Clock Oscillators Surface Mount Type
KC7050P-P2/ KC7050P-P3 Series
LV-PECL/ 3.3V or 2.5V/ 7.0×5.0mm
Features
• Miniature ceramic package
• Highly reliable with seam welding
• LV-PECL output
• Supply voltage V
CC
=3.3V
•
±25×10
−
6
available
How to Order
KC7050P 125.000 P 3 0 J 00
①
②
③④⑤⑥ ⑦
Table 1
Operating
Freq. Tol.
Note
−
6
Temperature
Code
×
10
Range (
°
C)
±
50
0
Standard specifications
±
30 0 to
+70
S
±
25
U
With only certain
±100
F
−40
to
+85
frequencies
±
50
G
±
50
−40
to
+105
6
①
Type (7.0×5.0mm SMD)
②
Output Frequency
③
Output Type (LV-PECL)
④
Supply Voltage (3 : 3.3V or 2 : 2.5V)
⑤
Frequency Tolerance (See Table 1)
⑥
Symmetry/ INH Function
(45/ 55%, Stand-by)
J : Low Phase Noise
E : Standard
Customer Special Model Suffix
⑦
(STD Specification is “00”)
Packaging (Tape & Reel 1000 pcs./ reel)
RoHS Compliant
Specifications
Item
Output Frequency Range
Note1
Symbol
fo
Specifications
KC7050P-P2
KC7050P-P3
25 to 175
±
50/
−
40 to
+
105
°C
±
100/
−
40 to
+
85
°C
±
50/
−
40 to
+
85
°C
±
50/ 0 to
+
70
°C
±
30/ 0 to
+
70
°C
±
25/ 0 to
+
70
°C
−
55 to
+
125
0 to
+
70
−
40 to
+
105
−
0.5 to
+
5.0
+
2.375 to
+
2.625
+
2.97 to
+
3.63
90 max.
30 max.
50
±
5
0.6 max.
V
CC
−1.810
to V
CC
−1.405
V
CC
−1.830
to V
CC
−1.305
V
CC
−1.025
to V
CC
−0.740
V
CC
−1.085
to V
CC
−0.880
V
CC
−1.810
to V
CC
−1.620
V
CC
−1.830
to V
CC
−1.555
V
CC
−1.025
to V
CC
−0.880
V
CC
−1.085
to V
CC
−0.900
Units
MHz
Initial tolerance, Operating temperature
range, Rated power supply voltage
ppm
change, Load change, Aging (1 year
@25°C), Shock and vibration
°C
°C
V
V
mA
µA
%
ns
V
V
ohm
V
V
ns
ms
ms
ps
ps
ps
Standard Specifications
Extend (Option)
Conditions
Frequency Tolerance
f
_tol
Storage Temperature Range
Operating Temperature Range
Max. Supply Voltage
Supply Voltage
Current Consumption
Stand-by Current
Symmetry
Rise/ Fall Time
(20% V
CC
to 80% V
CC
Maximum
Loaded)
Low Level Output Voltage
Note2
High Level Output Voltage
Note2
Output Load
Input Voltage Range
Low Level Input Voltage
High Level Input Voltage
Disable Time
Enable Time
Start-up Time
Deterministic Jitter
1 Sigma Jitter
Peak to Peak Jitter
T
_stg
T
_use
—
V
CC
I
CC
I
_std
SYM
tr/ tf
V
OL
V
OH
RL
V
IN
V
IL
V
IH
t
_dis
t
_ena
t
_str
DJ
J
Sigma
J
PK-PK
50ohm @crossing point
50ohm
50
0 to V
CC
30% V
CC
max.
70% V
CC
min.
150 max.
10 max.
10 max.
2 max.
4 max.
30 max.
@Minimum operating voltage to be 0 sec.
Measured with Wavecrest SIA-3000
Note : All electrical characteristics are defined at the maximum load and operating temperature range.
Note1: Please contact us for inquiry about operating temperature range, available frequencies and other conditions.
Note2: DC characteristic
Dimensions
7.0
1.4
0.6
(Unit: mm)
Recommended Land Pattern
5.08
(Unit: mm)
2.46
5.0
#4
#3
1.17
#5
#2
#6
#1
#1
#2
#3
#4
#5
#6
Pad Connections
INH
NC
Case GND
Output
Complementary Output
V
CC
0.75
2.54
1.6
2.54
Plating: Ni+Au
Tolerance:
±0.2
INH Function
Pad1
Pad4/ Pad5 (Output)
Open
Active
"H" Level
Active
"L" Level High Z (No-Oscillation)
3.6
2.54
1.6
Note: A capacitor of value 0.01μF and 10μF
between V
CC
and GND is recommended.
1.6
