TVS4201MR6
Transient Voltage
Suppressors
Low Clamping Voltage Surge Protection
Diode Array
The TVS4201MR6 transient voltage suppressor is designed to
protect high speed data lines from ESD, EFT, and lightning surges.
Features
www.onsemi.com
6
1
TSOP−6
CASE 318G
•
Protection for the Following IEC Standards:
•
•
•
•
•
IEC 61000−4−2 (ESD)
±30
kV (Contact)
IEC 61000−4−5 (Lightning) 25 A (8/20
ms)
Low Clamping Voltage
Low Leakage
UL Flammability Rating of 94 V−0
SZ Prefix for Automotive and Other Applications Requiring Unique
Site and Control Change Requirements; AEC−Q101 Qualified and
PPAP Capable
These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
High Speed Communication Line Protection
USB 1.1 and 2.0 Power and Data Line Protection
Digital Video Interface (DVI)
Monitors and Flat Panel Displays
MARKING DIAGRAM
42 MG
G
42 = Specific Device Code
M = Date Code
G
= Pb−Free Package
(Note: Microdot may be in either location)
*Date Code orientation may vary
depending upon manufacturing location.
Typical Applications
•
•
•
•
PIN CONFIGURATION AND SCHEMATIC
I/O 1
Unit
W
°C
°C
°C
kV
A
SZTVS4201MR6T1G
V
N
2
I/O 3
5 V
P
4 I/O
6 I/O
MAXIMUM RATINGS
(T
J
= 25°C unless otherwise noted)
Rating
Peak Power Dissipation
8/20
ms
@ T
A
= 25°C (Note 1)
Operating Junction Temperature Range
Storage Temperature Range
Lead Solder Temperature −
Maximum (10 Seconds)
IEC 61000−4−2 Air (ESD)
IEC 61000−4−2 Contact (ESD)
IEC 61000−4−4 (5/50 ns)
Symbol
P
pk
T
J
T
stg
T
L
260
ESD
EFT
±30
±30
40
Value
500
−40 to +125
−55 to +150
ORDERING INFORMATION
Device
TVS4201MR6T1G
Package
TSOP−6
(Pb−Free)
TSOP−6
(Pb−Free)
Shipping
3000 / Tape &
Reel
3000 / Tape &
Reel
Stresses exceeding those listed in the Maximum Ratings table may damage the
device. If any of these limits are exceeded, device functionality should not be
assumed, damage may occur and reliability may be affected.
1. Non−repetitive current pulse per Figure 1 (Pin 5 to Pin 2)
See Application Note AND8308/D for further description of
survivability specs.
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specification
Brochure, BRD8011/D.
©
Semiconductor Components Industries, LLC, 2015
1
June, 2015 − Rev. 1
Publication Order Number:
TVS4201MR6/D
TVS4201MR6
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise noted)
Symbol
I
PP
V
C
V
RWM
I
R
V
BR
I
T
I
F
V
F
P
pk
C
Parameter
Maximum Reverse Peak Pulse Current
Clamping Voltage @ I
PP
Working Peak Reverse Voltage
Maximum Reverse Leakage Current @ V
RWM
Breakdown Voltage @ I
T
Test Current
Forward Current
Forward Voltage @ I
F
Peak Power Dissipation
Capacitance @ V
R
= 0 and f = 1.0 MHz
I
PP
V
C
V
BR
V
RWM
I
R
V
F
I
T
V
I
F
I
Uni−Directional TVS
*See Application Note AND8308/D for detailed explanations of
datasheet parameters.
ELECTRICAL CHARACTERISTICS
(T
J
=25°C unless otherwise specified)
Parameter
Reverse Working Voltage
Breakdown Voltage
Reverse Leakage Current
Clamping Voltage
(t
p
= 8/20
ms
per Figure 1)
Symbol
V
RWM
V
BR
I
R
V
C
(Note 2)
I
T
=1 mA, (Note 3)
V
RWM
= 5 V
I
PP
= 1 A, Any I/O to GND
I
PP
= 5 A, Any I/O to GND
I
PP
= 8 A, Any I/O to GND
I
PP
= 25 A, Any I/O to GND
Junction Capacitance
Junction Capacitance
C
J
C
J
V
R
= 0 V, f=1 MHz between I/O Pins and GND
V
R
= 0 V, f=1 MHz between I/O Pins
3.0
1.5
6.0
1.0
8.5
9.0
10
12
5.0
3.0
pF
pF
Conditions
Min
Typ
Max
5.0
Unit
V
V
mA
V
2. TVS devices are normally selected according to the working peak reverse voltage (V
RWM
), which should be equal or greater than the DC
or continuous peak operating voltage level.
