Fused Single-Mode WDM
(1310/1550nm)
SWDM53 Series
Product Description
Oplink’s 1310/1550nm fused single-mode wavelength division multiplexers
are manufactured using the proven fused biconical taper technology and
Oplink’s stringent quality procedures. With low insertion loss and flat pass-
band, this device is ideal for combining or separating optical signals in the
1310 and 1550nm bands.
Oplink can provide customized designs to meet specialized feature applica-
tions. Also, Oplink offers modular assemblies that integrate other compo-
nents to form a full function module or subsystem.
Port 2 Signal
Port 1 In
L
Port 4 (terminated for
1x2 configuration)
Ø
Port 3 Pump
Performance Specificationns
SWDM53 Series
Standard
High Isolation
Unit
Features
Ultra Low Insertion Loss
Ultra High Isolation
Low Polarization Sensitivity
High Directivity
High Stable & Reliable
Bidirectional
Grade
(P=Premium, A=Grade A)
Operating Wavelength
Insertion Loss
Wavelength Dependent Loss
Temperature Dependent Loss
Isolation
Polarization Dependent Loss
Directivity
Maximum Power Handling
Operating Temperature
Storage Temperature
Fiber Type
Package Dimensions
**
P
< 0.3
< 0.15
< 0.15
> 17
< 0.1
A
< 0.5
< 0.20
< 0.20
> 16
> 55
500
- 10 to + 70
- 40 to + 85
P
< 0.7
< 0.15
< 0.15
> 34
< 0.2
A
< 1.0
< 0.20
< 0.20
> 30
dB
dB
dB
dB
dB
dB
mW
°C
°C
1295~1325nm / 1528~1565nm
Applications
Telecommunications
CATV
Subscriber Loop
Corning SMF-28
P1: 250µm SMF-28 fiber
P2: 900µm loose tube
P3: 3mm cable
P4:
(ø) 3.0 x (L) 54.0
(ø) 3.0 x (L) 60.0
(L) 96 x (W) 12 x (H) 6.4
(L)100 x (W) 80 x (H) 7.0
mm
Local Area Networks
Laboratory R&D
Note:
* Values are referenced without connector loss.
** The mechanical tolerance is +/-0.2 mm on all package dimensions unless otherwise specified.
S0166 - R01. 20101001
Fused Single-Mode WDM (1310/1550nm)
SWDM53 Series
Ordering Information
Oplink can provide a remarkable range of customized optical solutions. For detail, please contact Oplink’s OEM
design team or account manager for your requirements and ordering information (510) 933-7200.
SWDM
5
3
0
0
Wavelength
1550/1310nm= 53
Premium Grade= P
A Grade= A
Grade
Fiber Length
0.5 Meter = H
1.0 Meter = 1
1.5 Meters = 5
2.0 Meters = 2
Connector Type
None = 1
FC/PC = 2
FC/SPC = 3
FC/APC = 4
SC/PC = 5
SC/SPC = 6
SC/APC = 7
ST = 8
LC = 9
MU = A
Type
Standard= S
High Isolation= H*(P4 only)
Configuration
1x2 = 1
2x2 = 2 **
Package & Fiber Type
P1+ 250μm bare fiber = 11
P2+ 900μm loose tube = 22
P3+ 3mm cable = 33
P4+ 900μm loose tube = 42
P4+ 3mm cable = 43
46335 Landing Pkwy Fremont, CA 94538 Tel: (510) 933-7200 Fax: (510) 933-7300 Email: Sales@Oplink.com • www.oplink.com
Notes :
* Must be P4 package
** Not available for high isolation model
S0166 - R01. 20101001
Product Lines:
Mux/Demux
Switching/Routing
Coupling/Splitting
Monitoring/Conditioning
Amplification
Transmission
Interconnect
RGB Laser Modules
