using MOSFET semiconductor technology, designed to protect
against faults caused by short circuits, AC power cross,
induction and lightning surges.
The TBU
®
high speed protector, triggering as a function of
the MOSFET, blocks surges and provides an effective barrier
behind which sensitive electronics are not exposed to large
voltages or currents during surge events. The TBU
®
device is
provided in a surface mount DFN package and meets industry
standard requirements such as RoHS and Pb Free solder
reflow profiles.
Absolute Maximum Ratings (T
amb
= 25 °C)
Symbol
V
imp
V
rms
T
op
T
stg
Parameter
K.20, K.20E, K.21, K.21E, K.45
Value
P500-Gxxx-WH
P850-Gxxx-WH
P500-Gxxx-WH
P850-Gxxx-WH
500
850
300
425
-40 to +85
-65 to +150
Unit
V
V
°C
°C
Maximum protection voltage for impulse faults with rise time
≥
1 µsec
Maximum protection voltage for continuous V
rms
faults
Operating temperature range
Storage temperature range
Electrical Characteristics (T
amb
= 25 °C)
Symbol
Parameter
Maximum current through the device that will not cause
current blocking
P500-G120-WH
P500-G200-WH
P850-G120-WH
P850-G200-WH
P500-G120-WH
P500-G200-WH
P850-G120-WH
P850-G200-WH
P500-G120-WH
P500-G200-WH
P850-G120-WH
P850-G200-WH
50
150
275
150
275
200
400
200
400
55
2
1
0.7
22
Min.
Typ.
Max.
100
200
100
200
Unit
I
op
mA
I
trigger
Typical current for the device to go from normal operating
state to protected state
mA
I
out
R
device
R
bal
t
block
I
quiescent
V
reset
Maximum current through the device
mA
Ω
Ω
µs
mA
V
Series resistance of the TBU
®
device
Line-to line series resistance difference between two TBU
®
devices
Maximum time for the device to go from normal operating
state to protected state
Current through the triggered TBU
®
device with 50 Vdc circuit
voltage
Voltage below which the triggered TBU
®
device will transition to
normal operating state
The P-G series TBU
®
devices are bidirectional; specifications are valid in both directions.
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
Applications
■
Sensor protection
■
Signal line protection
P500-G and P850-G Series Dual TBU
®
High-Speed Protectors
Typical Performance Characteristics
V-I Characteristics
+I
Time to Block vs. Fault Current
1
0.1
Itrigger
Time to Block (sec)
0.01
0.001
0.0001
0.00001
0.000001
0.0000001
0.1
1
10
100
1000
-Vreset
+V
Vreset
-Itrigger
Fault Current (A)
Trigger Current Temperature
140
120
% of Trigger Current
100
80
60
40
20
-40
-20
0
20
40
60
80
Temperature (°C)
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
P500-G and P850-G Series Dual TBU
®
High-Speed Protectors
Operational Characteristics
The graphs below demonstrate the operational characteristics of the TBU
®
device. For each graph the fault voltage, protected side voltage,
and current is presented.
Tip
TEST CONFIGURATION DIAGRAM
Ring
Pxxx-G
P500-G Lightning, 500 V
P850-G Lightning, 850 V
3
Equipment
V1
V2
3
400 mA/div.
2
2
1
1
1 µs/div.
Ch1 V1
Ch2 V2
Ch3 Current
Ch1 V1
1
µ
s/div.
Ch2 V2
Ch3 Current
P500-G Power Fault, 120 Vrms, 25 A
P850-G Power Fault, 230 Vrms, 25 A
3
3
2
2
200 mA/div.
1
4 ms/div.
Ch1 V1
Ch2 V2
Ch3 Current
Ch1 V1
100 V/div.
1
4 ms/div.
Ch2 V2
Ch3 Current
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
200 mA/div.
100 V/div.
200 mA/div.
100 V/div.
P500-G and P850-G Series Dual TBU
®
High-Speed Protectors
Product Dimensions
P500-Gxxx
J
B
C
E
K
K
F
J
E
N
Dim.
A
4
A
5
2
6
H
B
M
3
1
C
D
PIN 1
D
N
E
TOP VIEW
SIDE VIEW
K
J
BOTTOM VIEW
F
K
L
L
F
E
G
J
N
P850-Gxxx
B
C
G
Min.
3.40
(.139)
5.90
(.232)
0.80
(.031)
0.000
(.000)
1.15
(.045)
1.05
(.041)
--
1.10
(.043)
0.375
(.015)
0.70
(.028)
--
P500-G
Typ.
