Miniature Aluminum Electrolytic Capacitors
RADIAL LEADS, POLARIZED, NEW FURTHER REDUCED CASE SIZING,
FROM NRWA WIDE TEMPERATURE RANGE
RoHS
EXTENDED TEMPERATURE
Compliant
NRWA
NRWS
includes all homogeneous materials
(today’s standard)
(reduced sizes)
NRWS Series
• MEETS THE REQUIREMENTS OF AEC-Q200*
*Contact NIC for supporting test data
CHARACTERISTICS
Rated Voltage Range
Capacitance Range
Operating Temperature Range
Capacitance Tolerance
Maximum Leakage Current @ +20°c
After 1 min.
After 2 min.
W.V. (Vdc)
S.V. (Vdc)
C < 1,000μF
C = 2,200μF
C = 3,300μF
C = 4,700μF
C = 6,800μF
C = 10,000μF
C = 15,000μF
Z-25°C/Z+20°C
Z-40°C/Z+20°C
Δ
Capacitance
Δ
Tan
δ
Δ
LC
Δ
Capacitance
Δ
Tan
δ
Δ
LC
*See Part Number System for Details
P N b S
f D il
Max. Tan
δ
at 120Hz/20°C
Low Temperature Stability
Impedance Ratio @ 120Hz
Load Life Test at +105°C & Rated W.V
2,000 Hours: 16V ~ 100V D> 10φ
1,000 Hours: All others
Shelf Life Test
+105°C 1,000 Hours
No Load
6.3
8
0.28
0.30
0.32
0.34
0.36
0.38
0.56
5
12
6.3 ~ 100VDC
2.2 ~ 15,000μF
-55°C ~ +105°C
±20% (M)
0.03CV or 4μA whichever is greater
0.01CV or 3μA whichever is greater
10
16
25
35
50
63
13
20
32
44
63
79
0.24
0.20
0.16
0.14
0.12
0.10
0.26
0.22
0.18
0.16
0.14
-
0.28
0.24
0.20
0.18
0.16
-
0.30
0.26
0.22
0.20
-
-
0.32
0.28
0.24
-
-
-
0.34
0.30
-
-
-
-
0.52
-
-
-
-
-
4
3
2
2
2
2
10
8
5
4
4
4
Within ±20% of initial measured value
Less than 200% of specified value
Less than specified value
Within ±20% of initial measured value
Less than 200% of specified value
Less than specified value
100
125
0.08
-
-
-
-
-
-
2
4
Note: Capacitors shall conform to JIS-C-5141, unless otherwise specified here.
*1. Add 0.5 every 1000μF for more than 1000μF *2. Add 1.0 every 1000μF for more than 1000μF
STANDARD PRODUCT AND CASE SIZE TABLE DφxL (mm)
Cap. (μF)
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1,000
2,200
3,300
4,700
6,800
10,000
15,000
Code
2R2
3R3
4R7
100
220
330
470
101
221
331
471
102
222
332
472
682
103
153
6.3
-
-
-
-
-
-
-
-
5x11
6.3x11
6.3x11
8x11.5
10x16
10x20
12.5x20
12.5x25
16x25
16x36
5
0.5
2.0
0.5
10
-
-
-
-
-
-
-
5x11
6.3x11
6.3x11
6.3x11
10x12.5
10x20
12.5x20
12.5x25
16x25
16x31
18x36
16
-
-
-
-
-
-
-
5x11
6.3x11
8x11.5
8x11.5
10x16
12.5x20
12.5x25
16x25
16x31
18x36
-
Working Voltage (Vdc)
25
35
-
-
-
-
-
-
-
-
-
-
-
5x11
5x11
5x11
6.3x11
6.3x11
8x11.5
8x11.5
8x11.5
10x12.5
10x12.5
10x16
10x20
12.5x20
12.5x25
16x25
16x25
16x35
16x31
18x36
18x36
-
-
-
-
-
50
5x11
5x11
5x11
5x11
5x11
5x11
6.3x11
8x11.5
10x12.5
10x16
10x20
12.5x25
16x31
18x36
-
-
-
-
63
5x11
5x11
5x11
5x11
5x11
6.3x11
6.3x11
8x12.5
10x16
10x20
12.5x20
16x25
-
-
-
-
-
-
100
-
-
-
-
8x11.5
8x12.5
10x12.5
10x20
12.5x25
16x25
16x31
-
-
-
-
-
-
-
LEAD SPACING AND DIAMETER (mm)
Case Dia. (Dφ)
Lead Dia. (Dφ)
Lead Spacing (F)
Dim.
