YTE-119-03-G-Q-340 datasheet, PDF

Datasheet> All Categories > The connector> The connector> YTE-119-03-G-Q-340

YTE-119-03-G-Q-340: DescriptionBoard Stacking Connector, 76 Contact(s), 4 Row(s), Female, Straight, 0.079 inch Pitch, Solder Terminal, Locking, Black Insulator, Socket, ROHS COMPLIANT; CategoryThe connector The connector; File Size582KB，1 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/; Environmental Compliance

Download Datasheet Parametric View All

YTE-119-03-G-Q-340 Overview

Board Stacking Connector, 76 Contact(s), 4 Row(s), Female, Straight, 0.079 inch Pitch, Solder Terminal, Locking, Black Insulator, Socket, ROHS COMPLIANT

YTE-119-03-G-Q-340 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1022418436
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
Other features	FLEXYZ
body width	0.316 inch
subject depth	0.34 inch
body length	1.513 inch
Body/casing type	SOCKET
Connector type	BOARD STACKING CONNECTOR
Contact to complete cooperation	GOLD (20) OVER NICKEL (50)
Contact completed and terminated	Gold (Au) - with Nickel (Ni) barrier
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	10 mΩ
Contact style	SQ PIN-SKT
DIN compliance	NO
Durability	100 Cycles
Filter function	NO
IEC compliance	NO
maximum insertion force	.5004 N
Insulator color	BLACK
insulator material	LIQUID CRYSTAL POLYMER (LCP)
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	YTE
Plug contact pitch	0.079 inch
Match contact row spacing	0.079 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	4
Number of rows loaded	4
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	2.0066 mm
Plating thickness	20u inch
polarization key	POLARIZED HOUSING
reliability	COMMERCIAL
Terminal length	0.148 inch
Terminal pitch	2 mm
Termination type	SOLDER
Total number of contacts	76
Evacuation force-minimum value	.278 N

Preview

Download Datasheet

View All

F-218 SUPPLEMENT

YTE–110–02–G–6–500

YTE–120–03–G–5–700

YTE–114–03–M–Q–368

(2.00 mm) .0787"

YTE SERIES

HIGH-DENSITY ELEVATED SOCKET STRIP

SPECIFICATIONS

For complete specifications

see www.samtec.com?YTE

Insulator Material:

Black Liquid Crystal Polymer

Contact Material:

Phosphor Bronze

Operating Temp Range:

-55 °C to +105 °C

Plating:

Sn or Au over

50 µ" (1.27 µm) Ni

Insertion Depth:

(2.62 mm) .103" to

(5.03 mm) .198" with

(0.38 mm) .015" wipe

Max Cycles:

100 with 10 µ" (0.25 µm) Au

RoHS Compliant:

Yes

Lead–Free Solderable:

Wave only

Mates with:

YTT, YTW, YTE

Body Height

from (8.64 mm)

.340" to

(20.32 mm)

.800"