4.00
(.157)
6.00
(.236)
0.85
(.033)
0.025
(.001)
1.25
(.049)
1.15
(.045)
--
1.20
(.047)
0.425
(.017)
0.75
(.030)
--
Max.
4.10
(.161)
6.10
(.240)
0.90
(.035)
0.050
(.002)
1.35
(.053)
1.25
(.049)
--
1.30
(.051)
0.475
(.019)
0.80
(.031)
--
G
H
E
4A
A
4
3
5
2
6
1
6A
H H
J
M
3A
1A
K
L
M
N
PIN 1
D
N
TOP VIEW
SIDE VIEW
BOTTOM VIEW
Pads 1A and 1 are internally connected; the same for pads 3A with 3, 4A with 4, and 6A with 6.
This allows for one PCB layout to accommodate the P500 or P850.
0.70
0.75 0.80
(.028) (.030) (.031)
0.375 0.425 0.475
(.015) (.017) (.018)
DIMENSIONS:
P850-G
Min. Typ. Max.
3.40 4.00 4.10
(.139) (.157) (.161)
8.15 8.25 8.35
(.321) (.325) (.329)
0.80 0.85 0.90
(.031) (.033) (.035)
0.000 0.025 0.050
(.000) (.001) (.002)
1.15 1.25 1.35
(.045) (.049) (.053)
1.05 1.15 1.25
(.041) (.045) (.049)
0.725 0.825 0.925
(.029) (.032) (.036)
1.10 1.20 1.30
(.043) (.047) (.051)
0.375 0.425 0.475
(.015) (.017) (.019)
0.25 0.30 0.35
(.010) (.012) (.014)
0.70 0.75 0.80
(.028) (.030) (.031)
0.70 0.75 0.80
(.028) (.030) (.031)
0.375 0.425 0.475
(.015) (.017) (.018)
MM
(INCHES)
Recommended Pad Layout
P500-Gxxx
1.225
(.048) 1.275
(.050)
0.75
(.030)
1.15
(.045)
0.375
(.015)
Pad Designation
Pad #
Apply
1
Tip In
2
NC
3
Tip Out
4
Ring Out
5
NC
6
Ring In
NC = Solder to PCB; do not make electrical
connection, do not connect to ground.
Block Diagram
P500-Gxxx
6
4
1
3
P850-Gxxx
1.225
(.048)
0.85
(.033)
1.25
(.049)
1.15
(.045)
0.375
(.015)
0.30
(.012)
0.75
(.030)
Pad #
1A
1
2
3
3A
Pad Designation
Apply
Pad #
Apply
Tip In
4A
Ring Out
Tip In
4
Ring Out
NC
5
NC
Tip Out
6
Ring In
Tip Out
6A
Ring In
P850-Gxxx
6 & 6A
4 & 4A
NC = Solder to PCB; do not make electrical
connection, do not connect to ground.
1 & 1A
3 & 3A
TBU
®
devices have matte-tin termination finish. Suggested layout should use non-solder mask
define (NSMD). Recommended stencil thickness is 0.10-0.12 mm (.004-.005 in.) with stencil
opening size 0.025 mm (.0010 in.) less than the device pad size. As when heat sinking any power
device, it is recommended that, wherever possible, extra PCB copper area is allowed. For
minimum parasitic capacitance, do not allow any signal, ground or power signals beneath any of
the pads of the device.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
P500-G and P850-G Series Dual TBU
®
High-Speed Protectors
Thermal Resistances
Part #
P500-G
Symbol
R
th(j-a)
Parameter
Junction to leads (package)
Junction to leads (per TBU
®
device)
Junction to leads (package)
Junction to leads (per TBU
®
device)
Value
113
236
119
215
Unit
°C/W
°C/W
°C/W
°C/W
P850-G
R
th(j-a)
Reflow Profile
Profile Feature
Average Ramp-Up Rate (Tsmax to Tp)
Preheat
- Temperature Min. (Tsmin)
- Temperature Max. (Tsmax)
- Time (tsmin to tsmax)
Time maintained above:
- Temperature (TL)
- Time (tL)
Peak/Classification Temperature (Tp)
Time within 5 °C of Actual Peak Temp. (tp)
Ramp-Down Rate
Time 25 °C to Peak Temperature
Pb-Free Assembly
3 °C/sec. max.
150 °C
200 °C
60-180 sec.
217 °C
60-150 sec.
260 °C
20-40 sec.
6 °C/sec. max.
8 min. max.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
