Verpackt in Gurtverpackung
-
Tape on Reel Packaging
Verpackungseinheit: 75 Stück -
Packaging unit: 75 pcs
PIN 1
Abspulrichtung -
Reel off Direction
7,2
150
12,84
±0,25
330
44,5
44
24
9,45
Layout - Vorschlag
PCB - Layout proposal
13,3
6,9
±0,2
1,5
-0,03
+0,2
9
±0,05
3,54
1
4
5
1,1
-0,03
2,25
7,9
2
0,03
-0,03
+0,07
+0,1
+0,1
18,9
5,4
3,54
3
5,1
1,3
1,3
1,4
-0,05
9
±0,1
1
-0,05
10,5
354130
254319
5 Pol. B Cod.
5 Pol. B Cod.
Gurtverpackung /
tape on reel
Schüttgut 100 Stck./
bulk 100 pcs.
max. 12,6
Koplanarität aller Kontakte und Clip <=0,1mm
coplanarity of all contacts and clips <=0,1mm
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
Ident-Nr.
Tolerances
All Dimensions
in mm
Typ
5:1
Bemerkung
Information:
Scale
1
5
4
2
3
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
c
Index
18.01.2011
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
Messerleiste M12 5pol.
B Cod.10,5mm o.Dichtung
www.ERNI.com
Class
254318
M12
I
A3
