1008 CHIP INDUCTORS
Outgassing Compliant Chip Inductors
AS413RAA
■
High SRF and excellent Q values
■
Tight tolerances, many values at 1%
■
39 inductance values from 10 nH to 8.2 µH
Current Derating
120
110
100
90
80
70
60
50
30
20
10
0
40
Typical Q vs Frequency
120
100
100
90
80
100 nH
12 nH
Percent of rated
I
rms
Features high temperature materials that pass NASA low
outgassing specifications and allow operation in ambi-
ent temperatures up to 155°C. The leach-resistant base
metalization with tin-lead (Sn-Pb) terminations ensures
the best possible board adhesion.
47 nH
-40
-20
0
20
25°C
40
60
80
100
120
140 160
Ambient temperature (°C)
Q Factor
70
60
50
40
30
20
10
0
10
100
1000
10000
330 nH
750 nH
1800 nH
A
B
overall
F
G
F
E
terminal
C
I
J
I
H
D
Terminal wraparound:
approx 0.015/0,38 both ends
Frequency (MHz)
Suggested
Land Pattern
Typical L vs Frequency
A max B max
0.115 0.110
2,92
2,79
C max D ref
0.080 0.020
2,03
0,51
E
F
0.080 0.020
2,03 0,51
G
H
I
J
0.060 0.100 0.040 0.050
1,52 2,54 1,02 1,27
Note: Dimensions are before solder application. For maximum overall
dimensions including solder, add 0.0025 in / 0,064 mm to
B
and
0.006 in / 0,15 mm to
A
and
C.
Core material
Ceramic
Terminations
Tin-lead (63/37) over silver-platinum-glass frit
Ambient temperature
–55°C to +125°C with
Imax
current, +125°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Tape and reel packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +155 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
2000 per 7″ reel
Plastic tape: 8 mm wide, 0.3 mm thick, 4 mm pocket spacing,
2.0 mm pocket depth
®
Specifications subject to change without notice.
Please check our website for latest information.
Document AS101-1
Revised 08/04/11
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2012
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
1008 CHIP INDUCTORS
AS413RAA Series (1008)
Part number
1
AS413RAA100_SZ
AS413RAA120_SZ
AS413RAA150_SZ
AS413RAA180_SZ
AS413RAA220_SZ
AS413RAA270_SZ
AS413RAA330_SZ
AS413RAA390_SZ
AS413RAA470_SZ
AS413RAA560_SZ
AS413RAA680_SZ
AS413RAA820_SZ
AS413RAA101_SZ
AS413RAA121_SZ
AS413RAA151_SZ
AS413RAA181_SZ
AS413RAA221_SZ
AS413RAA271_SZ
AS413RAA331_SZ
AS413RAA391_SZ
AS413RAA471_SZ
AS413RAA561_SZ
AS413RAA621_SZ
AS413RAA681_SZ
AS413RAA751_SZ
AS413RAA821_SZ
AS413RAA911_SZ
AS413RAA102_SZ
AS413RAA122_SZ
AS413RAA152_SZ
AS413RAA182_SZ
AS413RAA222_SZ
AS413RAA272_SZ
AS413RAA332_SZ
AS413RAA392_SZ
AS413RAA472_SZ
AS413RAA562JSZ
AS413RAA682JSZ
AS413RAA822JSZ
Inductance
2
(nH)
10 @ 50 MHz
12 @ 50 MHz
15 @ 50 MHz
18 @ 50 MHz
22 @ 50 MHz
27 @ 50 MHz
33 @ 50 MHz
39 @ 50 MHz
47 @ 50 MHz
56 @ 50 MHz
68 @ 50 MHz
82 @ 50 MHz
100 @ 25 MHz
120 @ 25 MHz
150 @ 25 MHz
180 @ 25 MHz
220 @ 25 MHz
270 @ 25 MHz
330 @ 25 MHz
390 @ 25 MHz
470 @ 25 MHz
560 @ 25 MHz
620 @ 25 MHz
680 @ 25 MHz
750 @ 25 MHz
820 @ 25 MHz
910 @ 25 MHz
1000 @ 25 MHz
1200 @ 7.9 MHz
1500 @ 7.9 MHz
1800 @ 7.9 MHz
2200 @ 7.9 MHz
2700 @ 7.9 MHz
3300 @ 7.9 MHz
3900 @ 7.9 MHz
4700 @ 7.9 MHz
5600 @ 7.9 MHz
6800 @ 7.9 MHz
8200 @ 7.9 MHz
Percent
tolerance
5,2
5,2
5,2
5,2
5,2,1
5,2
5,2
5,2
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5
5
5
Q min
3
44 @ 500 MHz
45 @ 500 MHz
50 @ 500 MHz
50 @350 MHz
55 @ 350 MHz
55 @ 350 MHz
60 @ 350 MHz
60 @ 350 MHz
65 @ 350 MHz
60 @ 350 MHz
46 @ 100 MHz
48 @ 100 MHz
37 @ 100 MHz
40 @ 100 MHz
40 @ 100 MHz
38 @ 100 MHz
40 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
40 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
35 @ 50 MHz
34 @ 50 MHz
32 @ 50 MHz
28 @ 50 MHz
28 @ 50 MHz
19 @ 7.9 MHz
20 @ 7.9 MHz
20 @ 7.9 MHz
20 @ 7.9 MHz
13 @ 2.5 MHz
14 @ 2.5 MHz
14 @ 2.5 MHz
14 @ 2.5 MHz
SRF min
4
(MHz)
3060
2680
2220
2200
2100
1380
1600
1420
1420
1140
1140
940
900
840
740
680
580
540
500
480
400
360
360
345
335
310
280
280
220
180
160
150
110
110
85
75
20
40
25
DCR max
5
(Ohms)
0.08
0.09
0.10
0.11
0.12
0.13
0.14
0.15
0.16
0.18
0.20
0.22
0.56
0.63
0.70
0.77
0.84
0.91
1.05
1.12
1.19
1.33
1.40
1.47
1.54
1.61
1.68
1.75
2.0
2.3
2.6
2.8
3.2
3.4
3.6
4.0
4.0
4.9
6.5
Imax
(mA)
900
900
850
900
900
900
850
850
820
780
710
710
440
410
400
390
370
330
330
310
280
280
270
270
270
250
250
230
230
220
210
190
180
160
160
160
150
150
110
1. When ordering, please specify
tolerance
and
testing
codes:
AS413RAA102GSZ
Tolerance: F
= 1%
G
= 2%
J
= 5%
Testing:
Z
= COTS
H
= Screening per Coilcraft CP-SA-10001
N
= Screening per Coilcraft CP-SA-10003
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/HP 4286A impedance analyzer or equivalent with Coilcraft-provided correlation pieces.
3. Q measured using an Agilent/HP 4291A with an AgilentHP 16197A test fixture or equivalents.
4. SRF measured using an Aglilent/HP 8753ES network analyzer or equivalent and a Coilcraft CCF1297 test fixture.
5. DCR measured on a Keithley 580 micro-ohmmeter or equivalent and a Coilcraft CCF858 test fixture.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
Specifications subject to change without notice.
Please check our website for latest information.
Document AS101-2
Revised 08/04/11
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2012
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
