YTE-102-03-M-5-375 datasheet, PDF

Datasheet> All Categories > The connector> The connector> YTE-102-03-M-5-375

YTE-102-03-M-5-375: DescriptionBoard Stacking Connector, 10 Contact(s), 5 Row(s), Female, Straight, 0.079 inch Pitch, Solder Terminal, Locking, Black Insulator, Socket, ROHS COMPLIANT; CategoryThe connector The connector; File Size584KB，1 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/; Environmental Compliance

Download Datasheet Parametric View All

YTE-102-03-M-5-375 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	YTE-102-03-M-5-375	-	-	View	Buy Now

YTE-102-03-M-5-375 Overview

Board Stacking Connector, 10 Contact(s), 5 Row(s), Female, Straight, 0.079 inch Pitch, Solder Terminal, Locking, Black Insulator, Socket, ROHS COMPLIANT

YTE-102-03-M-5-375 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1022418031
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
Factory Lead Time	2 weeks
Other features	FLEXYZ
body width	0.395 inch
subject depth	0.375 inch
body length	0.17 inch
Body/casing type	SOCKET
Connector type	BOARD STACKING CONNECTOR
Contact to complete cooperation	GOLD (20) OVER NICKEL (50)
Contact completed and terminated	Tin (Sn) - with Nickel (Ni) barrier
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	10 mΩ
Contact style	SQ PIN-SKT
DIN compliance	NO
Durability	100 Cycles
Filter function	NO
IEC compliance	NO
maximum insertion force	.5004 N
Insulator color	BLACK
insulator material	LIQUID CRYSTAL POLYMER (LCP)
JESD-609 code	e3
MIL compliance	NO
Plug contact pitch	0.079 inch
Match contact row spacing	0.079 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	5
Number of rows loaded	5
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	2.0066 mm
Plating thickness	20u inch
polarization key	POLARIZED HOUSING
reliability	COMMERCIAL
Terminal length	0.148 inch
Terminal pitch	2 mm
Termination type	SOLDER
Total number of contacts	10
Evacuation force-minimum value	.278 N

Preview

Download Datasheet

View All

F-218 SUPPLEMENT

YTE–110–02–G–6–500

YTE–120–03–G–5–700

YTE–114–03–M–Q–368

(2.00 mm) .0787"

YTE SERIES

HIGH-DENSITY ELEVATED SOCKET STRIP

SPECIFICATIONS

For complete specifications

see www.samtec.com?YTE

Insulator Material:

Black Liquid Crystal Polymer

Contact Material:

Phosphor Bronze

Operating Temp Range:

-55 °C to +105 °C

Plating:

Sn or Au over

50 µ" (1.27 µm) Ni

Insertion Depth:

(2.62 mm) .103" to

(5.03 mm) .198" with

(0.38 mm) .015" wipe

Max Cycles:

100 with 10 µ" (0.25 µm) Au

RoHS Compliant:

Yes

Lead–Free Solderable:

Wave only

Mates with:

YTT, YTW, YTE

Body Height

from (8.64 mm)

.340" to

(20.32 mm)

.800"
