M A TE RIA L: NY LO N 6/6 M A TE RIA L: NY LO N 6/6
UL 94 V -2 (RM S -01)
UL 94 V -0 (RM S -19)
DIM . "A "
CO LO R: NA TURA L
CO LO R: NA TURA L
±.015 [0.4]
P A RT NO .
P A RT NO .
P S -3-01
P S -4-01
P S -6-01
P S -7-01
P S -8-01
P S -10-01
P S -12-01
P S -14-01
P S -3-19
P S -4-19
P S -6-19
P S -7-19
P S -8-19
P S -10-19
P S -12-19
P S -14-19
3/16 [4.8]
1/4 [6.4]
3/8 [9.5]
7/16 [11.1]
1/2 [12.7]
5/8 [15.9]
3/4 [19.1]
7/8 [22.2]
.28 7.1
"A"
7/32 [5.6]
.11 2.8 REF
.56 14.3
REF
7/32 5.6
TO SNAP-LOCK IN A .187±.003
[4.75±0.08] DIA. HOLE, IN A
.031-.078 [0.79-1.98] PANEL THICKNESS
NOTES:
1.MATERIAL: "IMPACT MODIFIED" NYLON 6/6 (RMS-73)
AVAILABLE BY SPECIAL ORDER ONLY.
TO ORDER RELACE "-01" WITH "-73".
MATERIAL: " HEAT RESISTANT" NYLON 4/6 UL 94 V-2 (RMS-109)
AVAILABLE BY SPECIAL ORDER ONLY.
TO ORDER REPLACE "-01" WITH "-109"
2. COLOR: BLACK AVAILABLE BY SPECIAL ORDER ONLY.
TO ORDER ADD SUFFIX "BK" TO PART NO.
3. PART IS ALSO AVAILABLE IN A 1/8 (3.2) THICK CHASSIS BY
SPECIAL ORDER ONLY. TO ORDER USE P/N: PS-2-XX-XX
TYPICAL APPLICATION
TITLE:
CREATED USING
SOLIDWORKS
PUSH SPACER
FILE #: PS
SHEET: 1 OF 1
RE:
SHEET SIZE: A
DWN: SK
DT: 02/24/05
APP: SK
CHKD: DZ
PART #
H
G
F
-
REV.
SEE ECN #1208 FOR CHANGES
SEE ECN #1196 FOR CHANGES
COMPLETELY REDRAWN, SEE ECN #949
SEE ENGINEERING FOR REVISIONS A-E
DESCRIPTION
SK
11/29/06
SK
07/17/06
SK
02/24/05
-
-
ENGR. DATE
DWG IN
IN [MM]
FINAL
TOLERANCES
UNLESS NOTED
.XX=±.010
.XXX=±.005
FRAC.=±1/64
ANG.=±1°
RICHCO, INC.
RICHCO, INC.
ENG@RICHCO-INC.COM
(773) 539-4060
SEE TABLE
CA
PRINT
TYPE