α
6.3 8
10 12.5
0.5 0.6 0.6 0.6
2.5 3.5 5.0 5.0
0.5 0.5 0.5 0.5
16 18
0.8 0.8
7.5 7.5
0.5 0.5
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
SPECIFICATIONS ARE SUBJECT TO CHANGE
1
Miniature Aluminum Electrolytic Capacitors
STANDARD VALUES, SPECIFICATIONS AND CASE SIZES (mm)
Part Number
NRWS221M6.3V5x11F
NRWS331M6.3V6.3x11F
NRWS471M6.3V6.3x11F
NRWS102M6.3V8x11.5F
NRWS222M6.3V10x16F
NRWS332M6.3V10x20F
NRWS472M6.3V12.5x20F
NRWS682M6.3V12.5x25F
NRWS103M6.3V16x25F
NRWS153M6.3V16x36F
NRWS101M10V5x11F
NRWS221M10V6.3x11F
NRWS331M10V6.3x11F
NRWS471M10V6.3x11F
NRWS102M10V10x12.5F
NRWS222M10V10x20F
NRWS332M10V12.5x20F
NRWS472M10V12.5x25F
NRWS682M10V16x25F
NRWS103M10V16x31F
NRWS153M10V18x36F
NRWS101M16V5x11F
NRWS221M16V6.3x11F
NRWS331M16V8x11.5F
NRWS471M16V8x11.5F
NRWS102M16V10x16F
NRWS222M16V12.5x20F
NRWS332M16V12.5x25F
NRWS472M16V16x25F
NRWS682M16V16x31F
NRWS103M16V18x36F
NRWS470M25V5x11F
NRWS101M25V6.3x11F
NRWS221M25V8x11.5F
NRWS331M25V8x11.5F
NRWS471M25V10x12.5F
NRWS102M25V10x20F
NRWS222M25V12.5x25F
NRWS332M25V16x25F
NRWS472M25V16x31F
NRWS682M25V18x36F
NRWS330M35V5x11F
NRWS470M35V5x11F
NRWS101M35V6.3x11F
NRWS221M35V8x11.5F
NRWS331M35V10x12.5F
NRWS471M35V10x16F
NRWS102M35V12.5x20F
NRWS222M35V16x25F
NRWS332M35V16x35F
NRWS472M35V18x36F
NRWS2R2M50V5x11F
NRWS3R3M50V5x11F
NRWS4R7M50V5x11F
NRWS100M50V5x11F
NRWS220M50V5x11F
Cap.
(μF)
220
330
470
1,000
2,200
3,300
4,700
6,800
10,000
15,000
100
220
330
470
1,000
2,200
3,300
4,700
6,800
10,000
15,000
100
220
330
470
1,000
2,200
3,300
4,700
6,800
10,000
47
100
220
330
470
1,000
2,200
3,300
4,700
6,800
33
47
100
220
330
470
1,000
2,200
3,300
4,700
2.2
3.3
4.7
10
22
W.V.
(Vdc)
NRWS Series
Load Life Hours
@+105°C
1,000
1,000
1,000
1,000
2,000
2,000
2,000
2,000
2,000
2,000
1,000
1,000
1,000
1,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
1,000
1,000
1,000
1,000
2,000
2,000
2,000
2,000
2,000
2,000
1,000
1,000
1,000
1,000
2,000
2,000
2,000
2,000
2,000
2,000
1,000
1,000
1,000
1,000
1,000
1,000
2,000
2,000
2,000
2,000
1,000
1,000
1,000
1,000
1,000
6.3
10
16
25
35
50
Dissipation Factor Ripple Current Rating (mA) Max. Impedance (Ω)
+20°C/120Hz
+105°C/100kHz
+20°C/100KHz
0.28
160
1.40
0.28
240
0.58
0.28
250
0.55
0.28
450
0.26
0.30
760
0.12
0.32
900
0.10
0.34
1100
0.072
0.36
1420
0.054
0.38
1700
0.043
0.56
2100
0.032
0.24
150
1.40
0.24
240
0.58
0.24
250
0.55
0.24
370
0.39
0.24
560
0.16
0.26
900
0.10
0.28
1100
0.074
0.30
1420
0.054
0.32
1700
0.043
0.34
1950
0.035
0.52
2400
0.028
0.20
150
1.40
0.20
240
0.55
0.20
370
0.35
0.20
450
0.28
0.20
760
0.13
0.22
1100
0.075
0.24
1320
0.054
0.26
1600
0.043
0.28
1900
0.035
0.30
2300
0.028
0.16
150
1.40
0.16
240
0.60
0.16
370
0.39
0.16
400
0.34
0.16
560
0.17
0.16
900
0.10
0.18
1320
0.062
0.20
1600
0.043
0.22
1900
0.035
0.24
2200
0.028
0.14
120
2.10
0.14
140
2.10
0.14
180
1.10
0.14
360
0.46
0.14
580
0.26
0.14
650
0.18
0.14
900
0.11
0.16
1400
0.056
0.18
1800
0.038
0.20
2000
0.035
0.12
40
5.5
0.12
50
4.0
0.12
80
2.80
0.12
90
2.30
0.12
110
2.20
For Automotive Applications see part number system
2
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
SPECIFICATIONS ARE SUBJECT TO CHANGE
Miniature Aluminum Electrolytic Capacitors
STANDARD VALUES, SPECIFICATIONS AND CASE SIZES (mm)
Part Number
NRWS Series
Load Life Hours
@+105°C
1,000
1,000
1,000
2,000
2,000
2,000
2,000
2,000
2,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
2,000
2,000
2,000
2,000
1,000
1,000
2,000
2,000
2,000
2,000
2,000
Cap.