3. V
BR
is measured at pulse test current I
T
.
100
% OF PEAK PULSE CURRENT
90
80
70
60
50
40
30
20
10
0
0
20
40
t, TIME (ms)
60
80
t
P
20
18
CLAMPING VOLTAGE (V)
16
14
12
10
8
6
4
2
0
0
5
10
15
20
PEAK PULSE CURRENT (A)
25
30
I/O−GND
t
r
PEAK VALUE I
RSM
@ 8
ms
PULSE WIDTH (t
P
) IS DEFINED
AS THAT POINT WHERE THE
PEAK CURRENT DECAY = 8
ms
HALF VALUE I
RSM
/2 @ 20
ms
Figure 1. IEC61000−4−5 8/20
ms
Pulse Waveform
Figure 2. Clamping Voltage vs. Peak Pulse Current
(t
p
= 8/20
ms
per Figure 1)
www.onsemi.com
2
TVS4201MR6
100
80
VOLTAGE (V)
VOLTAGE (V)
0
20
40
60
TIME (ns)
80
100
120
140
60
40
20
0
−20
−20
20
0
−20
−40
−60
−80
−100
−20
0
20
40
60
TIME (ns)
80
100
120
140
Figure 3. IEC61000−4−2 +8 kV Contact Clamping
Voltage
IEC 61000−4−2 Spec.
Test Volt-
age (kV)
2
4
6
8
First Peak
Current
(A)
7.5
15
22.5
30
Current at
30 ns (A)
4
8
12
16
Current at
60 ns (A)
2
4
6
8
Figure 4. IEC61000−4−2 −8 kV Contact Clamping
Voltage
IEC61000−4−2 Waveform
I
peak
100%
90%
Level
1
2
3
4
I @ 30 ns
I @ 60 ns
10%
t
P
= 0.7 ns to 1 ns
Figure 5. IEC61000−4−2 Spec
ESD Gun
TVS
Oscilloscope
50
W
Cable
50
W
Figure 6. Diagram of ESD Test Setup
The following is taken from Application Note
AND8308/D − Interpretation of Datasheet Parameters
for ESD Devices.
ESD Voltage Clamping
For sensitive circuit elements it is important to limit the
voltage that an IC will be exposed to during an ESD event
to as low a voltage as possible. The ESD clamping voltage
is the voltage drop across the ESD protection diode during
an ESD event per the IEC61000−4−2 waveform. Since the
IEC61000−4−2 was written as a pass/fail spec for larger
systems such as cell phones or laptop computers it is not
clearly defined in the spec how to specify a clamping voltage
at the device level. ON Semiconductor has developed a way
to examine the entire voltage waveform across the ESD
protection diode over the time domain of an ESD pulse in the
form of an oscilloscope screenshot, which can be found on
the datasheets for all ESD protection diodes. For more
information on how ON Semiconductor creates these
screenshots and how to interpret them please refer to
AND8307/D.
www.onsemi.com
3
TVS4201MR6
TYPICAL PERFORMANCE CURVES
(T
J
= 25°C unless otherwise noted)
100
PEAK POWER DISSIPATION (%)
JUNCTION CAPACITANCE (pF)
90
80
70
60
50
40
30
20
10
0
0
25
50
75
100
125
150
175
200
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0
1
2
3
4
5
I/O−I/O
I/O−GND
T
A
, AMBIENT TEMPERATURE (°C)
V
BR
, REVERSE VOLTAGE (V)
Figure 7. Pulse Derating Curve
Figure 8. Junction Capacitance vs Reverse Voltage
Figure 9. RF Insertion Loss
www.onsemi.com
4
TVS4201MR6
TYPICAL APPLICATIONS
RJ45
Connector
TX+
TX+
TX−
TX−
PHY
Ethernet
(10/100)
RX+
Coupling
Transformers
RX+
RX−
RX−
TVS4201MR6
V
CC
GND
N/C
N/C
Figure 10. Protection for Ethernet 10/100 (Differential mode)
R1
RTIP
R2
RRING
V
CC
R3
T1
T1/E1
TRANCEIVER
TVS4201MR6
R4
TTIP
R5
TRING
T2
Figure 11. TI/E1 Interface Protection
www.onsemi.com
5
