Mini 980/1550nm WDM/Isolator
Hybrid
Mini WDIH59 Series
Product Description
Oplink’s WDIH is a combination of a 980/1550(1585)nm filter and a C-band
1550nm (or L-band 1585nm) polarization insensitive optical isolator. The Mini
WDIH is a low cost model with excellent performance including low insertion
loss, high isolation, high return loss, and low polarization dependent loss (PDL).
This product offers integrated solutions to EDFA applications by combining
more functions into a very compact package. The product package dimension
is about 3.0×30mm.
Oplink can provide customized designs to meet specialized feature applica-
tions. Also, Oplink offers modular assemblies that integrate other compo-
nents to form a full function module or subsystem.
Performance Specificationns
Mini WDIH59 Series
Min
Typical
Max
Unit
Features
Operating Wavelength Range (λs)
Pump Channel Wavelength Range (λp)
Channel Isolation (over λs,
0~70°C, all SOP)
Isolation
Insertion Loss (over
wavelength range
and 0~70°C, all SOP)
WDL
Return Loss
Polarization Dependent Loss
(PDL)
Polarization Mode Dispersion
(PMD)
Directivity
Operting Power Handling
Operating Temperature
Storage Temperature
Fiber Type
Package Dimension
COM & Pump Ports
Pass Port
Single Stage
Dual Stage
Single Stage
Dual Stage
Single Stage
Dual Stage
1528 ~ 1564 or 1570 ~ 1604
965 ~ 995
21
36
15
25
0.5
0.9
1.1
0.2
≥ 50
0.10
0.15
0.25
0.05
≥ 50
≤ 500
0 to +70
-40 to +85
PureMode HI1060 FLEX
SMF-28, 250µm Bare Fiber
(Φ) 3.0 x (L) 30.0
nm
nm
dB
dB
Wide Operating Wavelength Range
Compact Size
High Isolation
Ultra Low PDL & PMD
Highly Stable & Reliable
Small Package Dimension
Epoxy-free Optical Path
Pump Channel @ λs
Signal Channel @ λp
Pump Channel
Signal
Channel
Single Stage
Dual Stage
dB
dB
dB
dB
ps
dB
mW
°C
°C
Applications
EDFA
mm
S0078 - R02. 20100702
Mini 980/1550nm WDM/Isolator Hybrid
Mini WDIH59 Series
Mechanical Drawing / Package Dimensions (dimension in mm)
Forward Type
30.0mm
COMMON
PUMP
Ø3.0mm
PASS
Backward Type
30.0mm
Ø3.0mm
PASS
COMMON
PUMP
46335 Landing Pkwy Fremont, CA 94538 Tel: (510) 933-7200 Fax: (510) 933-7300 Email: Sales@Oplink.com • www.oplink.com
Ordering Information
Oplink can provide a remarkable range of customized optical solutions. For detail, please contact Oplink’s OEM
design team or account manager for your requirements and ordering information (510) 933-7200.
WDIH
0
3
0
Wavelength
1550/980nm = 1598
1585/980nm = 1698
Stage
Single = S
Dual = D
Package Type
P3 = 3
Fiber Length
0.5 meter = H
1.0 Meter = 1
1.5 Meters = 5
2.0 Meters = 2
Connector Type
None = 1
FC/PC = 2
FC/SPC = 3
FC/APC = 4
SC/PC = 5
SC/SPC = 6
SC/APC = 7
ST = 8
LC = 9
MU = A
Configuration
Forward Type = F
Backward Type = B
Fiber Type
As specified in perfor-
mance table
S0078 - R02. 20100702
Product Lines:
Mux/Demux
Switching/Routing
Coupling/Splitting
Monitoring/Conditioning
Amplification
Transmission
Interconnect
RGB Laser Modules