W.V.
Dissipation Factor Ripple Current Rating (mA) Max. Impedance (Ω)
(μF)
(Vdc)
+20°C/120Hz
+105°C/100KHz
+20°C/100KHz
NRWS330M50V5x11F
33
0.12
120
2.10
NRWS470M50V6.3x11F
47
0.12
180
1.10
NRWS101M50V8x11.5F
100
0.12
310
0.55
NRWS221M50V10x12.5F
220
0.12
500
0.30
NRWS331M50V10x16F
330
50
0.12
650
0.20
NRWS471M50V10x20F
470
0.12
800
0.13
NRWS102M50V12.5x25F
1,000
0.12
1100
0.10
NRWS222M50V16x31F
2,200
0.14
1650
0.055
NRWS332M50V18x36F
3,300
0.16
2000
0.035
NRWS2R2M63V5x11F
2.2
0.10
42
8.3
NRWS3R3M63V5x11F
3.3
0.10
58
6.0
NRWS4R7M63V5x11F
4.7
0.10
64
4.20
NRWS100M63V5x11F
10
0.10
90
2.80
NRWS220M63V5x11F
22
0.10
140
2.40
NRWS330M63V6.3x11F
33
0.10
200
1.40
63
NRWS470M63V6.3x11F
47
0.10
240
1.30
NRWS101M63V8x12.5F
100
0.10
300
0.60
NRWS221M63V10x16F
220
0.10
520
0.22
NRWS331M63V10x20F
330
0.10
765
0.17
NRWS471M63V12.5x20F
470
0.10
960
0.14
NRWS102M63V16x25F
1,000
0.10
1100
0.065
NRWS220M100V8x11.5F
22
0.08
235
0.83
NRWS330M100V8x12.5F
33
0.08
300
0.60
NRWS470M100V10x12.5F
47
0.08
330
0.39
NRWS101M100V10x20F
100
100
0.08
450
0.24
NRWS221M100V12.5x25F
220
0.08
700
0.15
NRWS331M100V16x25F
330
0.08
950
0.09
NRWS471M100V16x31F
470
0.08
1100
0.085
For Automotive Applications see part number system
RIPPLE CURRENT CORRECTION FACTORS
Cap. (μF)
~ 47
> 47 ~ 220
> 220 ~ 1,000
> 1,000
Frequency (Hz)
100
1K
10K ~
0.50 0.80
1.0
0.55 0.85
1.0
0.65 0.90
1.0
0.75 0.90
1.0
DIMENSIONS (mm)
Polarity Marking
Sleeve
+
dφ ± 0.05
F ± 0.5
-
L +
β
max.
15mm Min.
β
= L < 20mm = 1.5mm, L > 20mm = 2.0mm
Drawing is representative of parts as supplied in bulk or
straight lead format, please see taping specification for details
on taped format packaging.
4mm
Min.
Dφ ±
α
PART NUMBER SYSTEM
NRWS 101 M 35V 6.3X11 TB Y F
.
RoHS Compliant
TB = Tape & Box*
Case Size (DφxL)
Working Voltage (Vdc)
Tolerance Code (M=20%)
Capacitance Code: First 2 characters
significant, third character is multiplier
Series
*see taping specifications for details
Optional: For automotive equipment, sourced to special
production and inspection at TS-16949 certified production site
PRECAUTIONS
Please review the notes on correct use, safety and precautions found on
pages T10
&
T11
of NIC’s
Electrolytic Capacitor catalog.
Also found at
www.niccomp.com/precautions
If in doubt or uncertainty, please review your specific application - process
details with NIC’s technical support personnel:
tpmg@niccomp.com
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
SPECIFICATIONS ARE SUBJECT TO CHANGE
3
京公网安备 11010802033920号
EEWORLD
