
With a boss
（6.9）
1.6
±0.05
φ1.2
＋0.1
0
2.5
±0.05
φ0.9
＋0.1
0
＋0.1
φ0.9
0
2.5
±0.05
1.6
±0.05
Note:1. Tolerances are non-cumulative:
±
0.05mm for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing method. The dimensions above should serve as a guideline. Contact JST for details.
1
（19.5）
XA CONNECTOR High box type
Contact
Model No.
1.9
mm
2
Applicable wire
Q'ty / reel
AWG#
Insulation O.D. (mm)
28∼22
0.8∼1.9
8,000
SXA-001T-P0.6
0.08∼0.33
Material and Finish
6.5
3.1
1.3 1.6
Phosphor bronze, tin-plated (reflow treatment)
RoHS compliance
2.3
Contact
Crimping
machine
Crimp applicator
MKS-L
*MKS-SC
Applicator
Dies
Crimp applicator with dies
SXA-001T-P0.6
AP-K2N
MK/SXA/M-001-06 APLMK SXA/M001-06
SC/SXA/M-001-06 APLSC SXA/M001-06
Note: *Strip-crimp applicator
Housing
Standard type
B
2.5 2.4
6.9
Circuits
2
3
4
9.5
Model No.
Retainer
Standard
mountable
type
type
XAP-02V-1
XAP-03V-1
XAP-04V-1
XAP-05V-1
XAP-06V-1
XAP-07V-1
XAP-08V-1
XAP-09V-1
XAP-10V-1
XAP-11V-1
XAP-12V-1
XAP-13V-1
XAP-14V-1
XAP-15V-1
XARP-02V
XARP-03V
XARP-04V
XARP-05V
XARP-06V
XARP-07V
XARP-08V
XARP-09V
XARP-10V
XARP-11V
XARP-12V
XARP-13V
XARP-14V
XARP-15V
Dimensions (mm)
A
2.5
5.0
7.5
10.0
12.5
15.0
17.5
20.0
22.5
25.0
27.5
30.0
32.5
35.0
B
7.3
9.8
12.3
14.8
17.3
19.8
22.3
24.8
27.3
29.8
32.3
34.8
37.3
39.8
Q'ty / bag
Retainer
Standard mountable
type
type
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
500
500
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
5
6
7
A
Circuit No.1
5.8
8
9
10
Retainer mountable type
B
2.5 2.4
7.4
0.6
11
12
13
14
15
Material
10.5
PA 66, UL94V-0, natural (white)
RoHS compliance
A
Circuit No.1
5.8
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
