CN-RT
anti sulfuration chip networks
(concave termination)
resistors
EU
features
•
Excellent anti-sulfuration characteristic
due to using high sulfuration-proof inner
top electrode material
•
More advancement in the mounting density than
individual chip resistors
•
Mounting cost reduction by decreasing the number
of parts mounting times
•
Higher self-alignment effect in reflow-soldering process
•
Suitable for an image recognition mounter due to
square corner design
•
Products with lead-free terminations meet EU RoHS
requirements. EU RoHS regulation is not intended for
Pb-glass contained in electrode, resistor element and glass.
dimensions and construction
b
W
a
L
P
C
Dimensions
inches
(mm)
L±0.2 W±0.2
c
d±0.1 t±0.1 a (
top
) a (
bottom
) b±0.1
0.126 0.06 .01±.008 0.016
.02±.004 .016±.006
CN1J4RT
(3.2)
(0.5±0.1) (0.4±0.15)
(1.6) (0.3±0.2) (0.4)
Type
CN2A4RT
0.2
(5.08)
0.08 .016±.008
(2.0) (0.4±0.2)
0.022
0.126 .02±.01
(0.55)
(3.2) (0.5±0.3)
0.006
0.024
(0.6)
.03±.004 .03±.006
(0.15)
(0.8±0.1) (0.75±0.15)
P
0.031
(0.8)
0.05
(1.27)
Weight
(g)
10.2
20.6
33.5
d
Inner
Ceramic Protective Outer Resistive
Electrode
Film
Substrate Coating Electrode
CN2B4RT
ordering information
New Part #
CN
Type
CN
CNZ
1J
Size
1J
2A
2B
4
Number
of Resistors
4
RT
Termination
Material
RT : Sn
TD
Packaging
TD: Paper
TE: Plastic
Embossed
103
Nominal
Resistance
3 digits
J
Tolerance
J : ±5%
For further information on packaging,
please refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
1/28/11
68
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
anti sulfuration chip networks
(concave termination)
circuit schematic
CN1J4RT
CN2A4RT
CN2B4RT
R
1
R
2
R
3
R
4
jumper ratings
Type
CNZ1J4RT
CNZ2A4RT
50mΩ max.
Resistance
Current Rating
0.5A
1.0A
R
1
= R
2
= R
3
= R
4
CNZ2B4RT
applications and ratings
Part
Designation
CN1J4RT
CN2A4RT
CN2B4RT
Power
Rating
(w/ Element)
0.063
0.1
0.125
T.C.R.
(x10
-6
/K)
Maximum
Resistance Absolute
Operating
Rated
Overload
Range (Ω) Maximum
Temperature
Working
Voltage
J:±5% E24 Working
Range
Temperature
Voltage (5 Secs. Max.)
50V
100V
-55°C to
100V
200V
10~1M
+70°C
+125°C
200V
400V
Taping & Quantity Reel
(pcs)
TD
5,000
—
—
TE
—
4,000
4,000
±200
* Note that network resistors generate higher heat rather than single flat chip resistor under rated power output
environmental applications
Derating Curve
100
% Rated Power
80
60
40
20
0
-60 -40 -20
-55
80 100 120 140
125
70
Ambient Temperature
(°C)
0
20
40
60
Performance Characteristics
Parameter
Resistance
T.C.R.
Overload (Short time)
Resistance to Solder Heat
Rapid Change of Temperature
Moisture Resistance
Endurance at 70°C
Low Temperature Exposure
High Temperature Exposure
Requirement
Limit
Within specified
tolerance
Within specified
T.C.R.
±2.0%
±1.0%
±1.0%
±5.0%
±5.0%
±1.0%
±1.0%
∆
R
Typical
—
—
±0.50%
±0.25%
±0.50%
±1.0%
±0.50%
±0.20%
±0.20%
25°C
+25°C/-55°C and +25°C/+125°C
Rated voltage x 2.5 for 5 seconds
260°C ± 5°C, 10 seconds ± 1 second
-55°C (30 minutes) / +125°C (30 minutes), 5 cycles
40°C ± 2°C, 90-95% RH, 1000 hours, 1.5 hr ON / 0.5 hr OFF cycle
70°C ± 2°C, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
-55°C, 1 hour
+125°C, 1000 hours
Test Method
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
1/28/11
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
69
resistors
CN-RT
