£)nc.
20 STERN AVE.
SPRINGFIELD, NEW JERSEY 07081
U.S.A.
FEATURES
• Voltage Range 7.5 -75 Volts
• 1500 Wart Peak Pulse Power
• 20 Watt Steady State 9 75°C
• 15 Watt Steady State
9
100°C
• Glass passivated junction
• 1500 Watt surge capability at 1 ms
• Typically IR less than 5 uA above 10V
• Excellent clamping capability
• Stud cathode & stud anode
• Operating temperature -55°C to +175°C
•100% tested
BZY93 Series
MECHANICAL CHARACTERISTICS
• Case: Hermetically sealed DO-4 outline
TELEPHONE: (973) 376-2922
(212)227-6005
FAX: (973) 376-8960
• Finish: All external surfaces are corrosion resistant and
terminal solderable
• Polarity: Indicated by direction of zener symbol
• Weight: 4.2 grammes excluding mounting kit (approx)
• Torque setting 13inch/lb
ELECTRICAL DATA
• Forward voltage Vfl.SV max 9 IFS 5A 300uS square
wave pulse
• Vz measured with pulse
*
100uS and duty cycle * 0.001
• Rz determined with DC plus 10% superimposed AC O 1KHz
ELECTRICAL SPECIFICATION @ Tamb 25°C
Stud
Cathode
Part Number
BZY93C7V5
BZY93C8V2
BZY93C9V1
BZY93C10
BZY93C1 1
BZY93C12
BZY93C13
BZY93C15
BZY93C16
BZY93C18
BZY93C20
BZY93C22
BZY93C24
BZY93C27
Stud
Anode
Part Number
BZY93C7V5R
BZY93C8V2R
BZY93C9V1R
BZY93C10R
BZY93C11R
BZY93C12R
BZY93C13R
BZY93C15R
BZY93C16R
BZY93C18R
BZY93C20R
BZY93C22R
BZY93C24R
BZY93C27R
BZY93C30R
BZY93C33R
BZY93C36R
BZY93C39R
BZY93C43R
BZY93C47R
BZY93C51R
BZY93C56R
BZY93C62R
BZY93C68R
BZY93C75R
Zener Voltage
Vz (Volts) e iz
MIN
7.0
7.7
8.5
9.4
10.4
11.4
12.4
13.8
15.3
16.8
18.8
20.8
22.7
25.1
28.0
31.0
34.0
37.0
40.0
44.0
48.0
52.0
58.0
64.0
70.0
MAX
7.9
8.7
9.6
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.2
23.3
25.9
28.9
32.0
35.0
38.0
41.0
46.0
50.0
54.0
60,0
66.0
72.0
79.0
Iz
(A)
2.0
2.0
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
BZY93C30
BZY93C33
BZY93C36
BZY93C39
BZY93C43
BZY93C47
BZY93C51
BZY93C56
BZY93C62
BZY93C68
BZY93C75
Zener
Resistance
Rz (Q) @ Iz
Max
Typ
0.04
0.3
0.05
0.3
0.07
0.5
0.09
0.5
0.08
1.0
0.08
1.0
0.08
1.0
0.10
1.2
0,18
1.2
0.20
1.5
0.20
1.5
0.21
1.8
0.22
2.0
0.25
2.0
0.30
2.5
0.75
4.0
0.85
5.0
0.90
6,5
1.00
7.0
1.00
7.5
1.20
8.0
1.30
9.0
1.50
10.0
1,80
11.0
2.00
15,0
Maximum Reverse
Leakage IR @ VR
(mA)
0.10
0.10
(Volts)
5.1
o;os
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
O.OS
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
Max 20.32
Max 11.5
All dimensions in mm
STUD CATHODE NORMAL
STUD ANODE REVERSE
BZY93C I I I I
Voltage
= Stud Cathode Normal -
R = Stud Anode Reverse
U
NJ Semi-Conductors reserves the right to change test conditions, parameter limits and package dimensions without
notice. Information furnished by NJ Semi-Conductors is believed to be both accurate and reliable at the time of going
to press. However, NJ Semi-Conductors assumes no responsibility for any errors or omissions discovered in its use
NJ Semi-Conductors encourages customers to verify that datasheets are current before placing orders
Quality Semi-Conductors
